3C high discharge EVE 334ah LF334 Lifepo4 Lithium ion battery cell charging at -10C
3C high discharge EVE 334ah LF334 Lifepo4 Lithium ion battery cell charging at -10C
Specifications
Brand Name :
EVE
Model Number :
334ah
Certification :
CE/FCC/ROHS
Place of Origin :
china
MOQ :
100
Price :
2.3
Supply Ability :
10000 pcs/day
Delivery Time :
15 working days
Packaging Details :
carton box
Nominal capacity :
15ah
Nominal voltage :
3.2V
cycle life :
4000 times
Internal impedence :
0.18mΩ ± 0.05 mΩ
MCC :
2C 30S
charge cut-off voltage :
3.65V
Net Weight :
5.5kg
Single package size :
174*72*205mm
discharging cut-off voltage :
2.5V
Peak discharge :
3C 60S
Description
Normal capacity 334 Ah @ 0.5C discharge
Normal voltage 3.2V
Standard Charging voltage 3.65V
Internal resistance
0.18mΩ ± 0.05 mΩ
Max Constant Charge Current 2C 668A for 30S
Max Constant discharge current 3C 1002A for 30S
Standard Charging Current
 1C 334A
Standard Discharging Current
 0.5C 167A
Weight 5.5kg
Cell size 72*174*200mm

EVE 334ah cell is a EV battery

Comparison: Energy Storage Battery vs. Power Battery

Feature Energy Storage Battery (ESS) Power Battery (for EVs)
Primary Function To store energy for later use. Acts as a power bank. To provide instant, high power for acceleration and movement.
Application Grid energy storage, home solar systems, backup power. Electric Vehicles (EVs), electric bikes, power tools.
Key Performance Metric Energy Density (Wh/L) & Cycle Life
Focus on long duration and many charge/discharge cycles.		 Power Density (W/L)
Focus on delivering high bursts of power quickly.
Charge/Discharge Rate (C-rate) Typically lower C-rates. Slower, more stable charging and discharging over long periods (hours). Typically high C-rates. Rapid charging and discharging to meet power demands.
Cycle Life Requirement Very High. Designed for thousands of cycles over many years (often 10+ years). High, but generally less stringent than ESS. Focus on vehicle lifespan (e.g., 8-10 years).
System Voltage Generally higher system voltage (e.g., 400V - 1000V+ for large systems). Common standards are 400V and 800V platforms.
Cost Emphasis Cost per cycle is the most critical economic factor. Cost per unit of power (kW) is a major driver.
Common Chemistries Lithium Iron Phosphate (LFP) is dominant due to its safety and long cycle life. Various, including LFP (increasingly) and NMC (for high energy density).
Size & Weight Less constrained by size and weight; often large and stationary. Heavily optimized for size and weight to maximize vehicle range and efficiency.

Automative EVE 334ah and Energy Storage EVE 314ah

Feature EVE 334Ah Power Battery (e.g., LF334) EVE 314Ah Energy Storage Battery (e.g., LF314K)
Primary Design Purpose High Power / High C-rate Discharge High Capacity / Long Duration Discharge
Typical Application Electric Vehicles (EVs), HEVs, high-power tools, robotics. Stationary Energy Storage Systems (ESS), solar/wind backup, telecom backup.
Nominal Capacity 334 Ampere-hours (Ah) 314 Ampere-hours (Ah)
Key Performance Focus High Discharge/Charge Rate. Optimized for high current pulses and rapid energy transfer. High Cycle Life & Energy Density. Optimized for maximum total energy stored and delivered over time.
Typical Continuous Discharge Rate (C-rate) Higher (e.g., 1C to 3C or more continuous). Moderate (e.g., 0.5C standard, with high-cycle 1C options).
Cycle Life Very good, but secondary to power performance. Excellent. Designed for thousands of deep cycles (e.g., >8,000 cycles @ 80% DoD, 25°C).
Energy Density (Volumetric) May be slightly lower due to design trade-offs for power. Higher. Maximizes energy stored per unit volume, a critical metric for ESS.
Internal Resistance Lower. To minimize heat and voltage sag under high current. Slightly higher than power cells, but still very low for LFP chemistry.
Thermal Management Crucial due to heat generation at high rates. Less demanding under standard 0.5C operation, but still required.
Cost Emphasis Performance and reliability under stress. Lowest Cost per Cycle ($/kWh/cycle). Total lifetime cost is paramount.
Common Form Factor Prismatic cell, often optimized for vehicle battery pack integration. Prismatic cell, often with features for easy stacking in large ESS racks.

3C high discharge EVE 334ah LF334 Lifepo4 Lithium ion battery cell charging at -10C

Needed for high discharge rate battery,including 12V onbord battery,24V battery for golf cart,AGV,48V for forklift,crane,construction machinery.
