Specifications
Brand Name :
Lingyao
Model Number :
LYAPL1-20-I
Certification :
CE, ISO, GMP
Place of Origin :
China
MOQ :
1 unit
Price :
USD 150,000-350,000 per unit
Payment Terms :
D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1 unit per month
Delivery Time :
180 work days
Packaging Details :
carton, wood carton, pallets
Machine Name :
Ampoule Filling Line
Function :
Ampoules Washing, Sterilization, Filling, Sealing
Filling Volume :
1-20ml
Filling Liquid Type :
Tropical Disease Injectable
Max Output Capacity :
26000 BPH
Ampoules Material :
Glass
Filling Accuracy :
+/-0.5%
Breakage Rate :
<0.5%
Nitrigon Filling :
Yes
CIP/SIP :
Yes
Oven Cooling Style :
Water Cooling
LAF System :
Yes
Description

Ampoule Filling Line for Tropical Disease Injectable GMP Certified, 1-20ml Precision with 26,000 BPH Efficiency

Ideal for Herbal Extracts, Vaccines & Sensitive Biologics

Revolutionize Your Production with Unmatched Sterility & Speed
This GMP-certified ampoule filling line is engineered for high-demand tropical disease injectables, combining precision and durability to handle heat-sensitive herbal extracts, antiviral agents, and biologics. With a low breakage rate (<0.1%) and water-cooled oven technology, it thrives even in high-temperature environments common to tropical regions.

Core Features at a Glance
✅ All-in-One Automation: Seamlessly integrates ampoule washing, drying, sterilization, filling (1-20ml), and sealing – perfect for heat-labile formulations like antimalarial infusions or antiparasitic extracts.
✅ 26,000 BPH High Speed: Maximize output for urgent vaccine campaigns or epidemic response.
✅ SIP/CIP & LAF System: Ensures ISO 5-grade aseptic conditions, critical for WHO-compliant tropical disease drug production.
✅ Herbal Extract Optimization: Gentle handling prevents degradation of plant-based actives (e.g., artemisinin derivatives).

Ampoules Filling Line Spec:

technical parameters
　
product model LYQCL100+LYASMR
620/43+LYAGF8
size range 1-20ml national standard ampoules
Output(1-2ml) 16000-22000pcs/h
Output(5-10ml) 8000-12000pcs/h
Output(20ml) 5000-7000pcs/h
Clarity ＞99%
Breakage rate ≤1%(whole line)
Filling Precision ±0.5-2%(according to pharmacopoeia standard)
Water Consumption and Pressure 0.2-0.4Mpa / 0.6-1.0m³/h
Cleaning CA Consumption and Pressure 0.3-0.6Mpa / 35-80m³/h 0.3-1.0Mpa / 35-80m³/h
Sealed gas Gas(liquefied gas)+oxygen, oxyhydrogen generation gas, natural gas
Oxygen consumption 0.2-0.3Mpa,1.2-1.5m³/h
Gas consumption 0.1-0.3Mpa,1.5-2.5m³/h
Exhaust volume 3500-4100m³/h
Net weight 7800(kg)
Total power around 72kw 380V 50HZ
Outline size around 9940x2260x2445mm

Ampoule Filling Line for Tropical Disease Injectable GMP Certified, 1-20ml Precision with 26,000 BPH Efficiency

Ampoule Filling Line for Tropical Disease Injectable GMP Certified, 1-20ml Precision with 26,000 BPH EfficiencyAmpoule Filling Line for Tropical Disease Injectable GMP Certified, 1-20ml Precision with 26,000 BPH Efficiency

Why It Stands Out in Tropical Pharma?

  • Climate-Adaptive Design: Water-cooled chambers maintain stable temperatures during sterilization, preventing glass stress cracks in humid conditions.
  • Halal Compliance Ready: Material traceability and alcohol-free CIP options align with MENA market requirements.
  • Multi-Purpose Flexibility: Switch seamlessly between viscous herbal oils (neem, turmeric) and low-viscosity vaccines.

Applications Spotlight
