Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance
Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance
Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance
Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance
Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance
Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance
Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance
Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance
Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance
Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance
Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance
Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance
Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance
Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Linke
Certification :
RoHS, TUV, CE, ISO
MOQ :
1000m
Price :
Negotiable
Packaging Details :
According to requirement
Delivery Time :
7-15 days
Payment Terms :
Advance 30% deposit and ship after receiving 70% final payment
Supply Ability :
50000m/day
Model NO. :
LK-S19
AMP :
1200A
Color :
Customized
Material :
Silicone
Conductor :
Tinned Copper
Voltage :
500V
Property :
High Temperature Resistance
Transport Package :
Box Packaging
Customization :
Available
Shipping Cost :
about shipping cost and estimated delivery time.
Return&refunds :
You can apply for a refund up to 30 days after receipt of the products.
Core :
Multiple
conductor material :
copper/Tinned Copper
Conductor Type :
Twisted wire
Exterior material :
customize：PVC、PE、LSFOH、silicone rubber
insulating materials :
customize:PVC、PE 、XLPE、EPR、SIR
specifications :
0.1-450mm²
rated voltage :
300-600V
rated temperature :
-60± 200℃
type :
insulated
Lead Time :
7-15days
Description
Tinned Copper Silicone Wire Cable
Ultra-flexible very high strand count soft silicone cable with high temperature resistance and 500V/600V voltage rating, available in gauges 6-14AWG.
Product Specifications
  • Conductor: Ultra flexible high strand count tinned copper for maximum flexibility
  • Insulation: Silicone
  • Temperature Range: -60°C to 200°C (-76°F to 392°F)
  • Voltage Rating: 600 VAC
  • Compliances: Designed to meet UL VW-1 Vertical Wire Flame Test, RoHS Compliant
Applications
Battery Cable, Power Cable, Robotics, RC, Hobby, Automotive, Speakers, anywhere extra flexibility or high temperature rated is necessary.
Technical Specifications Table
Gauge (AWG) Number of Strands Gauge of Strands Insulation Thickness Finished Wire Diameter
06 3200 40 AWG (0.08MM) .065" (1.65mm) .334" (8.5mm)
08 1650 40 AWG (0.08MM) .059" (1.50mm) .236" (6.0mm)
10 1050 40 AWG (0.08MM) .051" (1.30mm) .213" (5.4mm)
12 680 40 AWG (0.08MM) .041" (1.05mm) .177" (4.5mm)
14 400 40 AWG (0.08MM) .033" (0.83mm) .138" (3.5mm)
Product Images
Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance Tinned Copper Silicone Wire Cable with High Flexibility 500V Voltage and High Temperature Resistance
Frequently Asked Questions
How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.
What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.
Can I get a discount?
It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.
Does your company accept OEM production?
Yes, we can print your company name and even customize the quality card to promote your company.
