Storage Lithium Polymer Battery Cell 103450 3.7V 1800mAh For Medical Device
Storage Lithium Polymer Battery Cell 103450 3.7V 1800mAh For Medical Device
Storage Lithium Polymer Battery Cell 103450 3.7V 1800mAh For Medical Device
Storage Lithium Polymer Battery Cell 103450 3.7V 1800mAh For Medical Device
Specifications
Certification :
CE, RoHS, MSDS, Un38.3
Brand Name :
RESKY
Model Number :
LP103450
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiable
Payment Terms :
T/T,Western Union
Supply Ability :
50000pcs/day
Delivery Time :
7-10days
Packaging Details :
Paper box
Model NO. :
LP103450
Nominal Capacity :
2000mAh
Weight :
25g
MOQ :
10PCS
Cycle Life :
500cycles
Warranty :
12months
Shipping :
UPS, DHL, FedEx, TNT, by Air, by Sea, Special Line
Color :
Blue PVC
Specification :
10*34*50mm
HS Code :
8507600090
Description
Product Description

Storage Lithium Polymer battery cell 103450 3.7V 1800mAh for Medical Device

NO. Items Specifications
1 batteries 3.7v 2000mah lipo battery
2 Charge voltage 4.2V
3 Nominal voltage 3.7V
4 Nominal capacity 2000mAh 0.2C Discharge
5 Charge current
 Standard Charging:0.5C
Rapid charge: 1.0C
6 Standard Charging method 0.5C CC(constant current)charge to 4.2V, then CV(constant voltage 4.2V)charge till charge current decline to ≤0.05C
7 Charging time
 Standard Charging:2.75hours(Ref.)
Rapid charge: 2hours(Ref.)
8 Max.charge current 1.0C
9 Max.discharge current 1.0C
10 Discharge cut-off voltage 2.5V0.25V(0.2C)
11 Operating temperature Charging: 0 °C ~45 °C
Discharging:0 °C ~45 °C
12 Storage temperature -10°C~ +45 °C
13 Dimension Length:50±2mm (not including tabs)
Width:34±0.5mm
Thickness:10±0.2mm
14 Drop Test The cell is to be dropped from a height of meter twice onto concrete ground. No fire, no leakage
15 cycle time ≥500times

Advantages:

High Energy Density: Lithium polymer battery cells offer significantly higher energy density compared to traditional battery types, enabling them to store more energy per unit weight or volume. This makes them ideal for devices where space is a constraint and long operational times are required.

Long Cycle Life: These batteries typically have a longer lifecycle, withstanding numerous charge and discharge cycles before significant capacity degradation occurs

Improved Safety: Advances in technology have led to the development of safer lithium polymer batteries with enhanced protection mechanisms against overcharging, overheating, and short-circuiting. Although safety concerns still exist, modern designs have significantly mitigated these risks.

Pictures:

Storage Lithium Polymer Battery Cell 103450 3.7V 1800mAh For Medical Device

Storage Lithium Polymer Battery Cell 103450 3.7V 1800mAh For Medical Device

Storage Lithium Polymer Battery Cell 103450 3.7V 1800mAh For Medical Device

Storage Lithium Polymer Battery Cell 103450 3.7V 1800mAh For Medical Device

Storage Lithium Polymer Battery Cell 103450 3.7V 1800mAh For Medical Device
