Specifications
Brand Name :
Deligreence
Model Number :
LiFePO4 Cell 6S
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Price :
USD 113.4-98 /pcs
Payment Terms :
T/T
Supply Ability :
100 pcs per week
Delivery Time :
5-8 working days
Packaging Details :
Carton
Product Name :
CE LiFePO4 Cell 6S Active Charger Equalizer Battery Balancer Module
Battery capacity limited :
Unlimited
Battery count limited :
2S~unlimited, At least balance 2 cells
Battery type :
LiFePO4, LiMnO4, AGM, Gell, Lead Acid, Flooded battery and so on
Working voltage :
1.8V~15V
Power consumption :
<50mW per 1S
Balance method :
pure electric sightseeing bus ,electric passenger car ,electric bus
Acceptable Constant balance current :
6A
Peak balance current :
10A
BMS limited :
Can work with BMS Or can work independently
Description
24V 48V 60V BMS 3S 1A 2A 5A Active Equalizer Balancer for LiFePO4 and LTO Battery Energy Equalization

QNBBM Balancers equalize voltage for every series of batteries, preventing all cells from overcharge, insufficient charge, or over discharge. This technology maximizes battery performance and extends battery life.

The balancers are compatible with all LiFePO4 batteries, lithium ion batteries, LTO batteries, and 2V/6V/12V Gel/Flooded/AGM lead acid batteries. Applications include Powerwall, Car audio, ESS, UPS, Solar Energy, Electric Vehicles, and Solar and wind energy systems.

6A Constant 10A Peak Battery Balancer Active Equalizer Works with BMS or Independently for LiFePO4 LTO Lead Acid Batteries
Main Technical Parameters
Parameter Specification
Battery Capacity Limited Unlimited
Battery Count Limited 2S~unlimited (At least balance 2 cells)
Battery Type Limited LiFePO4, LiMnO4, AGM, Gel, Flooded battery
Working Voltage 2V~5V (2V lead acid & lithium battery)
4V~9V (6V lead acid battery)
9V~15V (12V lead acid battery)
Power Consumption <50mW per 1S
Balance Method Energy Transfer & Dynamic
Acceptable Constant Balance Current 6A
Peak Balance Current 10A
Voltage Difference VS Balance Current 300mV-1A; 1V-3A
Voltage Difference After Using Balancer <10mV (<30mV for 12V lead acid)
Working Efficiency (1A balance current) >94%
Working Temperature -40°C to +80°C
Storage Temperature -40°C to +100°C
BMS Limited Can work with BMS or independently

Our battery balancer maintains batteries within 10mV voltage difference and can double battery lifespan.

6A Constant 10A Peak Battery Balancer Active Equalizer Works with BMS or Independently for LiFePO4 LTO Lead Acid Batteries 6A Constant 10A Peak Battery Balancer Active Equalizer Works with BMS or Independently for LiFePO4 LTO Lead Acid Batteries 6A Constant 10A Peak Battery Balancer Active Equalizer Works with BMS or Independently for LiFePO4 LTO Lead Acid Batteries 6A Constant 10A Peak Battery Balancer Active Equalizer Works with BMS or Independently for LiFePO4 LTO Lead Acid Batteries 6A Constant 10A Peak Battery Balancer Active Equalizer Works with BMS or Independently for LiFePO4 LTO Lead Acid Batteries
Why Choose Us?
  • One-stop power provider including lithium battery active balancer, BMS, charger and other accessories
  • Russia, Poland, and USA warehouses ensure quick delivery
  • Factory direct pricing and lifetime technical support
  • Reliable warranty protection
  • Looking for distributors! Making DIY Battery Projects Easier!
Frequently Asked Questions
Q1: I have a BMS already, can I use the balancer?
Yes, absolutely. Using BMS and balancer together provides optimal performance. Most BMS systems are intelligent and display battery information, but balance performance may be unsatisfactory. Adding our balancer solves this problem effectively.
Q2: What is the power consumption of the balancer?
The power consumption is very low, only 50mW per cell.
Q3: If I don't use the batteries for a long time, should I disconnect the balancers?
For batteries unused for 2-3 months, recharging is necessary for maintenance. Since balancer power consumption is minimal, it won't significantly drain the battery. Whether to disconnect depends on your battery pack capacity. Contact us with your specific details for professional advice.
Q4: My battery is NiCD or other special battery with nominal voltage of only 1.2V. Can I use your balancer?
Yes, that is possible. We have solutions, such as using one balancer for two cells. We have many customers with special batteries where our balancers work excellently.
Q5: What are the applications of your balancer?
Lithium batteries, lead acid batteries, and super capacitors.
Q6: What is the delivery time for your balancer?
1-2 business days if in stock. 1-3 weeks for volume orders.

All long pleasant business starts from good communication. We welcome your inquiries and are always available to answer your questions. Even if we can't make a deal, we're happy to share information and learn from each other.
