12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
Specifications
Brand Name :
Deligreence
Model Number :
LiFePO4 Cell 6S
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Price :
USD 113.4-98 /pcs
Payment Terms :
T/T
Supply Ability :
100 pcs per week
Delivery Time :
5-8 working days
Packaging Details :
Carton
Product Name :
CE LiFePO4 Cell 6S Active Charger Equalizer Battery Balancer Module
Battery capacity limited :
Unlimited
Battery count limited :
2S~unlimited, At least balance 2 cells
Battery type :
LiFePO4, LiMnO4, AGM, Gell, Lead Acid, Flooded battery and so on
Working voltage :
1.8V~15V
Power consumption :
<50mW per 1S
Balance method :
pure electric sightseeing bus ,electric passenger car ,electric bus
Acceptable Constant balance current :
6A
Peak balance current :
10A
BMS limited :
Can work with BMS Or can work independently
Description
Deligreen Equalizer Battery 12V 14V Lithium Balancer Lead Acid Equalizer Battery
Deligreen Equalizer Battery balancers equalize voltage for every series of batteries, preventing all cells from overcharge, insufficient charge, or over discharge. This maximizes battery performance and extends battery life.
The balancers are compatible with all LiFePO4 batteries, lithium ion batteries, LTO batteries, and 2V/6V/12V Gel/Flooded/AGM lead acid batteries. Applications include powerwalls, car audio systems, ESS, UPS, solar energy systems, electric vehicles, and solar and wind energy systems.
12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
Main Technical Parameters
Battery capacity limited Unlimited
Battery count limited 2S~unlimited (At least balance 2 cells)
Battery type limited LiFePO4, LiMnO4, AGM, Gel, Flooded battery and more
Working voltage 2V~5V (2V lead acid & lithium battery)
4V~9V (6V lead acid battery)
9V~15V (12V lead acid battery)
Power consumption <50mW per 1S
Balance method Energy transfer & Dynamic
Acceptable Constant balance current 6A
Peak balance current 10A
Voltage difference VS Balance current 300mV-1A; 1V-3A
Voltage difference after using the balancer <10mV <30mV (12V lead acid)
Working efficiency when balance current is 1A >94%
Working temperature -40°C to +80°C
Storage temperature -40°C to +100°C
BMS limited Can work with BMS or work independently
Battery balancer can keep batteries within 10mV and double battery lifespan.
12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery 12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery 12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
Package
12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
About Us
12V 14V Battery Balancer with 6A Constant Balance Current for LiFePO4 and Lead Acid Equalizer Battery
Why Choose Us?
  • One-stop power provider including lithium battery active balancer, BMS, charger and other accessories
  • Russia, Poland, and USA warehouses ensure quick delivery
  • Factory direct pricing and lifetime technical support
  • Reliable warranty
Looking for distributors! Make DIY Battery Easier!
Frequently Asked Questions
Q1: I have a BMS already, can I use the balancer?
Yes, absolutely. If you use the BMS and balancer together, that will be perfect. Most BMS are intelligent and can display battery information, but you might find the balance performance unsatisfactory. Adding the balancer will help solve this problem.
Q2: What is power consumption of the balancer?
The power consumption is very low, only 50mW.
Q3: If I don't use the batteries for a long time, should I disconnect the balancers?
Normally if you don't use the batteries for 2-3 months, you need to recharge the batteries for maintenance. Since the balancer power consumption is low, it won't consume much power from the battery. Whether you need to disconnect them depends on your battery pack capacity. For different capacities (10AH vs 100AH), the results vary. Contact us with your specific situation for professional suggestions.
Q4: My battery is NiCD or other special battery with nominal voltage of only 1.2V. Can I use your balancer?
Yes, that is possible. We have solutions, such as using one balancer for two of your cells. We have many customers with special batteries where the balancers work great.
Q5: What is application of your balancer?
Lithium battery, lead acid battery, super capacitor applications.
Q6: What is delivery time of your balancer?
1-2 business days if in stock. 1-3 weeks for volume orders.
All long pleasant business starts from good communication. Maybe you have many other questions to ask. We are always waiting for your inquiry. Even if we can't make the deal, we can make friends, share information and learn from each other.
