Specifications
Tank Material :
Q235 Carbon Steel
Gross Vehicle Weight :
14,000kg
Supply Ability :
10pcs/month
Pump Flow Rate :
60m³/h
Delivery Time :
30DAYS
Overall Dimension :
7,850 × 2,340 × 3,100mm
Engine Power :
118kW (160HP)
Model Number :
HOWO
Pump Head :
90m
Water Cannon Range :
>35m
Max Torque :
550N*m
Place of Origin :
CHINA
Tank Volume :
10,000L (10m³)
MOQ :
1
Drive Type :
4×4 All-Wheel Drive
Brand Name :
CLW Group
Description
Sinotruk HOWO 4*4 10000L Water Sprinkler Truck

The Sinotruk HOWO 4*4 water sprinkler truck is purpose-built for off-road and rough-terrain watering operations where conventional 4*2 trucks cannot operate. Built on a Sinotruk HOWO all-wheel-drive chassis and powered by a 160HP Yuchai diesel engine, this truck carries a 10,000-liter Q235 carbon steel tank and a Weilong self-priming centrifugal pump delivering 60m³/h flow.

The multi-directional spray system includes front flush, rear spray, side sprinklers and a 360° rotating water cannon with over 35 meters range, covering road washing, dust suppression, green belt irrigation and emergency fire support.

The 4*4 drivetrain, high ground clearance and off-road tires make this truck ideal for mining sites, rural roads, mountainous areas, desert regions and tropical rainy-season conditions. Standardized bolted assembly ensures component interchangeability and easy maintenance in remote locations.

Technical Specifications
Chassis
Chassis Brand Sinotruk HOWO
Drive Type 4*4 All-Wheel Drive
Steering Right-Hand Drive (RHD)
Cab Type 2080mm, 1.5-row, 2 seats + 1 sleeper
Cab Equipment A/C, central locking, air-suspension driver seat
Engine Model Yuchai YC4E160-33
Fuel Type Diesel
Displacement 4,260ml
Max Power 118kW (160HP)
Max Torque 550N*m
Cylinder Inline 4 cylinders
Emission Standard Euro 3
Transmission 8JS85TE + PTO, 8 forward + 2 reverse, Manual
Wheelbase 4,200mm
Front Axle Load 2,500kg
Rear Axle Load 9,000kg
Rear Axle Ratio 5.286
Frame 230*75*(6+4)mm reinforced steel
Front Suspension 1,300mm leaf spring
Rear Suspension 1,900mm leaf spring
Tire 8.25R20 off-road pattern, 6pcs + 1 spare
Fuel Tank 200L
Gross Vehicle Weight 14,000kg
Curb Weight 6,800kg
Payload 7,200kg
Overall Dimension 7,850 * 2,340 * 3,100mm
Superstructure
Tank Volume 10,000L (10m³)
Tank Material Q235 Carbon Steel
Tank Body Thickness 4mm
End Plate Thickness 4mm
Baffle Thickness 4mm
Tank Shape Cylindrical (elliptical cross-section)
Manhole DN450, with cover
Anti-surge Baffles Internal wave baffles
Pump Brand Weilong
Pump Model 80QZB-60/90N
Pump Type Self-priming centrifugal
Max Flow Rate 60m³/h
Max Head 90m
Self-priming Height 6.5m
PTO Integrated with 8JS85TE transmission, cab-controlled
Driveshaft Heavy-duty, PTO to pump
Front Flush Duckbill nozzle, road washing, wide flat spray
Rear Spray Road watering behind truck, even coverage
Side Sprinkler (L+R) Green belt irrigation, width >14m
Water Cannon Rear platform, 360° rotation, range >35m, column/mist adjustable
Ball Valves SS304 large-diameter, anti-collision gaskets
Pipe Joints Cast aluminum (elbow tee, flange tee, pump inlet/outlet)
Suction Strainer Removable filter at inlet
Fire Coupling Valve Standard fire hose connection
Rear Platform Non-slip steel grating with safety guardrail
Access Ladder Rear-mounted, anti-slip rungs
Cannon Storage Box Iron box for cannon protection
Music Horn Audible warning during operation
Standard Accessories 2* water hoses, spare tire, tool kit
Sinotruk HOWO 4×4 All-Wheel Drive Water Sprinkler Truck with 10,000-liter Capacity and Yuchai 160HP Engine Sinotruk HOWO 4×4 All-Wheel Drive Water Sprinkler Truck with 10,000-liter Capacity and Yuchai 160HP Engine Sinotruk HOWO 4×4 All-Wheel Drive Water Sprinkler Truck with 10,000-liter Capacity and Yuchai 160HP Engine Sinotruk HOWO 4×4 All-Wheel Drive Water Sprinkler Truck with 10,000-liter Capacity and Yuchai 160HP Engine Sinotruk HOWO 4×4 All-Wheel Drive Water Sprinkler Truck with 10,000-liter Capacity and Yuchai 160HP Engine Sinotruk HOWO 4×4 All-Wheel Drive Water Sprinkler Truck with 10,000-liter Capacity and Yuchai 160HP Engine Sinotruk HOWO 4×4 All-Wheel Drive Water Sprinkler Truck with 10,000-liter Capacity and Yuchai 160HP Engine
Applications
  • Municipal road watering and street flushing
  • Construction site and mining dust suppression
  • Green belt, plantation and farmland irrigation
  • Emergency water transport and drought relief
  • Fire-fighting auxiliary with 360° water cannon
  • Disinfection spraying (with optional chemical dosing tray)
Key Advantages
  1. All-wheel drive – operates on mud, sand, gravel and mountain roads where 4*2 trucks get stuck
  2. 10m³ large capacity – fewer refills, longer working cycles
  3. Proven Yuchai engine – widely serviced across Africa, Middle East and Central Asia
  4. Weilong pump – 60m³/h flow, self-priming from rivers and wells
  5. Standardized bolted construction – parts are interchangeable, field-repairable
  6. Euro 3 emission – no DPF/SCR after-treatment, lower maintenance cost
Optional Equipment
  • Electric remote-control water cannon
  • Dust suppression fog cannon (30-100m)
  • Pneumatic / solenoid in-cab valve control
  • Stainless steel tank (304/316) for potable water
  • Insulated tank for hot water transport
  • Mine explosion-proof configuration
  • Arrow board and warning lights
