LINO Motor For Vending Machine 12VDC 24VDC 118g 24RPMGMF8964
LINO Motor For Vending Machine 12VDC 24VDC 118g 24RPMGMF8964
LINO Motor For Vending Machine 12VDC 24VDC 118g 24RPMGMF8964
LINO Motor For Vending Machine 12VDC 24VDC 118g 24RPMGMF8964
LINO Motor For Vending Machine 12VDC 24VDC 118g 24RPMGMF8964
LINO Motor For Vending Machine 12VDC 24VDC 118g 24RPMGMF8964
Specifications
Brand Name :
LINO
Model Number :
GMF8964
Certification :
ROHS
Place of Origin :
ZHEJIANGNINGBO
MOQ :
1K
Price :
The price ranges from 15 to 20 RMB per unit. The specific model requirements vary
Payment Terms :
T/T
Supply Ability :
100,000 units per month
Delivery Time :
30work days
Packaging Details :
Carton with pallet
Voltage :
12VDC,24VDC
Motor :
RS365
typical application :
Vending machine, Spiral motor
Description

DC GEAR MOTOR GMF8964

Products' type: DC geared motor

LINO Motor For Vending Machine 12VDC 24VDC 118g 24RPMGMF8964
Model: GMF8964
Sort: Square shape DC geared motor
Typical applications: vending machine,coffee machine,communications-equipment, ACU-RITE,induced garbage can, electronic lock, optical equipment, medical instrumentation, office equipment, household appliances,etc…
Weight 118g (approx)

MODEL VOLTAGE AT NO LOAD AT MAXIMUM EFFICIENCY AT STALL
SPEED CURRENT SPEED CURRENT TORQUE TORQUE CURRENT
VDC RPM A RPM A mN.m kg.cm mN.m kg.cm A
GMF8964-365 24 24 0.11 19 0.29 1519 15.500 8232 84.000 1.17
Base motor option RS360,RS365,RS380,RS385,RS390,RS395
Gear ratio option 419
Note The specifications and output shaft can be changed as customer's request.
Packing detail Carton, Size: 40X35X41.5CM;108pcs/carton; G.W:14.5Kg.
