This 60V 45Ah LiFePO4 battery is specifically designed for electric tricycles, light cargo trikes, family commuters, and low-speed electric vehicles. With approximately 2.7-2.8kWh energy storage, it delivers 60-80 km real-world range per charge and supports 800-1500W motors. The built-in smart BMS ensures safety and longevity—3,000-4,000+ cycles with 5-8 years of service life. Weighing about 60% less than lead-acid batteries of equivalent capacity, it's the best choice for budget-conscious tricycle upgrades.
Key Selling Points
- Economical & Practical Range – 45Ah capacity delivers 60-80 km real-world range (with 1000W motor under load), perfect for daily commuting, light cargo, and rural use without frequent recharging.
- Strong Power Output – 60V platform with 67.5-200A peak current, supports 800-1500W motors, superior climbing and load capacity compared to 48V systems.
- 3,000-4,000+ Ultra-Long Cycle Life – LiFePO4 cells last 3-5+ times longer than lead-acid, significantly reducing long-term ownership costs.
- Lightweight & Portable Design – Weighs only ~40% of equivalent lead-acid batteries (~17-18kg), dramatically reducing vehicle weight, improving payload and energy efficiency, and easy for one person to carry and install.
- Smart BMS Full Protection – Over-charge, over-discharge, over-current, short-circuit, and over-temperature protection with real-time voltage, current, and temperature monitoring.
- Wide Temperature Operation – Discharge from -20℃ to 60℃, charge from 0℃ to 45℃, suitable for various extreme climates.
Technical Specifications
| Parameter |
Value |
| Battery Chemistry |
LiFePO₄ (Lithium Iron Phosphate) |
| Nominal Voltage |
60V / 60.8V |
| Nominal Capacity |
45Ah |
| Total Energy |
2.7 – 2.8 kWh (2,736Wh approx.) |
| Cycle Life (80% DoD) |
≥3,000 – 4,000 cycles |
| Weight |
17 – 18.5 kg |
| Dimensions (L*W*H) |
420*240*210 mm (Customizable) |
| Max. Continuous Discharge Current |
30A – 45A |
| Peak Discharge Current |
67.5A – 200A (≤30s) |
| Max. Charge Current |
10A – 22.5A |
| Charge Cut-off Voltage |
71.4V |
| Discharge Cut-off Voltage |
47.5V – 48V |
| Operating Voltage Range |
47.5V – 69.35V |
| Charge Temperature |
0℃ ~ 45℃ |
| Discharge Temperature |
-20℃ ~ 60℃ |
| Cell Configuration |
3P19S / 17S1P |
| Ingress Protection |
IP65 – IP67 |
| Communication (Optional) |
CAN, RS485, Bluetooth, 4G |
| Certification |
CE, UN38.3, MSDS, ISO9001, UL (Optional) |

Applications
- Family Commuter Tricycles – Daily commuting, school runs, grocery shopping
- Light Cargo Tricycles – Small goods transport, last-mile delivery
- Rural/Township Commuting – Short-distance travel, agricultural supply transport
- Municipal Sanitation Tricycles – Waste collection, street cleaning
- Sightseeing / Golf Carts – Low-speed tour vehicles
- Electric Motorcycles / E-Bikes – Two-wheeler power upgrades


FAQ
-
Q1: Is this 60V 58Ah battery suitable for my electric tricycle?
A1: Yes, it fits most 60V electric tricycle systems. Please confirm your vehicle voltage before purchase to avoid incompatibility.
-
Q2: What is the cycle life of this battery?
A2: It can support more than 1500 charge-discharge cycles. Under normal use, it can meet long-term use needs and greatly reduce the replacement frequency.
-
Q3: Does the battery come with BMS protection?
A3: Yes, built-in smart BMS provides full safety protection against overcharge, over-discharge, over-current and short circuit.
-
Q4: What is the charging time?
A4: With a standard charger, it takes about 6-8 hours to fully charge; if using a fast charger, the charging time can be appropriately shortened (subject to charger parameters).
-
Q5: Can I customize the size or connector of the battery?
A5: Yes, we accept customized dimensions, connector types and wiring methods, which can be personalized according to your specific needs.
-
Q6: What is the operating temperature range of the battery?
A6: It works stably from -20℃ to 60℃, which can work stably under different climate conditions such as cold and hot, suitable for use in different regions.
-
Q7: What is the weight of the battery?
A7: It is the weight of the standard version. The specific weight can be adjusted according to customized needs. For detailed weight parameters, please contact customer service for consultation.
