Specifications
Brand Name :
ULS
Model Number :
FBS Series
Certification :
RoSH; REACH; ISO9001:2015
Place of Origin :
China
MOQ :
1unit
Price :
USD, RMB, EUR
Payment Terms :
D/P, T/T, Western Union, MoneyGram
Supply Ability :
As per your demand
Delivery Time :
3~7 working days for sample
Packaging Details :
carton package with foam
Material :
Cast steel
Block Type :
Flange Type; Square Type; Square Type (Low);
Block :
Standard Block
Load Type :
Heavy Load
Rail Lenghth :
140 to 4000mm
Rail Width :
45mm
Distance from the Edge to the Center of the First Hole (from Left) :
22.5mm
Rail :
Standard rail
Heavy Preload :
0.10 ~ 0.12C
Light Preload :
0 ~ 0.02C
Medium Preload :
0.05 ~ 0.07C
Type of Rail :
Parallel Rail or Single Rail
Description

45mm Linear Guideway Cnc Linear Rail For Plasma Cutting Machine Parts

Linear Rail & Guide Block with High Punctuality, High Rigidity, Interchangeability:

Linear guideway can be divided into three types: roller linear guides, cylindrical linear guides, and ball linear guides. Linear guides are uesed for high-precision or high-speed linear reciprocating motion, and can bear a certain torque, and can realize high-precision linear motion under high load. According to the nature of friction, linear motion guides can be divided into sliding friction guides, rolling friction guides, elastic friction guides, fluid friction guides, etc.

The FBS series linear guideways are designed with load capacity and rigidity higher than other similar products with circular-arcgroove and structure optimization. It features equal load ratings in the radial, reverse radial and lateral directions, andself-aligning to absorb installation-error. Thus, the HG series linear guideways can achieve a long life with high speed, highaccuracy and smooth linear motion.

Linear bearings are mainly used in automated machinery, such as machine tools, bending machines, laser welding machines, etc. of course, linear bearings and linear shafts are used together. For example, linear guides are mainly used in mechanical structures with relatively high precision requirements. There is no intermediate medium between the moving elements and fixed elements of linear guides, but rolling steel balls are used.

PARAMETERS
Model Size 15mm, 20mm, 23mm, 28mm, 34mm, 45mm, 53mm, 63mm
Load Type Heavy load linear guide rail
Block Mounting Mounting from top
Rail Mounting Type Mounting from botton or mounting from top
No. of Blocks per Rail As per your request
Rail length 60mm above
Dust Protection ZZ - End seal, bottom seal and scraper
