Lithium Titanate Battery 40AH 2.3V Yinlong LTO Cells with 25000 Cycle Life for Car Audio
Lithium Titanate Battery 40AH 2.3V Yinlong LTO Cells with 25000 Cycle Life for Car Audio
Lithium Titanate Battery 40AH 2.3V Yinlong LTO Cells with 25000 Cycle Life for Car Audio
Lithium Titanate Battery 40AH 2.3V Yinlong LTO Cells with 25000 Cycle Life for Car Audio
Specifications
Brand Name :
Yinlong
Model Number :
66160
Certification :
CE/FCC/ROHS
Place of Origin :
China
MOQ :
4
Price :
38.7
Payment Terms :
T/T,Western Union
Supply Ability :
1000pcs/day
Delivery Time :
15 days
Packaging Details :
carton box
Nominal capacity :
40AH
Nominal voltage :
2.3V
Internal impedence :
≤1.0MΩ
cycle life :
25000 times
MCC :
240A
MCDC :
240A
Net Weight :
1230.0±10g
size :
66*161mm
Description
Lithium Titanate Yinlong LTO Cells 40AH 45Ah 2.3V For Car Audio
Product Overview

Lithium Titanate Yinlong 40AH/45Ah 2.3V LTO Lithium Battery For Car Audio

What is LTO/Lithium Titanate Battery?

Lithium titanate battery (LTO) uses lithium titanate as a negative electrode material for lithium ion batteries. It can be combined with lithium manganate, NCM materials, or lithium iron phosphate to form a 2.4V or 1.9V lithium ion secondary battery.

LTO Battery Specifications
No. Item Parameters Remark
1 Rated Capacity 40Ah
2 Nominal Voltage 2.3V
3 Internal Impedance ≤1.0mΩ Internal resistance measured at AC 1kHz after 50% charged
4 Standard Charge Cut-off Voltage 2.9V
5 Standard Discharge Cut-off Voltage 1.5V
6 Maximum Continuous Charge Current 6I₁(240A) 25℃±5℃
7 Maximum Continuous Discharge Current 6I₁(240A) 25℃±5℃
Lithium Titanate Battery 40AH 2.3V Yinlong LTO Cells with 25000 Cycle Life for Car Audio
8 (10s) Maximum Pulse Charge/Discharge Current (10s) 10I₁(400A) 25℃±5℃
9 Operating Temperature Range Temperature: -40~65℃ Humidity: ≤85%RH Recommended charge/discharge current ≤1I₁ (40A) when cell temperature is lower than 0℃. Recommended to cool the cell when temperature is higher than 35℃
10 Storage Temperature Range -5℃~28℃ ≤90%RH storage moisture range
11 Dimension Diameter: 66.0±1.0mm Height: 161.0±1.0mm Detailed dimension available in cell structure scheme
12 Weight 1230.0±10g
13 Cycle Life 16000 cycles under standard test environment Discharge capacity ≥80% of initial capacity after 16000 cycles
25,000 Times Deep Cycle Life
Lithium Titanate Battery 40AH 2.3V Yinlong LTO Cells with 25000 Cycle Life for Car Audio Lithium Titanate Battery 40AH 2.3V Yinlong LTO Cells with 25000 Cycle Life for Car Audio
Dimensions
Diameter: D Length: L Screw L: Sl Weight
66MM 160MM 20MM 1.25KG
Features & Performance Safety Protection
• 20000 Life Cycles
• Over Charging Protection
• Increased Safety Performance
• Over Discharging Protection
• Wide Operating Temperature Range
• Short Circuit Protection
• High Temperature Performance
• Penetration Protection
• Green Energy Without Contaminants
• Thermal Shock Protection
• Pressure Resistant Cells
• No Fires
• High Capacity System
• No Explosions
• Steady Output Voltage
• <3% Yearly Discharge Storage
• Triple Safety Protection
• Vibration & Shock Resistant
• No Memory Effect
Busbars for LTO

M12 size

Lithium Titanate Battery 40AH 2.3V Yinlong LTO Cells with 25000 Cycle Life for Car Audio
Transportation & Delivery
  • Shipment to USA: By sea + Express (DDP, Tax free)
    ETD: 5-8 days
    ETA: 25-35 days after sailing
    Tracking updated after pickup by local express (15-25 days after sailing)
  • Shipment to EU: By railway + Express (DDP, Tax free) - Except Switzerland, Romania
    ETD: 5-8 days
    ETA: 30-45 working days after shipping
    Tracking updated after pickup by local express (25-40 working days after shipping)
  • Other: For remote areas not listed, please provide shipping address and zip code for verification
About Us

Changsha Deligreen Power Co. LTD, founded in 2010, is a "Green Energy Solution Service Provider" specializing in lithium rechargeable batteries, BMS, balancers, chargers and related products.

Main applications: Electric bicycle, scooter, motorhome, AGV, solar/wind system, energy storage system, truck and more.

Our promises:

  • Real lithium capacity
  • 100% refund for any quality problem
  • 100% replacement for any shipping damage
  • Lifetime fast technical support

Customers' satisfaction is our endless pursuit.

Frequently Asked Questions
What is the life expectancy of a Lithium battery?
The typical estimated life of the LTO battery is 20,000 to 25,000 charge cycles. One charge cycle is a period of use from fully charged, to fully discharged, and fully recharged again.
Where can I get the price?
Please contact us or request a quote. We will offer you the best quote within 24 hours after receiving your product specifications including voltage, capacity, and application requirements.
How can you guarantee your quality?
We normally send samples for confirmation first. We manufacture bulk orders exactly as requested and offer 1 year warranty for small battery packs, 2-3 years for larger battery systems.
What is your term for payment?
We accept T/T, L/C, Paypal, Western Union, Money Gram, Ali Express, Cash, and other payment methods.
What kind of certificates do you have?
We provide CE, ROHS, MSD, and shipping certifications.
