Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
Specifications
Brand Name :
Deligreence
Model Number :
LiFePO4 Cell 6S
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Price :
USD 113.4-98 /pcs
Payment Terms :
T/T
Supply Ability :
100 pcs per week
Delivery Time :
5-8 working days
Packaging Details :
Carton
Product Name :
CE LiFePO4 Cell 6S Active Charger Equalizer Battery Balancer Module
Battery capacity limited :
Unlimited
Battery count limited :
2S~unlimited, At least balance 2 cells
Battery type :
LiFePO4, LiMnO4, AGM, Gell, Lead Acid, Flooded battery and so on
Working voltage :
1.8V~15V
Power consumption :
<50mW per 1S
Balance method :
pure electric sightseeing bus ,electric passenger car ,electric bus
Acceptable Constant balance current :
6A
Peak balance current :
10A
BMS limited :
Can work with BMS Or can work independently
Description
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer Balancer Battery Board
QNBBM Balancers equalize voltage for every series of batteries. Prevent all cells from overcharge, insufficient charge or over discharge. Maximize battery performance and extend battery life.
The balancers can be used for all LiFePO4 battery, lithium ion battery, LTO battery, 2V/6V/12V Gel/Flooded/AGM lead acid battery applied for these areas: Powerwall, Car audio, ESS, UPS, Solar Energy, Electric Vehicle, Solar and wind energy.
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
Main Technical Parameters
Parameter Specification
Battery capacity limited Unlimited
Battery count limited 2S~unlimited (At least balance 2 cells)
Battery type limited Battery: LiFePO4, LiMnO4 etc. AGM, Gel, Flooded battery and so on
Working voltage 2V~5V (2V lead acid battery and lithium battery)
4V~9V (6V lead acid battery)
9V~15V (12V lead acid battery)
Power consumption <50mW per 1S
Balance method Energy transfer & Dynamic
Acceptable Constant balance current 6A
Peak balance current 10A
Voltage difference VS Balance current 300mV-1A; 1V-3A
Voltage difference after using the balancer <10mV <30mV (12V lead acid)
Working efficiency when balance current is 1A >94%
Working temperature -40~+80°C
Storage temperature -40~+100°C
BMS limited Can work with BMS or can work independently
Battery balancer can keep batteries within 10mV and double battery lifespan
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
Package
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
About Us
Lto Battery Balancer 5A Capacitor Inductance Active Equalizer with 6A Constant and 10A Peak Balance Current
Why Choose Us?
  • One-stop power provider including lithium battery active balancer, BMS, charger and other accessories
  • Russia, Poland/USA warehouse ensure quick delivery
  • Factory direct price and whole life technical support
  • Reliable warranty
Look for distributors! Make DIY Battery Easier!
Frequently Asked Questions
Q1: I have a BMS already, can I use the balancer?
Yes, sure. If you use the BMS and balancer together, that will be perfect. Most BMS are intelligent and can display battery information, but you might feel the balance performance is not satisfactory. Now adding the balancer will help you solve the problem.
Q2: What is power consumption of the balancer?
The power consumption is very low, only 50mW.
Q3: If I don't use the batteries for a long time, should I disconnect the balancers?
Normally if you don't use the batteries for 2~3 months, you need to recharge the batteries. This is necessary for battery maintenance. Since the balancer power consumption is low, it won't consume much power from the battery. Whether you need to disconnect them or not depends on what capacity is your battery pack. For a 10AH and 100AH pack, the result is different. So you can contact us and tell us your situation in details. We will be glad to give you professional suggestion.
Q4: My battery is NiCD or other special battery. The nominal volt is only 1.2V. Can I also use your balancer?
Yes that is possible. We have solutions. For example, we can use 1 piece of balancers for two of your cells. We have many customers who have such special batteries. The balancers prove to be working great as well.
Q5: What is application of your balancer?
Lithium battery, lead acid battery, super capacitor
Q6: What is delivery time of your balancer?
1~2 business days if in stock. 1~3 weeks for volume order
All long pleasant business starts from good communication. Maybe you have many other questions to ask. We are always waiting for your inquiry. Even if we can't make the deal, we can make friends, share information and learn from each other.
