High SPL Plywood Loudspeaker Line Array Sound System
High SPL Plywood Loudspeaker Line Array Sound System
High SPL Plywood Loudspeaker Line Array Sound System
High SPL Plywood Loudspeaker Line Array Sound System
High SPL Plywood Loudspeaker Line Array Sound System
High SPL Plywood Loudspeaker Line Array Sound System
Specifications
Brand Name :
NOVA acoustics
Model Number :
SW-218 (B22)
Certification :
CE, RoHS, SGS
Place of Origin :
Guangzhou,China
MOQ :
8pcs
Payment Terms :
T/T, Western Union
Supply Ability :
500pcs per year
Delivery Time :
10-15 working days after get payment
Packaging Details :
Hard packing carton or Flightcase at extra cost
Description

High SPL Plywood loudspeaker Line Array Sound System 2 x 18" Horn Loaded 1600W Subwoofer For Living Event And Show

Quick Details:

Birtch plywood cabinet,Polyure painting, high quality sound. high power handling capability, punch Bass.

Description:

The B22 subwoofer is a high performance subwoofer designed for ground stacked applications,SW-B22 subwoofer employs two immensely powerful long excursion 18” transducers which built into a bandpass horn cabinet design. SW-B22 subwoofer is designed for any large format sound reinforcement application with high sound pressure levels and extended frequency.

The Cabinet of SW-218 is made from high class birch plywood with Polyure waterproofing paint. The rigid metal grill with acoustically transparent foam could protect the front of SW-B22 subwoofer cabinet.

Features:

Components 18"x2 long excursion Neodymium woofer

Dispersion Omni directional

Max SPL 140dB

Russian Birch plywood cabinet

Polyure waterproofing painting

Application:

1) Large scale outdoor sound reinforcement

2) Theater Sound Reinforcement
3) Live Sound Reinforcement
4.) Corporate Events
5) Fixed Installations

Specification:

SW-218 (B22 Horn Loaded Subwoofer)
System data
Frequency response 35 Hz - 220 Hz
Sensitivity(1W/1M): 104 dB
Max. SPL: 138 dB
Loudspeaker data
Configuration High performance subwoofer intended for ground stacked applications
Nominal impedance 4 Ω
Power handling capacity (RMS/peak 10 ms) 1600/6400 W
Components 2 x 18" driver
Dimensions / weight
Dimensions (H x W x D) 585 x 1160 x 920 / 1046 mm
Weight 106 kg (234 lb)

NOVA products:

High SPL Plywood Loudspeaker Line Array Sound System

High SPL Plywood Loudspeaker Line Array Sound System

Quality is our culture.
With us your business in safe, your money in safe.


We can offer you:

Competitive advantage products

Factory price

Confidentiality agreement

Quality assurance contract

After-sales service 24*7

High SPL Plywood Loudspeaker Line Array Sound System
