Specifications
Brand Name :
KVOU
Model Number :
48V50AH
Certification :
UL1973/IEC62619/UN38.3
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
D/A, D/P, T/T
Supply Ability :
5000 unit per month
Delivery Time :
7-15working days
Packaging Details :
Wooden box and Carton
Capacity(Ah) :
50
Series(PCS) :
15
Standard Voltage(Vdc) :
48
Standard Charge Current (A) :
25
Communication :
RS485/CAN
Protection Class :
IP54
Operation Life (Years) :
10/20(according to the cycles)
Operation Cycle Life :
7000 @1C
Description

Battery Pack Series Lifepo4 Cell 48V 50Ah Energy Battery System

Our rechargeable standard batteries are available off-the-shelf, without any development costs. This leads to reduced battery development efforts for mobile applications.

Naturally, our lithium-ion standard battery packs fulfil all the market-relevant safety standards as well as the worldwide national approvals. These aspects combined with the off-the-shelf availability reduce the overall development costs and allow your new device to reach profitability much earlier.

We also utilize lithium-ion cells with the highest energy density, maximized discharge current, and the utmost safety levels.

Specification

Parameter
KY-48V50AH
Cell Technology
Li-ion(LFP)
Capacity(Ah)
50
Series(PCS)
15
Standard Voltage(Vdc)
48
Max Voltage (Vdc)
54.75
Standard Charge Current (A)
25
Max Charge Current (A)
30
Max charge Voltage (Vdc)
53.25
Standard Discharge Current (A)
25
Max Discharge Current (A)
30
Communication
RS485/CAN
Protection Class
IP54
Weight(KG)
31
Operation Life (Years)
10/20(according to the cycles)
Operation Cycle Life
7000 @1C
Operation Temperature (℃)
0~50
Storage Temperature (℃)
-20~60℃ ≤85%R.H
Humidity
<45%
Altitude (m)
<2000
Dimensions (W*D*H)(mm)
532*235*230
Product Certificate
IEC62619,UN38.3

Series 48V 50Ah Lifepo4 Battery Pack Cell Energy Battery System

FAQ

Q: What are stacked batteries?

A: Significant attention has been drawn to modular/stacking battery systems that enable several batteries to concurrently power multiple electrical gadgets. These batteries are a sophisticated energy technology that may be linked in parallel or series to improve capacity or voltage.

Q: What is the most efficient battery storage?

A: Lithium-ion solar batteries last the longest. They have the best storage capacity and record the highest depth of discharge levels. They cost more than other types, such as lead-acid batteries, but you'll need to replace them less frequently.

Q: Is a modular battery rechargeable?

A: Modular lithium-ion batteries are a form of rechargeable battery that stores energy in a network of individual cells. This allows for greater adaptability and simpler production than competing battery technologies.

Q: How efficient is home battery storage?

A: It's a good question and the answer is, it depends on your lifestyle, energy usage and size of PV system. On average, a household would utilise 35 - 50% of the generated system without a battery. This would rise if you are in the house for much of the day. However, battery storage can raise this to 80%.
