H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler
H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler
H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler
H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler
H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler
H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler
H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler
H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler
H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler
H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler
H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler
H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler
Specifications
Brand Name :
KXD
Model Number :
KXD-SS78
Certification :
CE、ISO、SGS
Place of Origin :
Qingdao，China
MOQ :
1 set
Price :
USD 20,000.00-100,000.00
Payment Terms :
L/C,T/T
Supply Ability :
10000 Houses/Year
Delivery Time :
25 days
Packaging Details :
steel pallet
Beam :
H Section Steel
Maintenance :
Low Maintenance
Color :
Customized
Connections :
Bolts Connection
Type Of Connection :
Bolted
Insulation :
Available
Surface Coat :
Galvanized
Description
H Type New Design Poultry Farm Cage Design Manual Chicken Layer Cage

The new cage is developed according to the market demand, featuring compact structure, innovative design, and excellent ventilation. It is an ideal choice for all medium and small scale farmers.

H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler
4 Tiers H Frame Broiler Cage Specifications
Product Name 4 tier H type chicken broiler cage
Model 9LRC-4272
Material Galvanized wire
Tiers 4 Tiers
One Unit Size 1200mm × 1723mm × 2655mm (L×W×H)
Unit Capacity 136 birds
One Cell Size 1200mm × 700mm × 460mm (L×W×H)
Cell Capacity 17 birds per cell
Life Span 15-20 years
Living Space/Bird 494 cm²
Key Advantages
  • The cage frame is formed with hot galvanized plate using CNC machines, ensuring accurate assembly that improves structural stability and prevents manure belt run-off.
  • The feeding trough uses hot galvanized material, which is stronger than PVC. The V-shaped bottom design is more suitable for birds' eating habits, distributes feed more uniformly, prevents moldy feed, ensures fresh feed consumption, and reduces waste.
  • Enhanced lower connector with stamped design provides convenient observation and bird access. Push-in style doors offer easy operation.
  • Driving rolls feature integrated rubber coating that increases friction, solves manure belt off-tracking problems, extends belt service life. Includes one scraper at the manure belt end and two secondary scrapers below the returning belt for thorough manure clearing.
  • Each tier's manure is conveyed to the end via manure belt, falls onto cross manure belt, and is finally conveyed to a manure truck outside the poultry house via elevating manure belt. Periodic manure clearing improves rearing environment and reduces disease occurrence.
H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler
Complete Cage System Includes
  • Cage and frame
  • Fully automatic drinking system
  • Fully automatic feeding system
  • Fully automatic manure removing system
  • Fully automatic lighting system
  • Fully automatic environment and electric controller system
H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler H Section Steel Galvanized 4 Tiers Poultry Farm Cage for Chicken Layer and Broiler
