Custom 51.2V LiFePO4 Forklift Battery 304Ah 412Ah 560Ah with Smart BMS
Custom 51.2V LiFePO4 Forklift Battery 304Ah 412Ah 560Ah with Smart BMS
Custom 51.2V LiFePO4 Forklift Battery 304Ah 412Ah 560Ah with Smart BMS
Custom 51.2V LiFePO4 Forklift Battery 304Ah 412Ah 560Ah with Smart BMS
Custom 51.2V LiFePO4 Forklift Battery 304Ah 412Ah 560Ah with Smart BMS
Custom 51.2V LiFePO4 Forklift Battery 304Ah 412Ah 560Ah with Smart BMS
Custom 51.2V LiFePO4 Forklift Battery 304Ah 412Ah 560Ah with Smart BMS
Custom 51.2V LiFePO4 Forklift Battery 304Ah 412Ah 560Ah with Smart BMS
Specifications
MOQ :
2 Packs
Packaging Details :
Each battery is packed in a protective PE bag with foam cushioning and a strong export carton. Wooden cases or pallets are available for bulk orders.
Battery Management System :
Built-in Smart BMS
Customization :
Capacity, Dimensions, Weight, Connector, Protocol and Enclosure
Price :
Negotiable
Available Capacity :
304Ah, 412Ah and 560Ah
Certification :
UN38.3, MSDS, CE, IEC 62619
Model Number :
CLF-FLT-51V304-560Ah
Communication :
CAN and RS485 Optional
Place of Origin :
China
Application :
Forklift, Pallet Truck, Stacker and Material Handling Equipment
Supply Ability :
300 Packs per Month
Nominal Voltage :
51.2V
Battery Chemistry :
LiFePO4 / Lithium Iron Phosphate
Available Energy :
15564.8Wh, 21094.4Wh and 28672Wh
Fleet Management :
GPS Tracking Optional
Delivery Time :
25–35 Working Days
System Voltage :
48V
Brand Name :
Chalongfly
Wireless Monitoring :
Bluetooth Optional
Product Type :
LiFePO4 Forklift Battery
Description

Custom 51.2V LiFePO4 Forklift Battery Series

Industrial lithium forklift batteries available in 304Ah, 412Ah and 560Ah configurations with smart BMS, fast charging and flexible OEM/ODM customization.

Product Overview

The Chalongfly 51.2V LiFePO4 forklift battery series is designed for electric forklifts, pallet trucks, stackers, reach trucks and other industrial material handling equipment.

Available capacities include 304Ah, 412Ah and 560Ah, allowing the battery system to be selected according to daily operating hours, load conditions, available battery compartment space and charging schedule.

Each battery integrates lithium iron phosphate cells, a smart battery management system and a heavy-duty steel enclosure. Battery dimensions, service weight, connector, cable harness, communication protocol, monitoring functions and charger can be customized for different forklift models.

Available Battery Configurations

System Voltage Nominal Voltage Capacity Nominal Energy
48V 51.2V 304Ah 15564.8Wh
48V 51.2V 412Ah 21094.4Wh
48V 51.2V 560Ah 28672Wh

Battery dimensions, weight, current rating and connector configuration are customized according to the forklift model and operating requirements.

Main Technical Features

Product Model CLF-FLT-51V304-560Ah
Battery Chemistry LiFePO4 / Lithium Iron Phosphate
Battery Management System Built-in Smart BMS
Communication CAN and RS485 Optional
Wireless Monitoring Bluetooth Optional
Fleet Management GPS Tracking Optional
Charging Method CC/CV Fast Charging
Opportunity Charging Supported
Enclosure Customized Heavy-Duty Steel Enclosure
Low-Temperature Solution Charging Protection and Heating Optional
Maintenance Maintenance-Free

Key Product Advantages

Three Capacity Options

Select 304Ah, 412Ah or 560Ah according to operating time, forklift load, available installation space and charging schedule.

Fast and Opportunity Charging

The battery can be recharged during work breaks and shift changes, helping reduce equipment downtime and unnecessary battery replacement.

Smart Battery Management

The integrated BMS monitors cell voltage, current, temperature, state of charge and operating alarms to support stable battery operation.

Optional Bluetooth and GPS

Bluetooth monitoring can provide convenient battery status access, while optional GPS tracking supports industrial fleet and equipment management.

Maintenance-Free Operation

The LiFePO4 system does not require watering, acid inspection or equalization charging, reducing routine maintenance work.

Customized Forklift Integration

Battery dimensions, service weight, connector, communication, display, charger and mounting structure can be customized for the equipment.

Smart BMS Protection

Overcharge Protection Over-discharge Protection
Over-current Protection Short-circuit Protection
High-Temperature Protection Low-Temperature Protection Optional
Cell Voltage Monitoring Cell Balancing
State of Charge Monitoring Fault and Alarm Recording

Monitoring and Fleet Management

Optional Bluetooth monitoring allows compatible mobile devices to view battery voltage, state of charge, temperature, operating status and alarm information.

Optional GPS tracking can support battery location, forklift fleet management and equipment operating supervision according to project requirements.

Typical Applications

Electric Counterbalance Forklifts Industrial lifting and material transport applications Pallet Trucks Walk-behind and ride-on pallet handling equipment
Stackers and Reach Trucks Warehouse lifting and narrow-aisle operations Order Pickers Distribution center and warehouse picking equipment
Cold Storage Forklifts Optional low-temperature protection and heating Industrial Fleets Logistics, manufacturing and material handling fleets

Lead-Acid Battery Replacement

The battery can be designed to replace a compatible 48V lead-acid forklift battery. The following information must be confirmed before production:

  • Forklift brand, model and rated load
  • Original battery voltage and capacity
  • Battery compartment dimensions
  • Required battery service weight and counterbalance
  • Continuous and peak current requirements
  • Connector type, cable size and polarity
  • Controller and communication requirements
  • Charger voltage, charging current and protocol

OEM and ODM Customization

  • 304Ah, 412Ah, 560Ah and other customized capacities
  • Customized enclosure dimensions and installation structure
  • Customized battery service weight and counterweight
  • Customized continuous and peak discharge current
  • Customized Anderson, REMA and industrial connectors
  • Optional CAN and RS485 communication
  • Optional Bluetooth display and GPS tracking
  • Optional low-temperature heating
  • Matched lithium battery charger
  • Customized logo, color, labels and export packaging

Quality Control

  • Cell capacity and internal resistance matching
  • Battery voltage and capacity verification
  • Charge and discharge performance testing
  • BMS protection and communication testing
  • Connector, cable and insulation inspection
  • Enclosure, lifting point and mounting inspection
  • Final functional and packaging inspection

Packaging and Shipping

Each forklift battery is protected with moisture-resistant wrapping, reinforced cushioning and a heavy-duty export wooden case or pallet suitable for industrial battery transportation.

Shipping documents such as UN38.3 and MSDS can be prepared according to the final battery configuration and transportation route.

Frequently Asked Questions

Which capacity should I select?

The required capacity depends on the forklift model, motor power, rated load, daily working hours, number of shifts and available charging time.

Why is the nominal voltage 51.2V for a 48V forklift?

A standard 48V LiFePO4 battery normally uses sixteen cells in series, producing a nominal battery voltage of 51.2V.

Can this battery replace a lead-acid forklift battery?

Yes. Voltage, dimensions, service weight, current, connector, controller compatibility and charger requirements must be verified before replacement.

Are Bluetooth and GPS functions available?

Yes. Bluetooth battery monitoring and GPS fleet tracking can be configured according to project requirements.

Can the battery dimensions and weight be customized?

Yes. The enclosure and internal counterweight can be designed according to the forklift battery compartment and required service weight.

Is a matched charger available?

Yes. A lithium battery charger can be supplied according to the selected capacity, charging current and communication requirements.

What information is required for customization?

Please provide the forklift brand and model, original battery specifications, compartment dimensions, required weight, connector, daily working hours and charger information.

Request a Customized Forklift Battery Solution

Send Chalongfly your forklift model, original battery voltage, capacity, dimensions, weight, connector and daily operating requirements. Our team will recommend a suitable 51.2V LiFePO4 forklift battery configuration.
