JMC 18m Hydraulic Truck Mounted Aerial Work Platform
JMC 18m Hydraulic Truck Mounted Aerial Work Platform
JMC 18m Hydraulic Truck Mounted Aerial Work Platform
JMC 18m Hydraulic Truck Mounted Aerial Work Platform
JMC 18m Hydraulic Truck Mounted Aerial Work Platform
JMC 18m Hydraulic Truck Mounted Aerial Work Platform
JMC 18m Hydraulic Truck Mounted Aerial Work Platform
JMC 18m Hydraulic Truck Mounted Aerial Work Platform
JMC 18m Hydraulic Truck Mounted Aerial Work Platform
JMC 18m Hydraulic Truck Mounted Aerial Work Platform
JMC 18m Hydraulic Truck Mounted Aerial Work Platform
JMC 18m Hydraulic Truck Mounted Aerial Work Platform
JMC 18m Hydraulic Truck Mounted Aerial Work Platform
JMC 18m Hydraulic Truck Mounted Aerial Work Platform
JMC 18m Hydraulic Truck Mounted Aerial Work Platform
JMC 18m Hydraulic Truck Mounted Aerial Work Platform
Specifications
Brand Name :
CLW
Model Number :
CLW5823
Certification :
CCC, ISO, SGS, BV
Place of Origin :
Suizhou, China
MOQ :
1 UNIT
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500 Units/Month
Delivery Time :
30-35 days
Packaging Details :
Naked Pack with Wax
Condition :
New
Type :
Floding arm Type Aerial Lift Truck
Chassis Brand :
JMC, FAW, Dongfeng, ISUZU, etc
Drive type :
4x2, left or right hand drive
Dimensions (l x w x h) (mm) :
5995*2050*2900mm
Engine Brand :
JMC, Cummins
Fuel type :
Diesel
Engine power :
85kw/115hp
Transmission type :
Manual
Emission standard :
Euro IV
Max speed :
90km/h
Wheel base :
3360mm
Bucket Size :
1000x700x1250mm
Bucket Capacity :
200kg
Max Operation Height :
16meters
Working Arm Type :
H type
Warranty :
1 year
Description

New model JMC 18m Hydraulic Truck Mounted Aerial Work Platform with folding Arm Truck

Product Description

  1. Automatic Bucket Balance System, Bucket will be Stayed in Balance Level in All Working Time.
  2. The Stretching Angle Up to 80°, which will be Easier to Handle in All Time.
  3. Full Computer Control System with Danger Warning System.
  4. LCD Screen in Both the Bucket and Truck to Display the Working Status.
  5. Rectangular Shape Arms to Increase the Arm Strength.
  6. V Shape Leg, H Shape Leg can be adapted to Different Road Condition Increasing the Stability.

Product Specification

Parameter Overall dimension (Length*width*high) (mm) 5995*2050*2900
Total Mass (kg) 5730
Curb Mass (kg) 5405
Max speed (km/h) 90
Fuel type diesel
Engine Engine power 85kw/115hp
Displacement standard EURO 4
Chassis Chassis type JMC
Drive system 4x2
Tire type 7.00R16
Wheel Base (mm) 3360
Number of tire 6
passengers 2
Cabin Single, with 2 passengers allowed, with Air conditioner
Special parameter Working platform rating loading (kg) 200
Platform height (m) 16.3
Max Working Height (m) 18
Boom type Folding arm
Max hook loading weight (kg) 1000
Loading of hook (kg) 800-1000
Bucket rotation angle (°) 360
Control Control both on the ground and remote control in cage
Safety Device Relief valve, balance valve, double-way hydraulic lock, hand operated emergency hydraulic pump
Leveling System Hydraulic stablizer to level the vehicle on uneven ground


Folding arm boom lift truck details

JMC 18m Hydraulic Truck Mounted Aerial Work PlatformJMC 18m Hydraulic Truck Mounted Aerial Work PlatformJMC 18m Hydraulic Truck Mounted Aerial Work PlatformJMC 18m Hydraulic Truck Mounted Aerial Work Platform

Aerial work truck diagram

JMC 18m Hydraulic Truck Mounted Aerial Work Platform

JMC 18m Hydraulic Truck Mounted Aerial Work Platform

Sales Service

① Pre-sales Service: Communicate with customers, analyze their needs.
② Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③ After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.

FAQ

Q1: What kinds of truck mounted aeriel platform I can order from your company?


A: There are various sizes and types of arerial platform trucks with different functions,you can contact us and tell your request. We will recommend you suitable product.

Q2: Have you supplied truck mounted aeriel platform to any overseas companies?


A: Yes,with need of government project,we offered aerial platform trucks to many Africa and south-east Asian countries.

Q3: What about warranty?


A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q4: Where is your factory? How far from Shanghai to your factory?


A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city, welcome to visit us for factory inspection.

Warranty

1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.

Spare Parts

1. Supplying quick-wearing parts at the truck delivery.
2. Good quality parts produced by the truck manufacturing factory.
3. Only charge cost price for customer convenience.
