Floor Standing Outdoor Parking Kiosk IP65 Weatherproof Self Service Parking Payment Kiosk



Parking Payment Kiosk Description


This outdoor multifunction parking self‑service kiosk is specially engineered for exposed parking lot environments, featuring IP65 moisture‑proof, dust‑proof and anti‑corrosion cabinet design to cope with rain, humidity, high temperature and harsh outdoor weather. It supports bill and coin cash payment, QR code scanning, parking receipt printing, license plate query and parking fee settlement. 24‑hour unattended operation greatly cuts onsite manpower cost. Industrial hardware runs stable long‑term; compatible with Android / Linux / Windows OS, providing complete SDK & API for docking with parking management system. Floor‑standing structure is easy for onsite installation and deployment for open‑air parking areas, commercial plazas, airport and hospital parking lots.


Pay Station For Parking Kiosk Outdoor Payment Kiosk


Floor Standing Outdoor Parking Kiosk IP65 Weatherproof Self Service Parking Payment Kiosk






QR code


Floor Standing Outdoor Parking Kiosk IP65 Weatherproof Self Service Parking Payment Kiosk


Credit card

Floor Standing Outdoor Parking Kiosk IP65 Weatherproof Self Service Parking Payment Kiosk


Ticket printer

Floor Standing Outdoor Parking Kiosk IP65 Weatherproof Self Service Parking Payment Kiosk


Microphone

Floor Standing Outdoor Parking Kiosk IP65 Weatherproof Self Service Parking Payment Kiosk


Cash acceptor


Floor Standing Outdoor Parking Kiosk IP65 Weatherproof Self Service Parking Payment Kiosk

HD camera

Floor Standing Outdoor Parking Kiosk IP65 Weatherproof Self Service Parking Payment Kiosk

RFID reader

Floor Standing Outdoor Parking Kiosk IP65 Weatherproof Self Service Parking Payment Kiosk

Intercom




Parking Self-service Payment Machine Support Touch Bill and Coin Payment Receipt Printer

LKS Aims To Create An Integrated Technology-Based Lifestyle

LKS Pay Station Parking Support :

High‑Brightness Sunlight‑Readable Touch Screen: 15.6 / 21.5 inch industrial high‑bright LCD touch display, clear view under direct sunlight; capacitive / infrared touch optional, multi‑language UI support.

QR & Barcode Scan Function Fast 1D/2D scanner, read parking ticket barcode, payment QR‑code, support license‑plate‑based parking fee query.

Multiple Payment Modes Optional Besides bill & coin cash payment, optional NFC contactless payment, EMV card reader, RFID card for integrated payment experience.


Custom Peripherals:
LKS Pay Station Parking Kiosk Outdoor Kiosk:

Personalized Terminal Function Customization,

A Variety Of Functional Modules can be Combined;

All-Round Personalized Customization.

Details Shown of Pay Station Parking Kiosk

The functional modules are integrated and embedded

to create ingenious pay station parking in-lane

entry kiosk.

The design of the whole machine is ergonomic and

convenient for users to operate.

Hardware Components Included:

Camera

Touch display

Ticket printer

Credit card reader

Barcode scanner

RFID card reader

Industrial grade PC

Cash payment ( optional)

Power supply

LKS also accept customized design of pay station parking kiosk. We have professional design teams and R&D teams to meet different customers' requirements with batch orders.




Operating System Supported


Pay Station Parking Kiosk can support

android, Windows, or Linux System

Application Scenarios of Pay Station Parking Kiosk

‑ Open‑air commercial parking lots, shopping mall parking zones
‑ Airport, railway station, hospital outdoor car parks
‑ Government building, industrial park, community public parking area
‑ Highway service area, tourist attraction parking lots
‑ Integrated with parking barrier gate & parking management software system

Work Process of Pay Station Parking Kiosk

Key Benefits of Parking Automation


Main Hardware Components in Pay Station Parking Kiosk

NO.

Category

Module

Specification

1


Touch Display

LCD Display

15inch high brightness lcd display

Capacitive Touch Screen

15inch capacitive touch screen
2 Host Industrial Host Windows PC or Android board
3 Video Camera HD Camera Industrial HD camera with face recognition and live detection.
4 Printing Ticket Printer Printable width: 50mm-80mm, with automatic cutter; Can place lengthened 80mm thermal paper, support paper-lacking alarm interface.
5 Cash Payment

Banknotes

( optional)

Support cash receive and change
6 Barcode Payment Barcode Scanner Support online barcode payment like Applepay, Samsung Pay, Googlepay, WechatPay, Alipay, etc.
7 Card Payment

Credit Card Reader / POS


Ingenico / Verifone/Worldline brand Credit Card Reader/ POS ( Space preparation, provided by customer side)

8 Help Intercom Support emergency calls
9 Sound/Lights Control Speakers Audio amplifier,2x5W speaker
Lights Indicator light control board (communicating with computer and providing interface), there are indicator lights at room card dispensing, bank card, receipt slots, etc.

Successful Cases of Pay Station Parking Kiosk Outdoor Kiosk

LKS design, produce and deploy more than 500 units Pay Station Parking Kiosk

for one of the biggest parking lots operation company in US,UK and Europe market.

About LKS

Shenzhen Lean Kiosk Systems Co., Ltd. (Hereinafter referred to as LKS) was established on May 6th, 2011. We are devoting into providing the unmanned intelligent service kiosk products research, production, development, sales and after-sales service worldwide. Our products and services cover the parking lots,hotels,cinema, medical,social security, retail, shopping malls and other fields.

LKS belongs to the “National High-Tech Enterprises”, “National Specialized and Sophisticated Enterprises”.

We have obtained a number of Independent Intellectual Property Rights, Patents, Trademarks, Software Copyrights. Currently, we have 12 Design Patents, 6 Invention Patents, 16 Computer Software Copyright Registration Measures, 12 Utility Models, 26 Trademarks, 5 CCC certificates and 10 CE certificates.

LKS provides intelligent terminal solutions to global top 500 companies such as Walmart, ICBC(Industrial and Commercial Bank of China), Sinopec, Foxconn, etc. Meanwhile, LKS occupies more than 70% of the domestic cinema market share in the ticketing industry and more than 30% of the foreign parking pay station market share in the parking station industry.

LKS provide customize design, development and production solutions for overseas customers in Europe, America, Middle East, South-east Asia and other countries and have provided high-value and system-stable products for customers over 100 countries around the world.

In 2023, LKS purchased land in Dongyuan town, Heyuan city, Guangdong province, which is 2 to3 hours away from its headquarter in Shenzhen city by car. We are planning to build a leading self-service terminal and related surrounding intelligent terminal production base of the whole industrial chain, hoping that base built in 2025 can provide high-quality, short delivery cycle and cost-effective products for global customers.

The mission of LKS is to make business services easier.We will endeavour to carry out the mission and provide trustworthy services for global customers.

Product Certifications for the Pay Station Parking Kiosk Outdoor Kiosk

LKS Development History


The mission of LKS is to make business services easier.

LKS will endeavour to carry outthe mission to provide trustworthy services for global customers.


Production Process of Pay Station Parking Kiosk Outdoor Kiosk

Pay Station Parking Kiosk Workshop & Sales Team

FAQ of Pay Station Parking Kiosk Outdoor Kiosk
1. Are You A Manufacturing or Trading Company?
We are an OEM/ODM kiosk manufacturer.


2. How To Ship the Pay Station Parking Kiosk?
Air and sea shipping are optional, and sea shipping is recommended for bulk orders.

All kiosks should be kept vertically and cannot put down during transportation process.


3. What Payment Methods Does Your Company Accept?
We accept most payment methods, but mainly accept T/T. L/C, Western Union, PayPal and MoneyGram.


4. How Long is the Delivery Time of the Parking Payment Kiosk ?
It depends on the order quantity, about 5 weeks for samples and about 4 weeks for less than 100 units.


5. What Is The Warranty Period of Your Outdoor Parking Kiosk?
12 months for hardware components since shipment date.


6. Can You Customize The Parking Payment Kiosk?
Yes, we always customize the product according to yourrequirements. Including redesigning the kiosk

appearance, printing your company logo, choosing specific colors, etc. OEM or ODM is available.


7.What is the MOQ of Parking Payment Kiosk?
The MOQ is 10 units, we accept sample unit for testing before batch order.
