Specifications
Model Number :
LYAPF1-20
Certification :
CE, ISO, GMP
Place of Origin :
China(Thailand available soon)
MOQ :
1 unit
Price :
150,000-300,000USD per piece
Payment Terms :
D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1 unit per month
Delivery Time :
120-180 work days normally
Packaging Details :
carton, wood carton, pallets
Application :
Chemicals, vaccines and biologics
Function :
Vials Washing, Sterilization, Filling, Plugging, Capping
Filling Type :
Automatic
Capacity :
30000 ampoules per hour
Complaince :
CE, ISO, GMP
Materials :
316 SS
Pump Systerm :
adaptive servo-driven
Machine Name :
Vial Filling Line
Filling Volume :
2-30ml
Filling Liquid Type :
Vaccine
Output Capacity :
6000-26000 BPH
Vials Material :
Glass
Filling Accuracy :
+/-0.5%
Breakage Rate :
<0.5%
Nitrigon Filling :
Yes
CIP/SIP :
Yes
Oven Cooling Style :
Water Cooling
Plugging Style :
Half
Capping Head :
Multi
LAF :
Yes
Description

High-Speed Ampoule Filling Line with Hermetic Sealing, 30,000 Ampoules per Hour, High Precision, ISO 14644 Class 5 Certified

Revolutionize Your Pharma Production with the Next-Gen Ampoule Filling Line

Unmatched Speed & Accuracy
Engineered for high-throughput manufacturing, our ampoule filling line achieves 30,000+ ampoules per hour with ±0.5% dosing precision — ideal for critical injectables like vaccines and biologics. The adaptive servo-driven pump system dynamically adjusts viscosity variations (1-2000cP), eliminating underfills/overfills even with heat-sensitive fluids.

Hermetic Sealing: Zero-Contamination Guarantee
Featuring laser seam welding technology, this line creates airtight seals that exceed ISO 15378 integrity standards. Perfect for oxygen-sensitive formulations (e.g., mRNA vaccines or monoclonal antibodies), it reduces oxidation risks by 99.7% compared to traditional flame sealing.

Smart Compliance for Global Markets
● Real-time Aseptic Monitoring: Integrated particle counters and microbial air samplers ensure ISO 5 cleanroom equivalence during operation
● FDA/EMA Data Integrity: Audit-ready electronic batch records and 21 CFR Part 11-compliant HMI
● Rapid Changeover: Tool-free adjustments handle 1-20ml ampoules in ≤15 minutes — a 60% time saving for multi-product facilities

Sustainability Edge
The energy-recovery sealing module cuts power consumption by 40%, while 316L stainless steel contact parts withstand CIP/SIP cycles up to 135°C — crucial for Middle Eastern plants facing extreme heat.

Main Spec:

technical parameters
　
product model LYQCL100+LYASMR
620/43+LYAGF8
size range 1-20ml national standard ampoules
Output(1-2ml) 16,000-30,000pcs/h
Output(5-10ml) 8000-12000pcs/h
Output(20ml) 5000-7000pcs/h
Clarity ＞99%
Breakage rate ≤1%(whole line)
Filling Precision ±0.5-2%(according to pharmacopoeia standard)
Water Consumption and Pressure 0.2-0.4Mpa / 0.6-1.0m³/h
Cleaning CA Consumption and Pressure 0.3-0.6Mpa / 35-80m³/h 0.3-1.0Mpa / 35-80m³/h
Sealed gas Gas(liquefied gas)+oxygen, oxyhydrogen generation gas, natural gas
Oxygen consumption 0.2-0.3Mpa,1.2-1.5m³/h
Gas consumption 0.1-0.3Mpa,1.5-2.5m³/h
Exhaust volume 3500-4100m³/h
Net weight 7800(kg)
Total power around 72kw 380V 50HZ
Outline size around 9940x2260x2445mm

High-Speed Ampoule Filling Line with Hermetic Sealing, 30,000 Ampoules per Hour, High Precision, ISO 14644 Class 5 CertifiedHigh-Speed Ampoule Filling Line with Hermetic Sealing, 30,000 Ampoules per Hour, High Precision, ISO 14644 Class 5 CertifiedHigh-Speed Ampoule Filling Line with Hermetic Sealing, 30,000 Ampoules per Hour, High Precision, ISO 14644 Class 5 CertifiedHigh-Speed Ampoule Filling Line with Hermetic Sealing, 30,000 Ampoules per Hour, High Precision, ISO 14644 Class 5 Certified

Why Choose This Line?
✅ 3-Year Performance Warranty with 24/7 global technical support
✅ Modular design for future upgrades (e.g., robotic palletizing)
✅ Halal-compliant configurations available for MENA regions
