Double Head Steel Keel Profile Metal Stud and Track Roll Forming Machine
Double Head Steel Keel Profile Metal Stud and Track Roll Forming Machine
Specifications
Brand Name :
LIMING
Model Number :
HBLM-ST016
Certification :
BV、ISO、SGS
Place of Origin :
Hebei China
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T, L/C, D/A, D/P
Supply Ability :
80set/Year
Delivery Time :
35 work days
Packaging Details :
Nude、Anti-dust film, Anti-rust cloth
Name :
double line c channel steel roll forming machine
Type :
Tile Forming Machine
Usage :
roof
Tile Type :
Steel
Applicable Industries :
Building Material Shops
Condition :
New
Roller material :
High grade 45# forged steel, surface hard chromium plating
Warranty of core components :
18 month
Main motor power :
5.5KW
Electric Control System :
Whole Machine Adopts PLC
Description

Machine With Multiple Models Double Line C Stud Track Steel Roll Forming Machine
What is the Double Line C Stud track Steel Roll Forming Machine?
C Stud track Steel Roll Forming Machine is widely used around the world. This galvanized steel C Stud track Steel Roll Forming Machine have two forming lines, but they have seperated control systems, this kind of double line light gauge keel stud track c channel steel roll forming machine will save the space for the factory. And the products this machine produced is mainly used for the drywall and the ceiling structure. As a basic material, c channel is widely used for many aspects as assistant supporters.

Double Line C Stud Track Steel Roll Forming Machine:

Name double line c channel steel roll forming machine
Raw material Galvanized
Thickness 0.3-0.8mm
Inner Diameter 450-550mm
Max Coil width 300mm
Capacity 1.5T
Forming steps 10 rollers 10rollers
Shaft diameter 40mm
Design type Memorial arch
roller material GCr12MoV steel
shaft material 45# steel
Work speed 0-25m/min
Transport By gear
Power of main machine 3kw
Type of cutting Hydraulic
Cutting tolerance ±1mm
Cutter Gcr12
Hydraulic oil 46#
Hydraulic power 3kw
PLC Brand Delta(as your requirement)
