Specifications
Brand Name :
Hope-Wish
Model Number :
HP-HX50-HTVC61023-41100
Place of Origin :
China
Certification :
CE, FCC, ROHS, ISO9001
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
50 units per month
Delivery Time :
60-180
Packaging Details :
wooden case
Tilt :
-45 ° ~ + 90 °
Sensor Type :
PTZ Thermal
Pan :
N × 360 ° Continuous Rotation
Temperature Range :
-40°C To +70°C
Resolution :
1920x1080
Minimum Focus Distance :
5-10KM
Detection Range :
5-10KM
Spectral Range :
7.5μm To 14μm
Description

Features:

  • 12mm~1000mm HD IR-Corrected Zoom Lens
  • 1280X1024 or 640X480 uncooled thermal imager
  • Thermal lens options available with up to 1100mm
  • Optional Laser Range Finder up to 10km
  • Rugged IP66 and -50 to +65 ℃
  • Many other customization available

Technical Parameters:

Image SensorUncooled Vox
Resolution640X512 pixels, 1280X1024 optional
Pixel Pitch12μm
Lens23-230mm23-300mm31~155mm
FocusMotorized Autofocus
Spectral RangeLWIR (7000-14000nm)
Thermal Sensitivity30mK
Image Display ModesWhite Hot, other color palettes available

HD Thermal Camera Options

Image SensorHigh Sensitivity Cooled InSb
Resolution640X512 pixels, 1280X1024 optional
Pixel Pitch15μm
Lens90~1100mm22~450mm30~660mm
FocusMotorized Autofocus
Spectral RangeMWIR (3000-5000nm)
Thermal Sensitivity25mK
Cooler Lifetime10000 hours rated MTBF

Others Specifications

Optional LRFLRF10LRF5LRF3
Extended Range10km5km3km
Wavelength1535nm
Precision±3m

Applications:

The Hope-Wish HP- Long Range Thermal CameraThermal Imaging Camera, originating from China, is an advanced imaging solution designed for a variety of critical application occasions and scenarios. Equipped with a high-resolution 1920x1080 sensor and PTZ Thermal sensor type, this Long Range Thermal CameraThermal Imaging Camera offers exceptional clarity and precision in thermal detection, making it ideal for long-distance surveillance and monitoring tasks.
One of the primary application occasions for the Hope-Wish HP- Long Range Thermal CameraThermal Imaging Camera is border security and perimeter protection. Its impressive minimum focus distance of 5-10KM allows security personnel to detect and identify potential threats from a significant distance, enhancing early warning capabilities and response times. This makes it invaluable for installations, critical infrastructure, and large industrial sites where long-range detection is essential.
In addition to security, this Long Range Thermal CameraThermal Imaging Camera is highly effective in search and rescue operations. The spectral range of 7.5μm to 14μm enables the detection of heat signatures in challenging environments, such as dense forests, mountainous terrain, or during nighttime operations. Rescue teams can rely on the Hope-Wish HP- to locate missing persons or stranded individuals quickly and accurately, even in adverse weather conditions.

Company:

Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.

Ultra Long-Range Multi-Sensor PTZ Camera Thermal Imaging Camera Featuring Minimum Focus Distance 5-10KM Ideal for Security MonitoringUltra Long-Range Multi-Sensor PTZ Camera Thermal Imaging Camera Featuring Minimum Focus Distance 5-10KM Ideal for Security Monitoring
Hope-Wish solutions cover the border/coastal defense, anti UAV, intelligent transportation, forest fire prevention, environmental protection, individual photoelectric equipment (handheld, helmet, gun aiming), marine and other industries. The products developed by the Hope-Wish, with their excellent performance, reliable quality and thoughtful after-sales service has been widely praised by users all over the world.
Ultra Long-Range Multi-Sensor PTZ Camera Thermal Imaging Camera Featuring Minimum Focus Distance 5-10KM Ideal for Security MonitoringUltra Long-Range Multi-Sensor PTZ Camera Thermal Imaging Camera Featuring Minimum Focus Distance 5-10KM Ideal for Security MonitoringUltra Long-Range Multi-Sensor PTZ Camera Thermal Imaging Camera Featuring Minimum Focus Distance 5-10KM Ideal for Security Monitoring
