TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging
TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging
TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging
TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging
TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging
TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging
TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging
TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging
TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging
TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging
TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging
TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging
Specifications
conductor material :
copper/Tinned Copper
rated voltage :
300-600V
insulating materials :
customize:PVC、PE 、XLPE、EPR、SIR
colour :
customize
Place of Origin :
Guangdong, China
Brand Name :
linkecable
MOQ :
1000m
Price :
Negotiable
Packaging Details :
Safe Packaging
Delivery Time :
7-15 days
Payment Terms :
Advance 30% deposit and ship after receiving 70% final payment
Supply Ability :
50000m/day
Certification :
3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949
specifications :
0.1-450mm²
rated temperature :
-60± 200℃
package :
By roll
Current :
DC & AC
type :
insulated
Conductor Type :
Twisted wire
Exterior material :
customize：PVC、PE、LSFOH、silicone rubber
Description
H07bz5-F 3G2.5mm²+2*0.5mm² 450/750V TUV Certified AC EV Charging Cable
Cable Structure Overview
TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging
Construction Specifications
Unit A
Core2C
ConductorTinned Copper
AWG8
Construction (N/mm)168/0.254±0.008
InsulationPVC
Average thickness (mm)0.76
Minimum thickness (mm)0.69
Insulation diameter (mm)5.70±0.20
Unit B
Core6C
ConductorTinned Copper
AWG20
Construction (N/mm)26/0.16±0.008
InsulationPVC
Average thickness (mm)0.38
Minimum thickness (mm)0.33
Insulation diameter (mm)1.75±0.10
Cabling Components
FillerPP rope
SeparatorNon-woven Paper
Overlap≥25%
JacketTPE
Average thickness (mm)1.60
Minimum thickness (mm)1.40
Overall diameter (mm)15.0±0.40
Color Specifications
Unit A: 1. Black 2. Red
Unit B: 3. Blue 4. White 5. Gray 6. Brown 7. Purple 8. Yellow
Jacket color: Orange
Product Images
TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging

TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging

BrandLINKECross Section (mm²)0.01-500mm²
Wire Gauge (AWG)[e.g., 24AWG, 28AWG]ConductorTinned Copper /bare copper, based on client's requirements
Insulation materialPVC/TPU/Silicone rubber/PE/PP/XLPE/Nylon/otherJacket Material[PVC/PU/Rubber/Braid/etc.]
CertificationsRoHS/REACH/UL/CE/IP68/etcCustom Length[e.g., 1m, 3ft, 5m ±5% tolerance]
Cable Type[Medical/Power/Audio/Coaxial/Electrical/Automotive/Energy storage//etc.]Shielding[Shielded/Unshielded/Braid Shield]
Impedance[e.g., 75Ω (for coaxial cables)]Printing/Logo[Text/Label/Logo, max. 20 characters]
Bend Radius[e.g., ≥5× cable diameter]Current Rating[e.g., 5A]
Voltage Rating[e.g., 30V AC/DC]Connector Material[Gold-plated/Nickel-plated/Brass/etc.]
Connectors[e.g., USB Type-C, 3.5mm Jack, RJ45]JacketXLPE or PE or PVC RUBBER
Delivery Time7-14 days after confirming the orderColors[Black/White/Red/Custom Pantone/etc.]
temperatureMinus-70℃to 350℃(-70℃ ~ 350℃)PackageRoll/box/plate/Custom
Supporting Services\multicolumn {3}{l}{custom cable, end to end solutions, including precise cutting, crimping and installation of lugs (specify material,e.g.,copper/nickel plated)

TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging TUV Certified 450/750V EV Charging Cable with Tinned Copper Conductor for AC Charging
Quality Certifications

Our products meet the following international standards:
UL1007, UL1185, UL1672, UL10070, UL10483, UL1015, UL1569, UL10012, UL10269 (Single conductor, thermoplastic insulation)
UL2095, UL2129, UL2468, UL2586, UL2725, UL20233, UL20280, UL20963, UL2103, UL2463, UL2517, UL2587
UL2835, UL20276, UL20549, UL21198, 2104, UL2464, UL2576, UL2661, UL2919, UL20279, UL20886, UL21664
ISO9001 and ISO13485, TS16949
CNR - Appliance Wiring Material
Extruded PVC Insulated Single, rated 105ºC, 1000V, Class I, Group A, B, or AB, FT1 and/or FT2
Extruded PVC Non-integral Jacketed Cable, rated 105°C, 1000V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
Extruded TPU Non-integral Jacketed Cable, rated 80°C, 300V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2

Frequently Asked Questions
Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.
How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.
What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.
Can I get a discount?
It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.
Does your company accept OEM production?
Yes, we can print your company name, and we even customize the quality card to promote your company.
