Chalong Fly provides ODM&OEMs with assurances of quality for our products and services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.
| Item | Condition/Note | Specification |
| Nominal Capacity | 1C discharge capacity | 6.0Ah |
| AC Impedance | At AC1000Hz | 6.5mΩ |
| Nominal Voltage | | 3.2V |
| Cell Size | Diameter: 32.2±0.3mm, Max 32.5mm | Height: 70.5±0.3mm, Max.70.8mm |
| Weight | | 140±5g |
| End-of-charge Voltage | CC Mode | 3.65V |
| End-of-discharge Current | CV Mode | 0.3A |
| Charging Method | Standard Charging | 1C at CC/CV 60min |
| Max. Continuous Charging | 6C at CC/CV 10min | |
| End-of-discharge Voltage | CC Mode | 2.0V |
| Max continuous Discharge Current | | 36A |
| Max Pulse Discharging Current | 3s | 60A |
| Cycle life | 1C/100% DOD | ≥2000 cycles |
| Operating Temperature Range | Charging Temperature Discharging Temperature Storage Temperature | 0~60℃ -20~60℃ -20~45℃ |
