Specifications
Certification :
3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949
Place of Origin :
Guangdong, China
Brand Name :
Linke
MOQ :
1000m
Price :
Negotiable
Packaging Details :
According to requirement
Delivery Time :
7-15 days
Payment Terms :
Advance 30% deposit and ship after receiving 70% final payment
Supply Ability :
50000m/day
Model NO. :
BQ-C
Conductor Material :
Copper
Sheath Material :
PVC
Insulation Material :
Xlpvc
Material Shape :
Round Wire
Range of Application :
Multimedia, DVD Player, Speaker, Microphone
Voltage :
60V DC/25V AC
Type :
Insulated
Conductor Type :
Twisted wire
Application :
Overhead, Heating, Underground
Customization :
Available
Shipping Cost :
about shipping cost and estimated delivery time.
Return&refunds :
You can apply for a refund up to 30 days after receipt of the products.
Core :
Multiple
conductor material :
copper/Tinned Copper
Exterior material :
customize：PVC、PE、LSFOH、silicone rubber
insulating materials :
customize:PVC、PE 、XLPE、EPR、SIR
specifications :
0.1-450mm²
rated voltage :
300-600V
rated temperature :
-60± 200℃
colour :
customize
Description
Waterproof Rubber Sheathed Cable - Silicone Rubber Cable Universal Flexible Cable
400 Amp 95mm Super Flexible Rubber Double Insulated Welding Cable

Rubber-sheathed cable is a flexible, movable cable featuring multi-stranded fine copper wire conductors with rubber insulation and rubber sheath protection. Our product range includes general rubber-sheathed flexible cables, welding machine cables, submersible motor cables, radio device cables, and photographic light source cables.

  • Suitable for AC voltage up to 200V and pulsating DC peak values of 400V for welding machine secondary side wiring and clamp connections
  • Specifically designed for welding machine secondary side wiring and welding tong connections
  • Single-core construction with multi-strand flexible conductors
  • Heat-resistant polyester film insulation with protective rubber outer layers
Welding Cable Specifications
Core Operating Temperature Not exceeding 65°C
Typology YH (Compound rubber sheath for welding cable)
YHF (Neoprene or other synthetic sheathed welding cable)
Application Suitable for welding machines with voltage to ground not greater than 200V DC and pulsating current values of 400V
Welding Cable Technical Parameters
Nominal Cross Sectional Area (mm²) Quantity/Stranding Diameter (mm) Nominal Sheath Thickness (mm) Total Diameter (mm) Max Conductor Resistance at 20°C (Ω/km) Reference Weight
10 322/0.20 1.8 7.5-9.7 1.91 (YH)
1.95 (YHF)		 146 (No armor)
153.51 (Armor)
16 513/0.20 2 9.2-11.5 1.16 (YH)
1.19 (YHF)		 218.9 (No armor)
230.44 (Armor)
25 798/0.20 2 10.5-13 0.758 (YH)
0.78 (YHF)		 316.6 (No armor)
331.15 (Armor)
35 1121/0.20 2.2 11.5-14.5 0.536 (YH)
0.552 (YHF)		 426 (No armor)
439.87 (Armor)
50 1596/0.20 2.4 13.5-17 0.198 (YH)
0.204 (YHF)		 790 (No armor)
817.52 (Armor)
70 2214/0.20 2.6 17-22 0.161 (YH)
0.164 (YHF)		 1348.25 (No armor)
1392.55 (Armor)
95 2297/0.20 2.8 19-24 0.129 (YH)
0.132 (YHF)		 1678.5 (No armor)
Waterproof Flexible Silicone Rubber Cable with High Temperature Resistance for Industrial Applications
Universal Rubber Sheathed Flexible Cable
Rated Voltage (U0/U) 300/500V; 450/750V
Number of Cores 1, 2, 3, 4, 5, 3 + 1
Nominal Cross-sectional Area (mm²) 0.3-0.5, 0.75-6, 1.5-6, 1.5-400, 2, 3, 4, 5, 1-95, 1-150, 1-25, 1.5-150
Maximum Conductor Temperature 60°C
Environmental Temperature YC type: -40°C; YCW type: >-15°C
Cable Bending Radius Not less than 5 times the outside diameter of the cable
Application Designed for drives, household appliances, portable electrical equipment, and power tools with rated voltage of 450/750V
Waterproof Flexible Silicone Rubber Cable with High Temperature Resistance for Industrial Applications
Waterproof Rubber Sheathed Cable Features
  • Excellent electrical insulation performance under prolonged flooding and high water pressure conditions
  • Superior bending performance for frequent movement applications
  • High-density waterproof rubber compound for maximum protection
Waterproof Rubber Sheathed Cable Specifications
Model JHS; JHSB
Rated Voltage 450/750V; 300/500V
Number of Cores 1, 3, 4, 3 + 1
Nominal Cross-sectional Area (mm²) 1.5, 2.5, 4, 6, 10, 16, 25, 35, 50, 70
Long-term Working Temperature Not exceeding 65°C (Not exceeding 85°C for submersible pump power transmission)
Application Transmission of electrical power from submersible taps at AC voltages of 500 volts and below. Suitable for submersible pumps, coal mines, underwater work, underwater landscape lights, and other processing equipment
Waterproof Flexible Silicone Rubber Cable with High Temperature Resistance for Industrial Applications
Silicone Rubber Cable Features
  • Minimum temperature: Not less than -25°C (Not less than -20°C for silicone rubber control cable)
  • Bending radius: Minimum 10 times cable outer diameter (Unarmored cable minimum 6 times outer diameter)
  • Excellent thermal stability and stable electrical performance in high/low temperature and corrosive environments
  • Flexible structure for easy installation with outstanding anti-aging performance and long service life
Silicone Rubber Cable Applications
  • AC rated voltage 0.6/1KV and below for mobile electrical fixed laying or connecting cable transmission lines
  • Silicone rubber control cables for AC rated voltage 450/750V and below mobile or fixed laying of electrical instrumentation wiring or signal transmission
  • Widely used in metallurgy, electric power, petrochemical, electronics, automotive manufacturing and other industries
Silicone Rubber Cable Specifications
Implementation Standards Flame retardant and fire resistance test GB12666-90
Rated AC Voltage U0/U 0.6/1KV; U0/U 450/750V (Silicone rubber control cables)
Maximum Working Temperature 180°C
Minimum Ambient Temperature Silicone rubber sheath: Fixed laying -60°C, Non-fixed laying -20°C
Characteristics Resistant to heat radiation, cold, high temperature, voltage, acid, alkali, corrosive gases, and waterproof
Brand LINKE Cross Section (mm²) 0.01-500mm²
Wire Gauge (AWG) [e.g., 24AWG, 28AWG] Conductor Tinned Copper /bare copper, based on client's requirements
Insulation material PVC/TPU/Silicone rubber/PE/PP/XLPE/Nylon/other Jacket Material [PVC/PU/Rubber/Braid/etc.]
Certifications RoHS/REACH/UL/CE/IP68/etc Custom Length [e.g., 1m, 3ft, 5m ±5% tolerance]
Cable Type [Medical/Power/Audio/Coaxial/Electrical/Automotive/Energy storage//etc.] Shielding [Shielded/Unshielded/Braid Shield]
Impedance [e.g., 75Ω (for coaxial cables)] Printing/Logo [Text/Label/Logo, max. 20 characters]
Bend Radius [e.g., ≥5× cable diameter] Current Rating [e.g., 5A]
Voltage Rating [e.g., 30V AC/DC] Connector Material [Gold-plated/Nickel-plated/Brass/etc.]
Connectors [e.g., USB Type-C, 3.5mm Jack, RJ45] Jacket XLPE or PE or PVC RUBBER
Delivery Time 7-14 days after confirming the order Colors [Black/White/Red/Custom Pantone/etc.]
temperature Minus-70℃to 350℃(-70℃ ~ 350℃) Package Roll/box/plate/Custom
Supporting Services custom cable, end to end solutions, including precise cutting, crimping and installation of lugs (specify material,e.g.,copper/nickel plated)
Waterproof Flexible Silicone Rubber Cable with High Temperature Resistance for Industrial Applications

Independent Laboratory • Complete Testing Equipment • Full Quality Control

We test every product by strict standards to ensure superior quality and reliable performance.


No. Test Item Test Condition Test Requirement Test Data Result
1 Structure Inspection 1. Comply with wire size table
2. Minimum thickness ≥ 80% of average thickness		 Comply with wire size table Refer to test record Pass
2 Thermal Shock Wind the sample on an iron rod of specified size, place in an aging oven at specified temperature for 1 hour, cool the sample to room temperature for at least 30 minutes, then observe the sample No cracks on the sample surface No cracks Pass
3 Heat Deformation 1. Measure sample thickness (mark measurement position)
2. Place sample and test fixture in aging oven for preheating at specified temperature for 1 hour
3. Place sample under pressure column of test fixture for 1 hour
4. Re-measure sample thickness at the same position		 1. Sample shall not be cracked by pressure column or expose conductor
2. Thickness reduction ≤ 50%		 Refer to test record Pass
4 FT2 Apply a standard flame at a height of 125mm once 1. Flame shall not propagate along its length
2. Flame shall not spread to nearby flammable materials		 Refer to test record Pass
5 Aging 1. Take five sections of 200mm-long sheath
2. Place specimens in aging oven at 158℃ for 168 hours
3. After taking out specimens, place at room temperature 23±5℃ for 16 hours, then test elongation at break and tensile strength		 1. Elongation before aging ≥ 300%, elongation after aging ≥ 80% of that before aging
2. Tensile strength before aging > 1.41kg/mm², tensile strength after aging ≥ 80% of that before aging		 Refer to test record Pass
6 Cold Bend Store sample in low-temperature box at specified temperature for 4 hours, wind sample on iron rod of specified size with specified turns, complete winding within 30 seconds after sample is taken out of low-temperature box No cracks on the sample surface No cracks Pass
7 Conductor Resistance Measure resistance of one-meter core conductor with DC resistance meter At 20℃, resistance of 8AWG ≤ 2.23Ω/km Refer to test record Pass

Linke cable technology (DongGuan) Co. Ltd. concentrate on R&D and

provide professional solutions to the Cable&Wire,especially for the

different industry customers.It contains :


Humanoid robot cable,

AI power cable/data cable,

Semiconductor cable/industrial automatic cable,

Sensor cable,

New energy cable,

Medical beauty wire,

UL wire cable,


Linke Cable has diversified product development capabilities and technical capabilities to support diversified

customer needs. We have obtained the following product authorization:UL 758,CCC,RoHs,REACH,CE; We

have obtained the following quality management system:ISO 9001-2015(All products)；ISO 13485

(Medical apparatus and instruments),IATF 16949(Auto industry)


Waterproof Flexible Silicone Rubber Cable with High Temperature Resistance for Industrial Applications
About Our Company

We maintain a strong R&D team with 6 engineering professionals, each possessing over 10 years of technical expertise in wire and cable solutions. Our quality control department employs 10 specialists who strictly supervise every step from incoming materials to shipping, ensuring 100% product quality for our customers. Our production team consists of more than 50 experienced manufacturing professionals.

Certifications & Quality Assurance

Our products meet stringent quality standards and industry certifications to ensure reliability and performance in demanding applications.

Frequently Asked Questions
Are you a manufacturer or trading company?

We are a professional manufacturer with complete control over the production process from beginning to end. We welcome factory visits and provide pickup service in Shenzhen.

How can I get a sample to test your quality?

Samples are provided free of charge. New clients are expected to cover courier costs.

What's your Minimum order quantity?

Our standard MOQ is 100 meters. Due to the weight of cables, we recommend ordering suitable quantities to optimize freight costs, with sea transportation being the most economical option.

Can I get a discount?

Discounts are available based on order quantity. We can offer competitive pricing and freight arrangements for larger orders.

Does your company accept OEM production?

Yes, we offer OEM services including printing your company name and custom quality cards to promote your brand.
