Pulse J0026D21B Compatible LINK-PP LPJ0026ABNL 10/100 Base-T Tab Down Green/Yellow Led Single Port 8P8C RJ45 PCB Socket
Pulse J0026D21B Compatible LINK-PP LPJ0026ABNL 10/100 Base-T Tab Down Green/Yellow Led Single Port 8P8C RJ45 PCB Socket
Pulse J0026D21B Compatible LINK-PP LPJ0026ABNL 10/100 Base-T Tab Down Green/Yellow Led Single Port 8P8C RJ45 PCB Socket
Pulse J0026D21B Compatible LINK-PP LPJ0026ABNL 10/100 Base-T Tab Down Green/Yellow Led Single Port 8P8C RJ45 PCB Socket
Pulse J0026D21B Compatible LINK-PP LPJ0026ABNL 10/100 Base-T Tab Down Green/Yellow Led Single Port 8P8C RJ45 PCB Socket
Pulse J0026D21B Compatible LINK-PP LPJ0026ABNL 10/100 Base-T Tab Down Green/Yellow Led Single Port 8P8C RJ45 PCB Socket
Pulse J0026D21B Compatible LINK-PP LPJ0026ABNL 10/100 Base-T Tab Down Green/Yellow Led Single Port 8P8C RJ45 PCB Socket
Pulse J0026D21B Compatible LINK-PP LPJ0026ABNL 10/100 Base-T Tab Down Green/Yellow Led Single Port 8P8C RJ45 PCB Socket
Pulse J0026D21B Compatible LINK-PP LPJ0026ABNL 10/100 Base-T Tab Down Green/Yellow Led Single Port 8P8C RJ45 PCB Socket
Pulse J0026D21B Compatible LINK-PP LPJ0026ABNL 10/100 Base-T Tab Down Green/Yellow Led Single Port 8P8C RJ45 PCB Socket
Specifications
Brand Name :
LINK-PP
Model Number :
LPJ0026ABNL
Certification :
UL,ROHS,Reach,ISO
Place of Origin :
Guangdong,China
Compatible :
Pulse
Competitor P/N :
J0026D21B
Compatible Brands :
Pulse
Shield EMI Tabs :
YES
Temperature :
0℃ to 70℃
Application - LAN :
ETHERNET (NON PoE)
Reviews :
11
N.W/pcs :
0.007kg
Package :
Tray
SPQ :
50pcs
Qty/carton :
1200pcs
Carton size :
32*30*31cm
G.W/carton :
8.5kg
Description

Pulse J0026D21B Compatible LINK-PP LPJ0026ABNL 10/100 Base-T 8P8C RJ45 PCB Socket for Smart Meters and Satellite (Single Port, Tab Down, Green/Yellow Led)


The LPJ0026ABNL supports speed 10/100 Base-T, It is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to support application, such as Smart Meters, Router, Automation and Network Firewall.


LINK-PP Part Number:
 LPJ0026ABNL
 Pulse Part Number J0026D21B
Part Status
 Active Connector Type
 Jack
Number of Positions/Contacts
 8p8c (RJ45, Ethernet) Application-Lan
 Ethernet(NoN PoE)
Number of Ports
1x1 PortSpeed
10/100 Base-T
Latch
DownCores per Port
5
Orientation
90° Angle (Right)PCB Mount Angle

THT Solder

Shield EMI Tabs
WithLED Option

Green/Yellow

PCB
FR4PCB Retaining Post

T POST

Package Height (Inches/mm)
0.528/13.40
Package Length (Inches/mm)

0.839/21.30

Package Width (Inches/mm)
0.626/15.90
Temperature
0℃ TO 70℃
Bst Circuit
YesAutomDX

YES

Diodes
NoContact Mating Area Plating

GOLD 6u"/15u"/30u"

Turns Ratio RX/TX
1CT:1CTConfiguration RX/TX

T,C
