Specifications
Cabinet Material :
Support Customization
Cabinet Size :
Support Customization
Resolution :
128x64
Brand Name :
Longdaled
Model Number :
F - P2.5
Certification :
CE / RoHs / FCC / CCC / ISO9001 / ISO14001
Place of Origin :
Shenzhen , China
MOQ :
1 Sqm
Price :
Price is Negotiable
Payment Terms :
T / T
Supply Ability :
5000sqm per month
Delivery Time :
15 - 18 days
Packaging Details :
Plywood case / Flight case
Scan :
1/32
Warranty :
3 Years
Refresh Rate :
3840Hz
Model :
P2.5
Brightness :
600-800nits
Description

Led Stage Backdrop Screen RGB LED Stage Backdrop Flexible P2.5 LED Screen For Sale



Advantages :


Compared with the traditional PCB material , the flexible panel has high compressive and distortion resistance ,

which can better solve the problems of " beating around the bush , corner by corner " installation difficulties .
LED flexible module installation mode is mainly magnetic column suction, installation is convenient and quick ,

but also easy to shape , and box connection line is fast to joint connection , firm and reliable, for you to save the

" prehistory force " . Compared with regular size group, it saves more time and is easier to install.


Easy Maintenance IP43 Led Stage Backdrop Screen Flexible P2.5 Indoor Led Display


Technical parameters :


P2.5 Flexible Video LED Display Screen

S/N

Item

Technical Parameters

LED Parameters

1

Item Name

LED Type

Brightness

Wave Length

H/V Visual Angle

2

Red LED

SMD1515

540-702mcd

620-625nm

160º/160º

3

Green LED

SMD1515

1200-1300mcd

519-522nm

160º/160º

4

Blue LED

SMD1515

200-260mcd

462-465nm

160º/160º

Module Specification

1

Pixel Pitch

2.5mm

2

Pixel Configuration

1R1G1B

3

Module Resolution

128 x 64 pixels

4

Module Pixles

8192 pixels

5

Module Size

320mm X 160mm

Cabinet Specification

1

Cabinet Size

Customized

6

Cabinet Materials

Die Casting Aluminum Cabinet for Rental Purpose

8

Packaging

Flight case/Wooden case

9

Fly Case Size

105*65*65CM ( one case for six cabinets )/ 85kg

Whole Screen Specification

1

Screen Brightness

600-800cd/m²

3

Best Viewing Distance

2.5m - 40m

4

Max. Power Consumption

358W/m²

5

Average Power Consumption

146W/m²

6

Gray Level

65536 levels ( 16 bit )

9

Refresh Frequency

3840Hz

11

Screen Life-span

≥100,000 hours

12

MTBF

≥5,000 hours

17

Screen Plainness

<±1mm

18

Power Supply Mode

AC220±10% 50Hz/AC110±10% 60Hz

21

Control System

Linsn, Novastar or as you required.

22

Display Content

Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc.


FAQ :


1 : What is the warranty of your led display ?
A : We offer 2 - 3 years warranty and more than 100000 hours screen life span .

2 : What is your payment term ? How long it takes to delivery ?
A : We usually accapt the T / T or L / C , both of them will at least 30 % deposit in advance ,

and the rest of 70 % will paid before delivery . The lead time is usually 20 day .

3 : How can you ensure the led display product quality ?
A : Before shippment , all the screens have aging test and then we also have waterproof test and shake test ,

ensure products can transportation safety and normal use .

4 : What is your pre - sale and post - sale service ?
A : For pre - sale service , we have professional sales team and technical team ,

who are willing to answer your question within 24 hours .
For post - sale service , we will instruct you how to installation , how to use , how to change the broken moudles ,

and we can also send the technicals to your country , in general , our led display will not have a big problem ,

you can rest assured to buy .


Easy Maintenance IP43 Led Stage Backdrop Screen Flexible P2.5 Indoor Led Display


Company other products :


Indoor fixed LED screen: P2.5, P3, P4, P5, P6, P8, P10
Indoor rental LED screen: P3, P3.9, P4, P4.8, P5, P6
Outdoor fixed LED screen: P5, P6, P8, P10
Outdoor rental LED screen: P3.9, P4.8, P5, P6, P6.25, P8, P10
Small pitch LED screen: P1.25 , P1.538 , P1.56 , P1.667 , P1.86 , P1.875 , P1.9 , P2
Front service maintenance LED screen: P6.67, P8, P10
Stadium perimeter LED screen: P8, P10
LED poster player: P2.5, P3, P4, P5, P6, P8, P10
