UL2651 Shielded Flat Ribbon Cable with TPU Insulation and Copper Conductor for Flame Retardant Applications
UL2651 Shielded Flat Ribbon Cable with TPU Insulation and Copper Conductor for Flame Retardant Applications
UL2651 Shielded Flat Ribbon Cable with TPU Insulation and Copper Conductor for Flame Retardant Applications
UL2651 Shielded Flat Ribbon Cable with TPU Insulation and Copper Conductor for Flame Retardant Applications
UL2651 Shielded Flat Ribbon Cable with TPU Insulation and Copper Conductor for Flame Retardant Applications
UL2651 Shielded Flat Ribbon Cable with TPU Insulation and Copper Conductor for Flame Retardant Applications
UL2651 Shielded Flat Ribbon Cable with TPU Insulation and Copper Conductor for Flame Retardant Applications
UL2651 Shielded Flat Ribbon Cable with TPU Insulation and Copper Conductor for Flame Retardant Applications
UL2651 Shielded Flat Ribbon Cable with TPU Insulation and Copper Conductor for Flame Retardant Applications
UL2651 Shielded Flat Ribbon Cable with TPU Insulation and Copper Conductor for Flame Retardant Applications
Specifications
Exterior material :
customize：PVC、PE、LSFOH、silicone rubber
Certification :
3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949
Range of Application :
Flame Retardant
Application :
Overhead, Heating, Underground
Conductor Type :
Twisted wire
Production :
Manufacture
Voltage :
Low Voltage
conductor material :
copper/Tinned Copper
Customization :
Available
rated temperature :
-60± 200℃
Material Shape :
Flat Wire
rated voltage :
300-600V
Certification1 :
UL
Type :
Insulated
Model NO. :
SHIELD FLAT CABLE
Return&refunds :
You can apply for a refund up to 30 days after receipt of the products.
colour :
customize
Insulation Material :
TPU
specifications :
0.1-450mm²
Place of Origin :
Guangdong, China
Brand Name :
Linke
MOQ :
1000m
Price :
Negotiable
Packaging Details :
According to requirement
Delivery Time :
7-15 days
Supply Ability :
50000m/day
Sheath Material :
PVC
insulating materials :
customize:PVC、PE 、XLPE、EPR、SIR
Core :
Multiple
Conductor Material :
Copper
Transport Package :
Carton
Description
Flat Data Signal Video Audio Ribbon Cable UL2651 Shielded with TPU Insulation
This shielded flat ribbon cable meets UL2651 specifications and features TPU insulation, designed for reliable data, signal, video, and audio transmission in demanding industrial applications.
Technical Specifications
UL Specification Maximum Use Temperature Maximum Operating Voltage Number of Conductors Conductor Thickness (mm±0.05) Width (Wmm±0.2)
2651 105ºC 300V 8 28 AWG
7/0.127		 0.90 10.16
9 28 AWG
7/0.127		 0.90 11.43
10 28 AWG
7/0.127		 0.90 12.70
12 28 AWG
7/0.127		 0.90 15.24
14 28 AWG
7/0.127		 0.90 17.78
16 28 AWG
7/0.127		 0.90 20.32
20 28 AWG
7/0.127		 0.90 25.40
26 28 AWG
7/0.127		 0.90 33.02
30 28 AWG
7/0.127		 0.90 38.10
34 28 AWG
7/0.127		 0.90 43.18
40 28 AWG
7/0.127		 0.90 50.80
50 28 AWG
7/0.127		 0.90 63.50
60 28 AWG
7/0.127		 0.90 76.20
64 28 AWG
7/0.127		 0.90 81.28
UL2651 Shielded Flat Ribbon Cable with TPU Insulation and Copper Conductor for Flame Retardant Applications UL2651 Shielded Flat Ribbon Cable with TPU Insulation and Copper Conductor for Flame Retardant Applications UL2651 Shielded Flat Ribbon Cable with TPU Insulation and Copper Conductor for Flame Retardant Applications UL2651 Shielded Flat Ribbon Cable with TPU Insulation and Copper Conductor for Flame Retardant Applications
Quality Certifications
  • ISO9001 and ISO13485, TS16949 certified
  • CNR - Appliance Wiring Material certification
  • Extruded PVC Insulated Single, rated 105ºC, 1000V, Class I, Group A, B, or AB, FT1 and/or FT2
  • Extruded PVC Non-integral Jacketed Cable, rated 105ºC, 1000V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
  • Extruded TPU Non-integral Jacketed Cable, rated 80ºC, 300V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
Frequently Asked Questions
Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.
How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.
What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.
Can I get a discount?
It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.
Does your company accept OEM production?
Yes, we can print your company name, and we even custom the quality card to promote your company.
