51.2V 105Ah LiFePO4 Golf Cart Battery with 5376Wh Capacity and Smart BMS for 48V Lead-Acid Conversion
51.2V 105Ah LiFePO4 Golf Cart Battery with 5376Wh Capacity and Smart BMS for 48V Lead-Acid Conversion
51.2V 105Ah LiFePO4 Golf Cart Battery with 5376Wh Capacity and Smart BMS for 48V Lead-Acid Conversion
51.2V 105Ah LiFePO4 Golf Cart Battery with 5376Wh Capacity and Smart BMS for 48V Lead-Acid Conversion
51.2V 105Ah LiFePO4 Golf Cart Battery with 5376Wh Capacity and Smart BMS for 48V Lead-Acid Conversion
51.2V 105Ah LiFePO4 Golf Cart Battery with 5376Wh Capacity and Smart BMS for 48V Lead-Acid Conversion
51.2V 105Ah LiFePO4 Golf Cart Battery with 5376Wh Capacity and Smart BMS for 48V Lead-Acid Conversion
51.2V 105Ah LiFePO4 Golf Cart Battery with 5376Wh Capacity and Smart BMS for 48V Lead-Acid Conversion
51.2V 105Ah LiFePO4 Golf Cart Battery with 5376Wh Capacity and Smart BMS for 48V Lead-Acid Conversion
51.2V 105Ah LiFePO4 Golf Cart Battery with 5376Wh Capacity and Smart BMS for 48V Lead-Acid Conversion
Specifications
Certification :
UN38.3, MSDS
Model Number :
CLF-GC-51V105Ah
MOQ :
2 Packs
Packaging Details :
Each battery is protected with moisture-resistant wrapping, reinforced cushioning and a heavy-duty export wooden case or pallet. Accessories are packed separately according to the final system configuration.
Supply Ability :
500 Packs per Month
Price :
Negotiable
Delivery Time :
25–35 Working Days
Brand Name :
Chalongfly
Place of Origin :
Hunan,China
Description
48V Golf Cart Lithium Conversion

51.2V 105Ah LiFePO4 Golf Cart Battery

5376Wh lithium traction battery with smart BMS and high-current discharge for 48V golf cart upgrades and lead-acid battery conversion.

Product Overview

The Chalongfly 51.2V 105Ah LiFePO4 battery is designed for 48V electric golf carts requiring reliable traction power, extended runtime and intelligent battery management.

With 5376Wh of nominal energy, the battery is suitable for recreational golf carts, golf-course fleets, resort vehicles, community mobility carts and compatible lead-acid-to-lithium conversion projects.

The standard configuration supports 150A continuous discharge and 300A peak discharge. Higher-current BMS options can be evaluated for applications requiring stronger acceleration or hill-climbing performance.

Main Specifications

Model CLF-GC-51V105Ah
System Voltage 48V Golf Cart System
Nominal Voltage 51.2V
Rated Capacity 105Ah
Nominal Energy 5376Wh
Battery Chemistry LiFePO4
Maximum Charge Voltage 58.4V
Charge Current 50A
Continuous Discharge 150A Standard
Peak Discharge 300A Standard
Dimensions 472 × 312 × 243mm
Approximate Weight 45kg
Cycle Life More Than 4,000 Cycles

Higher-current BMS configurations are available according to motor power, controller current and hill-climbing requirements.

48V Lead-Acid to Lithium Conversion

The battery can be configured to replace compatible 48V lead-acid golf cart battery banks. A proper conversion requires more than matching system voltage.

Battery Compartment Fitment

Battery dimensions, mounting position and bracket design must match the available vehicle space.

Controller Current Matching

Continuous and peak battery current must be selected according to the golf cart motor controller and expected driving conditions.

Matched Lithium Charger

A charger with the correct LiFePO4 voltage and charging profile should be used rather than assuming the original lead-acid charger is compatible.

High-Current Traction Performance

Standard Continuous Current 150A
Standard Peak Current 300A
Higher-Current Option Available According to BMS and Vehicle Requirements
Selection Factors Motor Power, Controller Current, Vehicle Weight, Hill Grade and Acceleration

Smart BMS and Battery Monitoring

The integrated smart BMS monitors battery operation and provides protection against common electrical and temperature faults.

Overcharge Protection Over-discharge Protection
Over-current Protection Short-circuit Protection
Temperature Monitoring Cell Balancing
Bluetooth Monitoring Available

Optional Complete Golf Cart Battery System

  • Matched LiFePO4 battery charger
  • SOC display or touch display
  • Bluetooth battery monitoring
  • DC/DC voltage reducer
  • Battery mounting bracket
  • Main power connector and cables
  • Charging receptacle and charging cable
  • Optional heating function
  • Optional GPS function

Typical Applications

Golf Course Carts Traction power for recreational and commercial golf-course fleets Resort Vehicles Electric mobility for hotels, resorts and tourism facilities
Community Mobility Low-speed transportation for residential and campus environments Utility Carts Customized battery systems for compatible electric utility vehicles

Information Required for Battery Selection

  • Golf cart brand, model and year
  • Original battery system voltage
  • Motor rated and peak power
  • Motor controller maximum current
  • Battery compartment dimensions
  • Main power connector type
  • Existing charger specifications
  • Required driving range
  • Maximum hill grade and vehicle load

OEM and ODM Customization

  • BMS continuous and peak current
  • Battery enclosure dimensions
  • Main connector and cable harness
  • CAN or RS485 communication when required
  • Matched charger configuration
  • Display and Bluetooth monitoring
  • Mounting bracket and installation accessories
  • Logo, label and packaging customization

Frequently Asked Questions

Is this a 48V or 51.2V battery?

It is designed for a 48V golf cart system, while the LiFePO4 battery has a nominal voltage of 51.2V.

Can it replace a 48V lead-acid battery bank?

Yes, after confirming the controller, charger, battery compartment, connector, cable size, DC/DC converter and maximum current requirements.

Is 150A continuous discharge enough for every golf cart?

No. Required battery current depends on motor power, controller current, vehicle weight, acceleration and hill-climbing requirements. Higher-current BMS configurations are available.

Is a charger available?

Yes. A matched LiFePO4 charger can be supplied according to the final battery configuration.

What information is needed before ordering?

Please provide the golf cart model, original battery voltage, motor power, controller maximum current, battery compartment dimensions, connector type and required driving range.

Upgrade Your 48V Golf Cart to LiFePO4

Send Chalongfly your golf cart model, motor power, controller current, original battery configuration, battery compartment dimensions and required driving range. Our team will evaluate the complete lithium conversion and recommend the battery, BMS, charger and installation accessories.
