QNBBM Balancers equalize voltage for every series of batteries, preventing all cells from overcharge, insufficient charge, or over discharge. This maximizes battery performance and extends battery life.
The balancers are compatible with all LiFePO4 batteries, lithium ion batteries, LTO batteries, and 2V/6V/12V Gel/Flooded/AGM lead acid batteries. Applications include Powerwall, Car audio, ESS, UPS, Solar Energy, Electric Vehicles, and Solar and wind energy systems.
| Battery capacity limited | Unlimited |
| Battery count limited | 2S~unlimited (At least balance 2 cells) |
| Battery type limited | Lifepo4, LiMnO4, AGM, Gell, Flooded battery |
| Working voltage | 2V~5V (2V lead acid & lithium), 4V~9V (6V lead acid), 9V~15V (12V lead acid) |
| Power consumption | <50mW per 1S |
| Balance method | Energy transfer & Dynamic |
| Acceptable Constant balance current | 6A |
| Peak balance current | 10A |
| Voltage difference VS Balance current | 300mV-1A; 1V-3A |
| Voltage difference after using the balancer | <10mV <30mV (12V lead acid) |
| Working efficiency when balance current is 1A | >94% |
| Working temperature | -40~+80°C |
| Storage temperature | -40~+100°C |
| BMS limited | Can work with BMS or independently |
Battery balancer can keep batteries within 10mV and double battery lifespan.
Yes, absolutely. If you use the BMS and balancer together, that will be perfect. Most BMS are intelligent and can display battery information, but you might find the balance performance unsatisfactory. Adding the balancer will help solve this problem.
The power consumption is very low, only 50mW.
Normally if you don't use the batteries for 2-3 months, you need to recharge them for maintenance. Since the balancer power consumption is low, it won't consume much power. Whether you need to disconnect them depends on your battery pack capacity. Contact us with your specific situation for professional advice.
Yes, that is possible. We have solutions, such as using one balancer for two of your cells. We have many customers with special batteries where the balancers work great.
Lithium battery, lead acid battery, super capacitor systems.
1-2 business days if in stock. 1-3 weeks for volume orders.
All long pleasant business starts from good communication. We welcome your inquiries and are always available to answer questions. Even if we can't make a deal, we can share information and learn from each other.
