Specifications
Brand Name :
Deligreen
Model Number :
48V10kwh
Description
Customized 48V Hybrid Inverter Solar Energy System 30kw
Complete Solar Energy Storage Solution

Are you looking for a solution to store solar power? While solar panels cannot generate electricity at night, our Deligreen Power energy storage system enables 24-hour power availability through integrated battery storage.

The Deligreen ESS eliminates the complexity of purchasing multiple components separately. This all-in-one home storage battery offers plug-and-play convenience for simplified installation and operation.

Key Advantages
  • Integrated All-in-One System
  • Available capacities: 10kwh/15kwh/20kwh/25kwh
  • UPS Function with LCD Screen
  • Back-up Power Capability
  • 24-Hour Solar Power Utilization
  • 10-Year Warranty
  • Plug and Play Installation
Technical Specifications
Phase Single Phase
Rated Voltage 51.2V
Rated Capacity 200Ah
Continuous Discharge Current 100A
Peak Discharge Current 110A/10s
Standard Charging Current 50A
Fast Charging Current 100A
Parallel Capability 15P
Cooling Mode Self Cooled
Battery Type Lifepo4 Lithium Iron Phosphate
Cycle Life 10000 Times
Rated Grid Frequency 230V/176-270V
PV Max Input Power 4200W
MPPT Voltage Range 60-115V DC
Charging/Discharging Efficiency >92%
Battery Voltage Range 40V DC-60V DC ±0.6V DC
Warranty Battery: 10 Years, Inverter: 5 Years
Noise Level @1m <35db
Certificates CE, MSDS, UN38.3, ISO:9001
Certification
Product Certificate CE, UN38.3, MSDS, Sea Freight Dangerous Package
Battery Certificate CE, UL, IEC 62109-1&2, IEC 62477, EN61000, UN38.3
Dimensions & Environmental Specifications
Inverter Size/Weight 602×403×139mm / 15kg
Battery Size/Weight 602×403×200mm / 55kg
Chassis Size/Weight 602×403×82mm / 6kg
Installation Stacked
Storage Humidity Range ≤85% RH
Operating Temperature 20-55°C
Recommended Temperature 25°C
Waterproof Rating IP21
Customized 48V 30kw Hybrid Inverter Solar Energy System with Plug and Play All in One Home Storage Battery
Shipping & Delivery Information
USA Delivery

Method: Sea + Express (DDP, Tax Free)

ETD: 5-8 days

ETA: 25-35 days after sailing

Tracking updates available after local express pickup. Typically takes 15-25 days after sailing.

EU Delivery

Method: Railway + Express (DDP, Tax Free) - Excludes Switzerland, Romania

ETD: 5-8 days

ETA: 30-45 working days after shipping

Tracking updates available after local express pickup. Typically takes 25-40 working days after shipping.

Note: For remote areas not listed, please provide shipping address and zip code for verification.
