Specifications
Brand Name :
Deligreen
Model Number :
66160
Certification :
CE/FCC/ROHS
Place of Origin :
China
MOQ :
4
Price :
38.7
Payment Terms :
T/T,Western Union
Supply Ability :
1000pcs/day
Delivery Time :
15 days
Packaging Details :
carton box
Nominal capacity :
40AH
Nominal voltage :
2.3V
Internal impedence :
≤1.0MΩ
cycle life :
25000 times
MCC :
240A
MCDC :
240A
Net Weight :
1230.0±10g
size :
66*161mm
Description
6 Mins UPS Lithium Battery Yinlong LTO Cells
Product Overview
6 mins fast charging 40AH lithium titanate LTO battery telecom lithium battery
What is LTO/Lithium Titanate Battery?
Lithium titanate battery (LTO) uses lithium titanate as a negative electrode material for lithium ion batteries. It can be combined with lithium manganate, NCM materials, or lithium iron phosphate to form a 2.4V or 1.9V lithium ion secondary battery.
LTO Battery Specifications
No. Item Parameters Remark
1 Rated Capacity 40Ah
2 Nominal Voltage 2.3V
3 Internal Impedance ≤1.0mΩ Internal resistance measured at AC 1kHz after 50% charged
4 Standard Charge Cut-off Voltage 2.9V
5 Standard Discharge Cut-off Voltage 1.5V
6 Maximum Continuous Charge Current 6I1(240A) 25℃±5℃
7 Maximum Continuous Discharge Current 6I1(240A) 25℃±5℃
8 (10s) Maximum Pulse Charge/Discharge Current 10I1(400A) 25℃±5℃
9 Operating Temperature Range Temperature: -40~65℃ Humidity: ≤85%RH Recommended charge/discharge current ≤1I1 (40A) when cell temperature is lower than 0℃. Recommended to cool the cell when temperature is higher than 35℃
10 Storage Temperature Range -5℃~28℃ ≤90%RH storage moisture range
11 Dimension Diameter: 66.0±1.0mm Height: 161.0±1.0mm Detailed dimension available in cell structure scheme
12 Weight 1230.0±10g
13 Cycle Life Under standard test environment, continuous charge and discharge for 16000 cycles Discharge capacity ≥80% of initial capacity after 16000 cycles
6 Mins Fast Charging 40AH Lithium Titanate LTO Battery with 25000 Times Cycle Life Yinlong LTO Cells
25000 times deep cycle life
6 Mins Fast Charging 40AH Lithium Titanate LTO Battery with 25000 Times Cycle Life Yinlong LTO Cells
Dimensions
Diameter: D Length: L Screw L: Sl Weight
66MM 160MM 20MM 1.25KG
Features & Performance Safety Protection
  • 20000 LIFE CYCLES
  • OVER CHARGING PROTECTION
  • INCREASED SAFETY PERFORMANCE
  • OVER DISCHARGING PROTECTION
  • WIDE OPERATING TEMPERATURE RANGE
  • SHORT CIRCUIT PROTECTION
  • HIGH TEMPERATURE PERFORMANCE
  • PENETRATION RESISTANCE
  • GREEN ENERGY WITHOUT CONTAMINANTS
  • THERMAL SHOCK RESISTANCE
  • PRESSURE RESISTANT CELLS
  • NO FIRES
  • HIGH CAPACITY SYSTEM
  • NO EXPLOSIONS
  • STEADY OUTPUT VOLTAGE
  • <3% YEARLY DISCHARGE STORAGE
  • TRIPLE SAFETY PROTECTION
  • VIBRATION & SHOCK RESISTANT
  • NO MEMORY EFFECT
6 Mins Fast Charging
6 Mins Fast Charging 40AH Lithium Titanate LTO Battery with 25000 Times Cycle Life Yinlong LTO Cells
Transportation & Delivery
Shipment to USA: By sea + Express (DDP, Tax free)
ETD: 5-8 days
ETA: 25-35 days after sailing
The tracking will be updated after pick up by local express. Usually takes 15-25 days after sailing.
Shipment to EU: By railway + Express (DDP, Tax free). Except Switzerland, Romania
ETD: 5-8 days
ETA: 30-45 working days after shipping
The tracking will be updated after pick up by local express. Usually takes 25-40 working days after shipping.
For remote areas not listed, please provide shipping address and zip code for verification.
About Us
Changsha Deligreen Power Co., LTD, founded in 2010, is a "Green Energy Solution Service Provider".

We focus on newest technology, new ideas, hard-working and honest people. Our expertise includes lithium rechargeable batteries, BMS, balancers, chargers and related products.

Main applications: electric bicycles, scooters, motorhomes, AGV, solar/wind systems, energy storage systems, trucks and more.

Our Promises:
• "Real" lithium capacity
• "100%" refund for any quality problem
• "100%" replacement for any shipping damage
• Lifetime fast technical support

Customers' satisfaction is our endless pursuit.
Frequently Asked Questions
What is the life expectancy of a Lithium battery?
The typical estimated life of the LTO battery is 20,000 to 25,000 charge cycles. One charge cycle is a period of use from fully charged, to fully discharged, and fully recharged again.
Where can I get the price?
Please Click Contact Now or Request a Quote. We will offer you the best quote within 24 hours after we receive your product specifications including voltage, capacity, and application requirements.
How can you guarantee your quality?
Normally we will send you a sample to confirm everything first. We will manufacture the bulk order exactly as requested. We offer 1 year warranty for small battery packs and 2-3 years for larger battery systems.
What is your term for payment?
We accept T/T, L/C, Paypal, Western Union, Money Gram, Ali Express, Cash, and other payment methods.
What kind of certificates do you have?
We can provide CE, ROHS, MSD, and shipping certifications.
