3.3KW IP66 Waterproof EV Battery Charger with Wide Voltage Range for Electric Vehicles
3.3KW IP66 Waterproof EV Battery Charger with Wide Voltage Range for Electric Vehicles
Specifications
Brand Name :
Deligreen
Model Number :
S2-3.3KW
Certification :
CE/FCC/ROHS
Place of Origin :
China
MOQ :
1
Price :
417.2
Payment Terms :
T/T,Western Union
Supply Ability :
1000pcs/day
Delivery Time :
10 days
Packaging Details :
35X24X20 cm/box
Input voltage range :
AC 90～265V
Input current :
16A
Output Rated voltage :
48V/72v/84V/96V/144V/312V
Max charging voltage :
66V
Max output current :
5-45A
Power factor :
≥0.99 Half load
Efficiency :
≥93% Full load
IP :
IP66
Application :
motorcycles/boats/surfboards
Net Weight :
6kg
Single package size :
294*210*111
Description
12V 60A 24V 30A 36V 20A 48V 15A 72V 10A EV Battery OBC Charger
Product Overview

800W 1500W Battery Charger 12V 60A 24V 30A 36V 20A 48V 15A 72V 10A Battery Charger

ItemValue
Place of OriginChina
ProvincesGuangdong
Brand NameDeligreencs
Model NumberS2-3.3KW
TypeWall Charger
CertificationRoHS
UseScooter, Electric Car, Electric Bike
Is LED Lamp IlluminationNO
Output48V/5-45A, 72V/5-40A, 84V/5-40A, 96V/5-32A, 144V/5-23A, 312V/5-10A
Output Power3.3KW
Input220V
Accessory TypeCharger Accessories
Model NumberCDS2-3.3KW
Input VoltageAC95-265V
Type of CoolingAir Cooling
Size294*210*111mm
Cell TypeLiFePO4 or Li-ion
IP GradeUP to IP66
Efficiency99%
CANNOT support
Weight6Kg
Lithium Battery Charger Introduction
  • Deligreen 3.3kw/6.6kw fully enclosed frequency conversion pulse charger is specifically designed for electric vehicle power batteries according to national standards
  • Features high efficiency, small size, high stability, long life, and full waterproof technology with IP66 protection level
  • Built-in thermal sensor works reliably from -20℃ to +85℃ with overheat protection and automatic recovery
  • IP66 waterproof rating guarantees operation in any weather conditions
3.3KW IP66 Waterproof EV Battery Charger with Wide Voltage Range for Electric Vehicles 3.3KW IP66 Waterproof EV Battery Charger with Wide Voltage Range for Electric Vehicles 3.3KW IP66 Waterproof EV Battery Charger with Wide Voltage Range for Electric Vehicles
Wide Voltage Options

Besides 220V and 110V fixed input voltage, this S2 car charger is available with wide range of input voltage

Input Voltage Range Input Current Output Rated Voltage Max Charging Voltage Max Charging Current Power Factor Efficiency
AC 90～265V ≤ 16A 48V 58.8V 45A ≥0.99 ≥93% Half load
≥93% Full load
72V99V40A
84V116V40A
96V132V32A
144V198V23A
312V440V10A
Electrical Parameters
ParameterValue
Input Frequency Rate45-65Hz
Standby Power Consumption≤ 5W
Output TypeConstant Pressure/Current
Output Power3300W@220VAC, 2800W@110VAC, 2650W@90-265VAC
CV Accuracy±1%
CC Accuracy±1%
Ripple Voltage Coefficient5%
Low Voltage Output13.8V CV
Rated Current5A
CAN CommunicationOptional
Protection Functions
Protection TypeSpecification
Input Over-voltage ProtectionAC264V
Input Under-voltage ProtectionAC90V
Output Over-voltage ProtectionYes
Output Start Voltage0.3 times rated voltage
Output Over-current ProtectionYes
Over Temperature ProtectionPower down from 85℃, shut off at 90℃
Short Circuit ProtectionStop output
Reverse Battery ProtectionStop output
Ground Protection≤ 100mΩ
Safety Specifications
SpecificationValue
Withstand PressureInput to output: 2000VAC≤10mA, Input to ground: 2000VAC≤12mA, Output to ground: 2000VAC≤10mA (1 minute)
Insulation ResistanceInput, output, signal end to shell ≥10MΩ (Test voltage 1000VDC)
Electromagnetic ImmunitySatisfy GB/T 18487.3-2001 11.3.1
Electromagnetic DisturbanceSatisfy GB/T 18487.3-2001 11.3.2
Harmonic CurrentSatisfy GB 17625.1-2003 6.7.1.1
Current Rise Time≤5S, Overshoot ≤5%
Off Response Time100% to 10%≤50mS, 100% to 0%≤200mS
Protection LevelIP66
Vibration Resistance10-25Hz Amplitude 1.2mm, 25-500Hz 30m/s², each direction 8 hours
Noise≤60dB(Class A)
MTBF150000H
Working EnvironmentRelative temperature 5%-95% without condensation
Operating Temperature-20℃ ~ +85℃
Storage Temperature-30℃ ~ +90℃
Shape and Size
3.3KW IP66 Waterproof EV Battery Charger with Wide Voltage Range for Electric Vehicles

3.3KW Air Cooling - Horizontal Mounting Size within Q2-3.3KW

Connector Type
3.3KW IP66 Waterproof EV Battery Charger with Wide Voltage Range for Electric Vehicles
Indicator Status Definition
No Alarm Status:
  • Charging operation status: Red light flashes at 1s intervals, green light off
  • Heating operation status: Green light flashes at 1s intervals, red light off
  • Waiting state: Green light always on, red light off
With Alarm Status:
  • Hardware failure or DC12V failure: Red, green pattern
  • PFC, CC & CP slave CPU communication failure: Red, green, red pattern
  • DC bus voltage failure: Red, green, red, green pattern
  • Low or high AC voltage protection: Red, green, red, green, red pattern
  • Battery not connected: Red, green, red, green, red, green pattern
  • Segment charge timeout protection: Red, red pattern
  • Battery temperature protection: Red, red pattern
  • CPU temperature or transformer temperature protection: Green, red, green pattern
  • Output short-circuit protection: Green, red, green, red pattern
  • Transformer primary overcurrent protection: Green, red, green, red, green pattern
Product Appearance Requirements
  • Outer surface should be flat, without obvious defects such as scratches and deformation
  • Surface coating should be uniform
  • Nameplates and signs firmly installed with clear handwriting
  • Parts and components fastened and reliable, free from defects and damages
  • Each product marked with product logo including part number, trademark, model, production number, company name, and warning instructions
Packaging, Transportation and Storage
Packaging:

Product name, model, specification, manufacturer name printed on label. Box contains product manual.

Transportation:

Suitable for transportation by car, boat and airplane. Protected from sun, moisture with civilized transportation.

Storage:

Store in packing box in clean, dry, well-ventilated environment at 5℃-40℃. Avoid exposure to sunlight, fire and water. Shelf life of 2 years.

Note: If storage time exceeds 2 years, product should be tested by professional before use.
Frequently Asked Questions
Is CAN protocol available?

Yes, we can supply CAN for your battery communication.

Is there LED light?

Yes, there are RED/YELLOW/GREEN LED lights for charging status indication.

Can Li-ion battery high-power chargers be charged in constant voltage mode?

Lithium battery uses constant current charging method.

What is Single-phase electricity?

Single-phase electricity refers to the form of electric energy transmission consisting of a phase wire (live wire) and a neutral wire.

Transportation & Delivery
Shipping to USA:

By sea + Express (DDP, Tax free)
ETD: 5-8 days
ETA: 25-35 days after sailing

Shipping to EU:

By railway + Express (DDP, Tax free)
ETD: 5-8 days
ETA: 30-45 working days after shipping

Note: For remote areas not listed, please provide shipping address and zip code for verification.
About Deligreen Power

Changsha Deligreen Power Co., LTD, founded in 2010, is a "Green Energy Solution Service Provider" specializing in lithium rechargeable batteries, BMS, balancers, chargers and related products.

Our Promises:
  • Real lithium capacity
  • 100% refund for any quality problem
  • 100% replacement for any shipping damage
  • Lifetime fast technical support

Customers' satisfaction is our endless pursuit.
