Deligreen 2.3V 35Ah Yinlong LTO Cells Lithium Titanate Battery with 25000 Cycles and 6C Fast Charging
Deligreen 2.3V 35Ah Yinlong LTO Cells Lithium Titanate Battery with 25000 Cycles and 6C Fast Charging
Specifications
Brand Name :
yinlong
Model Number :
2.3v35ah
Certification :
CE/FCC/ROHS
Place of Origin :
china
MOQ :
4
Price :
Negotiable
Payment Terms :
D/A,D/P,T/T,Western Union
Supply Ability :
1000pcs/day
Delivery Time :
15 working days
Packaging Details :
carton box
Nominal capacity :
35ah
Nominal voltage :
2.3v
Internal impedence :
≤1.0MΩ
cycle life :
25000 times
MCC :
210A
MCDC :
210A
Net Weight :
1222g
size :
66*161mm
Description
Deligreen 2.3V 35Ah Yinlong LTO Cells 66160 Lithium Titanate Battery
Product Specifications
Item Parameters Remark
Rated Capacity 35Ah
Nominal Voltage 2.3V
Internal Impedance ≤1.0mΩ Internal resistance measured at AC 1kHz after 50% charged
Standard Charge Cut-off Voltage 2.9V
Standard Discharge Cut-off Voltage 1.5V
Maximum Continuous Charge Current 6C (210A) 25℃±5℃
Maximum Continuous Discharge Current 6C (210A) 25℃±5℃
Maximum Pulse Charge/Discharge Current (10s) 10C (350A) 10 sec
Dimension Diameter: 66.0±1.0mm
Height: 161.0±1.0mm		 The detailed dimension can be found in "11.Scheme of the cell structure" of this specification
Weight 1222.0±10g
Key Advantages
  • Safest Lithium chemistry with high energy density
  • Built-in automatic protection for over-charge, over discharge, over current and over temperature
  • Efficient & long-lasting up to 20000+ cycles
  • Energy capacity hours of 40AH last 1HR
  • Internal cell balancing
  • Wide temperature range: -40℃~60℃
  • <3% yearly discharge storage with triple safety protection
  • High capacity system with 40AH
About LTO/Lithium Titanate Batteries

Lithium titanate battery (LTO) uses lithium titanate as a negative electrode material for lithium ion batteries. It can be combined with lithium manganate, NCM materials or lithium iron phosphate to form a 2.4V or 1.9V lithium ion secondary battery.

  • LTO battery is deep cycle with more than 25000 cycles
  • LTO lithium battery is one of the best options for solar energy systems
  • Ideal for street lamps, home power walls, solar systems, etc.
  • Yinlong 66160 can discharge at 10C rate
6-Minute Fast Charging

Yinlong technology enables fast charging in just 6-10 minutes.

Deligreen 2.3V 35Ah Yinlong LTO Cells Lithium Titanate Battery with 25000 Cycles and 6C Fast Charging Deligreen 2.3V 35Ah Yinlong LTO Cells Lithium Titanate Battery with 25000 Cycles and 6C Fast Charging
Safety Testing

Comprehensive safety testing including cutting, over charge/discharge, burning, drilling, stabbing, and stabbing in water.

Deligreen 2.3V 35Ah Yinlong LTO Cells Lithium Titanate Battery with 25000 Cycles and 6C Fast Charging Deligreen 2.3V 35Ah Yinlong LTO Cells Lithium Titanate Battery with 25000 Cycles and 6C Fast Charging Deligreen 2.3V 35Ah Yinlong LTO Cells Lithium Titanate Battery with 25000 Cycles and 6C Fast Charging
Important Notes:
  • Genuine Yinlong LTO 35Ah 66160 cell
  • M12 screws and busbars available as optional accessories - contact us for details
  • Production year: 2018
  • Cut off terminals and welded again
Extended Lifespan

Lithium titanate's spinel structure features minimal lattice parameter changes (0.3% volume change), providing excellent cycle stability compared to graphite materials which experience 10% volume changes leading to pulverization and reduced cycle life.

Applications
  • Intensive energy storage stations
  • Home energy storage
  • Charging piles
  • E-bus/E-car
  • Electric tools
  • Forklifts
Deligreen 2.3V 35Ah Yinlong LTO Cells Lithium Titanate Battery with 25000 Cycles and 6C Fast Charging
Customer Case Examples
Deligreen 2.3V 35Ah Yinlong LTO Cells Lithium Titanate Battery with 25000 Cycles and 6C Fast Charging Deligreen 2.3V 35Ah Yinlong LTO Cells Lithium Titanate Battery with 25000 Cycles and 6C Fast Charging Deligreen 2.3V 35Ah Yinlong LTO Cells Lithium Titanate Battery with 25000 Cycles and 6C Fast Charging
Shipping & Delivery
USA Delivery

By sea + Express (DDP, Tax free)
ETD: 5-8 days
ETA: 25-35 days after sailing
Tracking updates after local express pickup (typically 15-25 days after sailing)

EU Delivery

By railway + Express (DDP, Tax free) - Excluding Switzerland, Romania
ETD: 5-8 days
ETA: 30-45 working days after shipping
Tracking updates after local express pickup (typically 25-40 working days after shipping)

For remote areas not listed, please provide shipping address and zip code for verification.

About Yinlong

Yinlong is a global comprehensive new energy industry group that integrates titanium core materials, batteries, electric motor control, charging equipment, intelligent energy storage systems, and pure electric vehicle research, development, production and sales.

About Deligreen Power

Changsha Deligreen Power Co., LTD, founded in 2010, is a "Green Energy Solution Service Provider" specializing in lithium rechargeable batteries, BMS, balancers, chargers and related products for applications including electric bicycles, scooters, motorhomes, AGVs, solar/wind systems, energy storage systems, and trucks.

Our Commitments:
  • Real lithium capacity as specified
  • 100% refund for any quality problems
  • 100% replacement for any shipping damage
  • Lifetime fast technical support
Frequently Asked Questions
What is the life expectancy of a Lithium battery?
The typical estimated life of the LTO battery is 20,000 to 25,000 charge cycles. One charge cycle is a period of use from fully charged, to fully discharged, and fully recharged again.
Where can I get the price?
Please click Contact Now or Request a Quote. We will provide the best quote within 24 hours after receiving your product specifications including voltage, capacity, and application details.
How can you guarantee your quality?
We typically send samples for confirmation first. Production orders are made exactly as requested. We offer 1 year warranty for small battery packs and 2-3 years for larger battery systems.
What is your term for payment?
We accept T/T, L/C, Paypal, Western Union, Money Gram, Ali Express, Cash, and other payment methods.
What kind of certificates do you have?
We provide CE, ROHS, MSD, and shipping certifications.
