IP65 SMD P6.67 Outdoor Led Screen Module For Animation Columns
IP65 SMD P6.67 Outdoor Led Screen Module For Animation Columns
IP65 SMD P6.67 Outdoor Led Screen Module For Animation Columns
IP65 SMD P6.67 Outdoor Led Screen Module For Animation Columns
IP65 SMD P6.67 Outdoor Led Screen Module For Animation Columns
IP65 SMD P6.67 Outdoor Led Screen Module For Animation Columns
IP65 SMD P6.67 Outdoor Led Screen Module For Animation Columns
IP65 SMD P6.67 Outdoor Led Screen Module For Animation Columns
Specifications
Cabinet Size :
960X960mm Or Customization
Resolution :
48x24
Cabinet Material :
Die-casting Aluminum Cabinet/ Standard Outdoor Waterproof Iron Cabinet
Model :
P6
Brightness :
4000~8000nits(Adjustable)
Scan :
1/6
Brand Name :
Longdaled
Model Number :
Outdoor P6
Certification :
CE / RoHs / FCC / CCC / ISO9001 / ISO14001
Place of Origin :
Shenzhen , China
MOQ :
1 Sqm
Price :
Price is Negotiable
Payment Terms :
T / T
Supply Ability :
5000sqm per month
Delivery Time :
15 - 18 days
Packaging Details :
Plywood case / Flight case
Refresh Rate :
3840Hz
Warranty :
3 Years
Description

Led Stage Backdrop Screen Aluminum Hanging LED Screen Truss Display Outdoor Events P6



Functions and Advantages :


1 . LED advertisements with strong visual impact , large size , dynamic effect and sound and picture integration

can comprehensively stimulate the audience's senses and effectively convey information to guide consumption ;


2 . Outdoor LED screens with wide coverage are generally installed in shopping malls and other areas with

concentrated pedestrian flow . Through frequent communication with user groups , consumers' strong desire to

buy is stimulated and brand awareness is improved ;


3 . Long release period outdoor LED advertisements can be played around the clock .

It is easier for the audience to see , can better guide the potential customer group , so that businesses with less

cost to achieve better publicity effect ;


4. Outdoor LED advertisements with low audience aversion can broadcast programs to more audiences in a real

and timely manner through live broadcasting technology .

Including special topics , columns , variety shows , animation , radio plays , TV plays , etc , rich in content ,

to avoid the advertising audience consciously and actively avoid the contact barriers .


IP65 SMD P6.67 Outdoor Led Screen Module For Animation Columns


Specifications :


Outdoor P6 LED Screen

Part I Technicial Parameters

Led Module Specification

NO.

Item

Specification

1

Pixel Pitch

6.67mm

2

Module Resolution

W48×H24dots

3

Module Size

320*160mm

4

Led Packing

 2727

5

IP Rate

65

6

IC

Constant current IC

7

LED composition

1R1G1B

Cabinet Specification

1

Cabinet Size

960*960mm

2

Module Qty

W3X H6 =18PCS

3

Physical Resolution

W144×H144dots

4

Power Consumption(MAX.)

800 W/m2

5

Power Consumption(AVE.)

240 W/m2

6

Cabinet Material

Die-casting Aluminum

/Standard Outdoor Waterproof Iron Cabinet

7

Physical Density

20736 dots/m2

8

Net Weight

45Kg

Screen Specification

1

Brightness

4000~8000cd/m2

2

Colors

16.7 trillion

3

Brightness Control

Software 256 level adjustable

4

Gray Level

14-16

5

View Distance

6～50m

6

Refresh Rate

3840Hz

7

Drive Mode

1/6s

8

Life Span

100,000h

9

MTBF

1000h

10

Control mode

Synchronous control or Asynchronous control

11

Frame Frequency

≥60Hz

12

Certification

CE/ROHS/FCC/CCC/ISO9001/ISO14001

13

Operation Temperature

-20℃ ～ +45℃

14

Operation Humidity

10%～95%




FAQ :


Question1 : How can I trust your LONGDA LED factory ?

Answer : Yes , when you talk with us now , we are here . We do led since 2009 , it is over 17 years .

In the past 13 years , we develop so well . Tomorrow and future , we will largely expand our LED market, you will see it .
Welcome to try our LED sample quality .
We do have 100% confidence in our LED product .

Question2 : If I need led very urgently , how fast can you finish the goods ?

Answer : How fast you want ? Three days ? One week ? Definite shipping date ?
We produce LED everyday . We have some led modules in stock .
Put the most urgent and important order at the first place .
You are important to us . Surely to establish first-time good relationship .
We do must finish it at FAST ROCKET TIME .

Question3 : Is it easy to install this led display ?

Answer : If you are new to LED , we will help you to know led from ZERO to Professional .
We have installation manual book and professional engineering team to guide you .
To help you better understand LED is to make us get your earlier trust .
If you knew LED before , we can learn from each other .
We could be Future Shaking - hands Partners .
Our engineering team remote help is ready for you 24 hours .
