Specifications
Brand Name :
KVOU
Model Number :
KVOU-372 L
Place of Origin :
Jiangxi
Certification :
GB/T 36276 UL CE UN38.3 MSDS RoHS
MOQ :
1 set
Packaging Details :
1. Regular package inner box inside , outside is strong safe foam battery Packing carton box 2. Be customized following customers in request
Delivery Time :
7-15working days
Payment Terms :
T/T, D/P D/A
Supply Ability :
5000 unit per month
IP Rating :
IP55
Communication Port :
RS485, CAN
Nominal Voltage :
DC 1331.2(1000~1500V)
Battery Type :
LiFePO4
Dimension(W*D*H) :
1300*1300*2300 Mm
Charge/Discharge C-rate :
≤0.5C
Protection Class :
IP55
Grid connection :
Off Grid, Hybrid Grid, On Grid
Description

Product Description:

1300*1300*2300 Mm Industrial-Commercial-Energy-Storage With Gas Water Firefighting

Industrial and Commercial Energy Storage is the ideal smart grid industrial battery storage solution for solar applications as well as a reliable Lithium-ion battery storage for global businesses. This energy storage cabinet offers utility-scale solar battery storage solutions in a sleek and compact design. The Industrial and Commercial Energy Storage Cabinets are designed to operate in a wide range of temperatures, from -20℃ to 55℃, and provide a nominal voltage of DC 1331.2 (1000~1500V) and a rated frequency of 50/60 Hz. The cabinets are 1300mm in length, 1300mm in width and 2300mm in height, making them suitable for various industrial and commercial applications.

1300*1300*2300 Mm Industrial and Commercial Energy Storage With Gas Water Firefighting1300*1300*2300 Mm Industrial and Commercial Energy Storage With Gas Water Firefighting1300*1300*2300 Mm Industrial and Commercial Energy Storage With Gas Water Firefighting1300*1300*2300 Mm Industrial and Commercial Energy Storage With Gas Water Firefighting1300*1300*2300 Mm Industrial and Commercial Energy Storage With Gas Water Firefighting1300*1300*2300 Mm Industrial and Commercial Energy Storage With Gas Water Firefighting1300*1300*2300 Mm Industrial and Commercial Energy Storage With Gas Water Firefighting

Features:

  • Product Name: Industrial and Commercial Energy Storage
  • Battery Type: LiFePO4
  • Cooling: Liquid Cooling
  • Working Temp: -20℃~55℃
  • Nominal Voltage: DC 1331.2(1000~1500V)
  • Protection Class: IP55
  • Key Features: Battery Energy Storage System, Next-generation Commercial Battery Systems, Industrial-Power-Storage-System

Technical Parameters:

Parameter Value
Charge/Discharge C-rate ≤0.5C
Fire protection Gas + Water Firefighting
Rated Frequency 50/60 Hz
Capacity 372 KWh
Communication Port RS485, CAN
Protection Class IP55
Grid connection Off Grid, Hybrid Grid, On Grid
Nominal Voltage DC 1331.2(1000~1500V)
IP Rating IP55
Temp Control Mode Liquid Cooling

VR-PB 215 F
VR-PB 372 L
DC Side
Cell Model
LFP 280Ah
LFP 280Ah
Nominal Voltage
3.2V
3.2V
Max. Charging Current
140A
280A
Maximum Discharge Current
140A
280A
Maximum Voltage
3.65V
3.65V
Minimum Voltage
2.5V
2.5V
Cluster Charge Termination Voltage
3.6V
3.6V
Cluster Discharge Termination Voltage
2.8V
2.8V
Maximum Operating Temperature-Charging
0~55℃
0℃～55℃
Maximum Operating Temperature-Discharge
-30~55℃
-30~55℃
Module Grouping Method
1P16S
1P52S
Module Nominal Voltage
51.2V
166.4V
Module Nominal Energy
14.336kWh
46.592kWh
Equalization Method
Passivity
Passivity
Battery System Grouping Method
1P240S
1P416S
Dc Side Nominal Power
215kWh
372kWh
Dc Side Nominal Voltage
768V
1331V
Dc Side Voltage Range
600~876V
1000~1500V
Charge/Discharge Multiplier
0.5C
0.5C/1.0C
Integrated Efficiency
≥94%
≥94%
AC Side
Rated Power
100kW
/
Rated Output Voltage
400V
/
Total Harmonic Distortion Rate Of Current
≤3%(Rated Power)
/
Dc Component
≤0.5%
/
Power Factor
≥0.99(Rated Power)
/
Rated Frequency
50/60Hz
/
Isolation Method
/
/
System
Dimension(W*D*H)
1600mm*1100mm*2360mm
1300*1300*2300mm
Protection Level
IP54
IP55
Cooling
Air Cooling
Liquid Cooling
Fire protection
Aerosol + Water firefighting
Gas + Water firefighting
Communication Interface
Ethernet/CAN/RS485
Ethernet/CAN/RS485
Operating Temperature Range
-20~55℃
-20~55℃
Operating Humidity Range
≤95%
≤95%
Anti-Salt Spray Grade
C3(C4/C5 optional)
C3(C4/C5 optional)
Altitude
≤2000m
≤2000m
Weight
＜3.2T
＜3.5T

Applications:

Industrial and Commercial Energy Storage

KVOU is proud to offer the KVOU-372 L model, an industrial-grade energy storage system with advanced future-proof solar battery storage technologies. This energy storage system is designed for solar applications, providing energy storage optimization with superior performance and reliability. The KVOU-372 L is also suitable for commercial energy storage applications, providing a comprehensive energy storage solution for businesses.

This energy storage system is certified to GB/T 36276 UL CE UN38.3 MSDS RoHS standards, guaranteeing maximum safety and reliability. The KVOU-372 L model is capable of providing 372 KWh capacity and is rated IP55 for protection against dust and water. It is available in a 1300*1300*2300 dimension and supports both off grid, hybrid grid, and on grid connections. The system also supports a charge/discharge C-rate of ≤0.5C.

The KVOU-372 L model is available with a minimum order quantity of one set and is packed in a regular package inner box inside a strong safe foam and battery packing carton box. Delivery is typically within 7-15 working days, and payment terms include T/T, D/P D/A. KVOU is able to supply up to 5000 units per month.

Customization:

Industrial and Commercial Energy Storage

Brand Name: KVOU

Model Number: KVOU-372 L

Place of Origin: Jiangxi

Certification: GB/T 36276 UL CE UN38.3 MSDS RoHS

Minimum Order Quantity: 1 set

Packaging Details: 1. Regular package inner box inside , outside is strong safe foam battery Packing carton box 2. Be customized following customers in request

Delivery Time: 7-15working days

Payment Terms: T/T, D/P D/A

Supply Ability: 5000 unit per month

Charge/Discharge C-rate: ≤0.5C

Product name: Industrial And Commercial Energy Storage Cabinets

Dimension (L*W*H): 1300*1300*2300

Temp Control Mode: Liquid Cooling

Rated Frequency: 50/60 Hz

KVOU offers commercial-energy-storage-systems, large-scale solar battery systems for industries, and future-proof solar battery storage technologies. Our industrial and commercial energy storage cabinets are certified with GB/T 36276 UL CE UN38.3 MSDS RoHS and are available in a minimum order quantity of 1 set. We provide regular package inner box inside , outside is strong safe foam battery Packing carton box and can customize our services following customer requests. Our delivery time is 7-15 working days and we can supply up to 5000 units per month. The energy storage cabinets have a Charge/Discharge C-rate of ≤0.5C and dimension of 1300*1300*2300. The temperature control mode is liquid cooling and the Rated Frequency is 50/60 Hz.

Support and Services:

Technical Support and Services for Industrial and Commercial Energy Storage
  • On-site technical support for installations, repairs and maintenance
  • 24/7 phone and online support
  • Regular remote monitoring and diagnostics
  • Software updates and upgrades
  • Performance optimization and troubleshooting
  • Warranty and extended services
  • Data analysis and reporting
  • Energy management consultation
