3 Lines 6 Axles Pipe Transport Trailer 40-60T For Heavy Pipe Transport
3 Lines 6 Axles Pipe Transport Trailer 40-60T For Heavy Pipe Transport
3 Lines 6 Axles Pipe Transport Trailer 40-60T For Heavy Pipe Transport
3 Lines 6 Axles Pipe Transport Trailer 40-60T For Heavy Pipe Transport
3 Lines 6 Axles Pipe Transport Trailer 40-60T For Heavy Pipe Transport
3 Lines 6 Axles Pipe Transport Trailer 40-60T For Heavy Pipe Transport
3 Lines 6 Axles Pipe Transport Trailer 40-60T For Heavy Pipe Transport
3 Lines 6 Axles Pipe Transport Trailer 40-60T For Heavy Pipe Transport
Specifications
Brand Name :
Startrailer
MOQ :
2 units
Model Number :
LB1-001
Certification :
CCC、ISO
Place of Origin :
Shandong Province, China
Delivery Time :
35 days after received payments
Price :
USD19,000~USD39,000
Payment Terms :
T/T
Supply Ability :
30 units per month
Packaging Details :
2 units/package transported by break-bulk-vessel or roll-on-roll-off-vessel
Size :
13000mm*3000mm*1600mm
Max payload :
40-60T
Material :
Carbon Steel
Type :
Low Bed Semi Trailer
Purpose :
Logistics between cities
Description

Click this link to talk to us:
https://api.whatsapp.com/send?phone=8613864856071

3 Lines 6 Axles Pipe Transport Trailer 40-60T For Heavy Pipe Transport

Low bed trailers are most commonly used to transport heavy vehicles (such as tractors, buses, rail vehicles,etc.) mining and forestry machinery, road construction equipment (such as excavators, bulldozers, loaders, pavers, cranes,etc.) and other heavy-duty cargo.

Overview

Quick Details

Purpose: Logistics between cities Type: Semi-Trailer Material: Carbon Steel Certification: CCC / ISO9001

Size:13000*3000*1600mm Max Payload:60T

Place of Origin: Shandong, China (Mainland) Brand: Startrailer

Leaf spring: Leaf Spring 6 pcs Axle Brand: Fuwa/BPW Spare Wheel Bracket:2 pieces Kingpin:90mm

Suspension: leaf spring suspension or Air suspension colour: optional

Support leg: JOST brand D200T Landing Leg:28T load landing leg

Wheelbase:5100+1320+1320mm

Supply Ability

Supply Ability:300 Set/Sets per Month

Packaging & Delivery

Packaging Details: nude in shipment

Port: Any port of China

Lead Time :

20~25 Days After Deposit

Product Description

3 Axles 60 Ton Low Bed Semi Trailer Heavy Transport Trailers

Product parameter:

Dimension(Lx W x H)(mm) 13000*2800*1700
Curb Weight(KG) 7000
Loading Weight( KG) 40000
Total Wheight(KG) 47000
Departure Angle 16
Axle Brand FUWA 13TON Axle
Axle Number 3
Wheelbase(mm) 8580+1310+1310
Suspension system Mechanical suspension
Steel Spring 10/10/10
Frame The height of the beam is500mm, the upper plate is 18mm, down plate is 20mm, the middle plate is 10mm.according to the buyer’s requirement
Platform plate 5mm Diamond Plate
Tire Type and quantity 1200-20 12units
Traction Pin 50mm or 90mm
Spare Wheel Bracket Two pieces
Tool Box 1 Unit
Landing Leg 28T load landing leg
Brake system Dual Line braking system, none ABS.
Brake air chamber Six air chambers
Electrical system 24V,7 Pole plug
Tail lamp with turn signal, brake light & reflector, side lamp etc.
One set 6-core standard Cable.
Side Guard None
Painting Colour by customer’s requirement
Packing Polish with wax before shipping
Delivery way Transfer to China port, and carry by ro-ro ship, the freight cost depends on the volume.

3 Lines 6 Axles Pipe Transport Trailer 40-60T For Heavy Pipe Transport3 Lines 6 Axles Pipe Transport Trailer 40-60T For Heavy Pipe Transport

Our Advantage:

High-grade steel for semi-trailer

The steel we use is high-grade steel, and it contains niobium and 0.98‰ of titanium, which keeps the chassis very strong with high torsional stiffness and low dead weight. The main beams are the strongest in the market, allowing for more load capacity. We are proud to offer every customer 5-year warranty on the mainframe.

3 Lines 6 Axles Pipe Transport Trailer 40-60T For Heavy Pipe Transport

Designed for optimial load distribution

Our trailer is designed for optimal load distribution. Instead of two web reinforcement structure design, which is commonly used by other Chinese factories, we adopt the structure of width plate and stiffened plate reinforcement. As a result, our trailer has excellent torsional stiffness and is exceptionally stable when loaded.

3 Lines 6 Axles Pipe Transport Trailer 40-60T For Heavy Pipe Transport

FAQ

1. Q: Are you a manufacturer or trading company?

A: We are a manufacturer.

2. Q: What about the quality of your product?

A: "Quality is a priority." We always attach great importance to quality controlling from the very beginning.

3.Q: What payment do you accept?

A: T/T, L/C, Trade assurance;

4.Q: What is the MOQ of your products?

A: 1 set.
