Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck with 400HP WEICHAI Engine, 15-18m³ Stainless Steel Material Box, and PLC Digital Control System
Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck with 400HP WEICHAI Engine, 15-18m³ Stainless Steel Material Box, and PLC Digital Control System
Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck with 400HP WEICHAI Engine, 15-18m³ Stainless Steel Material Box, and PLC Digital Control System
Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck with 400HP WEICHAI Engine, 15-18m³ Stainless Steel Material Box, and PLC Digital Control System
Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck with 400HP WEICHAI Engine, 15-18m³ Stainless Steel Material Box, and PLC Digital Control System
Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck with 400HP WEICHAI Engine, 15-18m³ Stainless Steel Material Box, and PLC Digital Control System
Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck with 400HP WEICHAI Engine, 15-18m³ Stainless Steel Material Box, and PLC Digital Control System
Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck with 400HP WEICHAI Engine, 15-18m³ Stainless Steel Material Box, and PLC Digital Control System
Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck with 400HP WEICHAI Engine, 15-18m³ Stainless Steel Material Box, and PLC Digital Control System
Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck with 400HP WEICHAI Engine, 15-18m³ Stainless Steel Material Box, and PLC Digital Control System
Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck with 400HP WEICHAI Engine, 15-18m³ Stainless Steel Material Box, and PLC Digital Control System
Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck with 400HP WEICHAI Engine, 15-18m³ Stainless Steel Material Box, and PLC Digital Control System
Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck with 400HP WEICHAI Engine, 15-18m³ Stainless Steel Material Box, and PLC Digital Control System
Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck with 400HP WEICHAI Engine, 15-18m³ Stainless Steel Material Box, and PLC Digital Control System
Specifications
Material box volume :
15-18 m³
Charging arm rotation :
350° rotation, 5m radius
Material box material :
SS304, 4mm
Engine power :
400 HP (257 kW)
Dosing accuracy :
≤±2%
Diesel tank capacity :
1.0-1.2 m³
Tire specification :
12R22.5 / 295/80R22.5 (12+1)
Engine model :
WEICHAI WP12.400E201
Transmission type :
HW19710, 10F+2R
Max speed :
80 km/h
Description
Sinotruk HOWO 8x4 15-Ton ANFO Explosive Mixing Truck
The Sinotruk HOWO 8x4 On-Site Mixed ANFO Explosive Truck is a specialized mining vehicle designed for safe and efficient mixing and loading of ANFO explosives directly at blast holes. Built on the proven HOWO 8x4 heavy-duty chassis, this vehicle is ideal for open-pit mining, quarry blasting, and large-scale infrastructure projects.
Key Features
  • Sinotruk HOWO 8x4 Chassis: 1,800+3,775+1,400mm wheelbase, GVW 31,000-32,000kg, payload 15,000-16,500kg
  • WEICHAI 400HP Euro III Engine: WP12.400E201, 400HP (257kW) with HW19710 10-speed manual transmission
  • 15-18m³ Stainless Steel Dry Material Box: Multi-compartment design, SS304 construction, 4mm thickness
  • Diesel Tank: 1.0-1.2m³ capacity (approx. 1,000-1,100kg)
  • Three-Stage Spiral Conveying System: 350° rotation, 5m radius
  • PLC Digital Control: ±2% dosing accuracy with over-temperature/pressure alarms
  • Safety Equipment: EBS/ABS, front disc brakes, speed limiter, forward exhaust, tire burst protection
  • Positioning & Control: GPS + BeiDou positioning with handheld remote control
Applications
  • Open-pit mining and quarry blasting operations
  • Large-scale infrastructure blasting projects
  • Mining contractor blasting services
  • On-site explosive logistics and mixing
Technical Specifications
Chassis Sinotruk HOWO 8x4 (LHD/RHD)
Overall Dimensions 9,850-11,600 × 2,500-2,550 × 3,900-3,980 mm
Wheelbase 1,800 + 3,775 + 1,400 mm
GVW / Payload 31,000-32,000 kg / 15,000-16,500 kg
Engine WEICHAI WP12.400E201, 400 HP (257 kW), Euro III
Transmission HW19710, 10F+2R
Max Speed 80 km/h
Tires 12R22.5 / 295/80R22.5 (12+1)
Dry Material Box 15-18 m³ (14.5-16.8 m³ effective), SS304, 4mm
Dry Material Capacity 15-16.5 tons
Diesel Tank 1.0-1.2 m³
Dosing Accuracy ≤±2%
Charging Arm 350° rotation, 5m radius
Control PLC digital with handheld remote
Positioning GPS + BeiDou
Safety EBS/ABS, speed limiter, disc brakes, forward exhaust, alarm shutdown
Applications Open-pit mining, quarrying, infrastructure blasting
