Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
Specifications
Core :
Multiple
rated temperature :
-60± 200℃
Model NO. :
UL1185
Material Shape :
Round Wire
Conductor Material :
Copper
Conductor Type :
Twisted wire
Exterior material :
customize：PVC、PE、LSFOH、silicone rubber
Sheath Material :
PVC
Place of Origin :
Guangdong, China
Brand Name :
Linke
MOQ :
1000m
Price :
Negotiable
Packaging Details :
Safe packaging
Delivery Time :
7-15 days
Payment Terms :
Advance payment+final payment upon shipment
Supply Ability :
50000m/day
insulating materials :
customize:PVC、PE 、XLPE、EPR、SIR
 payment method :
Initial Payment Full Payment
conductor material :
copper/Tinned Copper
specifications :
0.1-450mm²
Certification :
3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949
Description
PVC Insulated Fire Resistant Electrical Wire 18AWG 300V Power Signal Cable
Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
UL1185 Single-Core Insulated Wire Specifications
  • Rated temperature: 80°C
  • Rated voltage: 300 volts
  • Conductors: 30-4/0 AWG solid or stranded bare or tinned copper wire
  • Lead-free PVC insulation
  • Bare or tinned copper wire wrapped for shielding
  • Lead-free PVC coating, compliant with RoHS regulations
  • Passed UL VW-1 vertical flame resistance test
  • Reference standards: UL 758 and UL 1581
Application
Internal wiring of general electronic and electrical equipment
Construction Specifications
Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
P/N Conductor AWG Conductor No./mm Insulation Material Insulation Thickness/mm Spiral Shield No./mm Jacket Material Jacket Thickness/mm Overall Diameter/mm
1185-22 22 17/0.160 PVC 0.38 42/0.12 PVC 0.38 2.70
1185-20 20 21/0.180 PVC 0.38 47/0.12 PVC 0.38 2.90
1185-18 18 34/0.180 PVC 0.38 55/0.12 PVC 0.38 3.15
1185-16 16 26/0.254 PVC 0.38 61/0.12 PVC 0.38 3.50
Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
Brand LINKE Cross Section (mm²) 0.01-500mm²
Wire Gauge (AWG) [e.g., 24AWG, 28AWG] Conductor Tinned Copper /bare copper, based on client's requirements
Insulation material PVC/TPU/Silicone rubber/PE/PP/XLPE/Nylon/other Jacket Material [PVC/PU/Rubber/Braid/etc.]
Certifications RoHS/REACH/UL/CE/IP68/etc Custom Length [e.g., 1m, 3ft, 5m ±5% tolerance]
Cable Type [Medical/Power/Audio/Coaxial/Electrical/Automotive/Energy storage//etc.] Shielding [Shielded/Unshielded/Braid Shield]
Impedance [e.g., 75Ω (for coaxial cables)] Printing/Logo [Text/Label/Logo, max. 20 characters]
Bend Radius [e.g., ≥5× cable diameter] Current Rating [e.g., 5A]
Voltage Rating [e.g., 30V AC/DC] Connector Material [Gold-plated/Nickel-plated/Brass/etc.]
Connectors [e.g., USB Type-C, 3.5mm Jack, RJ45] Jacket XLPE or PE or PVC RUBBER
Delivery Time 7-14 days after confirming the order Colors [Black/White/Red/Custom Pantone/etc.]
temperature Minus-70℃to 350℃(-70℃ ~ 350℃) Package Roll/box/plate/Custom
Supporting Services custom cable, end to end solutions, including precise cutting, crimping and installation of lugs (specify material,e.g.,copper/nickel plated)
Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable
Quality CertificationsOur products meet the following international standards:
UL1007, UL1185, UL1672, UL10070, UL10483, UL1015, UL1569, UL10012, UL10269 (Single conductor, thermoplastic insulation)
UL2095, UL2129, UL2468, UL2586, UL2725, UL20233, UL20280, UL20963, UL2103, UL2463, UL2517, UL2587
UL2835, UL20276, UL20549, UL21198, 2104, UL2464, UL2576, UL2661, UL2919, UL20279, UL20886, UL21664
ISO9001 and ISO13485, TS16949
CNR - Appliance Wiring Material
Extruded PVC Insulated Single, rated 105ºC, 1000V, Class I, Group A, B, or AB, FT1 and/or FT2
Extruded PVC Non-integral Jacketed Cable, rated 105°C, 1000V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
Extruded TPU Non-integral Jacketed Cable, rated 80°C, 300V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
Frequently Asked Questions
Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.
How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.
What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.
Can I get a discount?
It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.
Does your company accept OEM production?
Yes, we can print your company name, and we even customize the quality card to promote your company.
