Flexible Sealed Lead Acid Battery High Discharge Rate 51.3 Kg  2V 800AH
Flexible Sealed Lead Acid Battery High Discharge Rate 51.3 Kg  2V 800AH
Specifications
Place of Origin :
China
Brand Name :
HRESYS
Certification :
CE
MOQ :
10 Pcs
Price :
Negotiable
Packaging Details :
Box/carton(standard package)
Delivery Time :
30 DAYS
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1800000 PCS/YEAR
Model Number :
VHR 2GT800
Product Name :
2 V Lead-acid Batteries
Capacity :
800 Ah
Float Charge Voltage :
2.25 V/cell @25℃
Weight :
51.3 kg (113.1 lbs)
Application :
General Use
Nominal Voltage (V) :
2
Internal Resistance :
Approx. 0.28mOhm (fully charged @20℃)
Dimension :
L382mm x W170mm x H340mm
Description

2 V 800 AH Top Terminal VRLA AGM Battery for General Use , L382mm x W170mm x H340mm

  • Product Overview

HRESYS General purpose Valve Regulated Lead Acid AGM batteries,ranging from 200Ah to 3000Ah. With advanced manufacturing technique and industry scale, GT Series delivers high energy density and high reliability performance, highly suited for UPS systems, security and alarm systems, telecommunication, CATV, emergency light systems, and other backup applications.

  • Features and Benefits​
    • 12+ years design floating life at 25°C (77°F)
    • Maintenance-free operation and non-leakage
    • Standard sizes for general purpose
    • Flexible design for multiple installation space
    • Self-regulating pressure relief valve with flame arrester

  • Applications
    • Uninterrupted Power Supply(UPS)
    • Emergency Power Supply
    • Electric Tools and Toys
    • Cable Television

Flexible Sealed Lead Acid Battery High Discharge Rate 51.3 Kg  2V 800AH

  • Complied standards
    • IEC 60896-21/22
    • GB/T 19638
    • JIS C8704
    • BS6290 part 4

  • Management and Product Certificates
    • ISO9001:2015
    • ISO14001:2015
    • OHSAS18001:2007
    • CE Certificate

  • Product Specification​
Nominal Voltage (V) 2
Designed Floating Life (25℃) 12 Years
Nominal Capacity (25℃) 800 Ah@ C10 (to 1.80Vpc)
Dimension (mm) L382mm x W170mm x H340mm
Approx. Weight 51.3 kg (113.1 lbs)
Terminal Type Female Copper Insert M8
Internal Resistance Approx. 0.28mOhm (fully charged @20℃)
Max. Charge Current 200 A
Max. Discharge Current(5S) 3200 A
Short Circuit Current 9000 A
Self Discharge Approx. 2.5% per month @ 20℃
Ambient Temperature Discharge: -20~55°C
Charge: -20~50 C
Storage: -20~45 C
Float Charge Voltage 2.25V/cell@25℃
Equalize Charge Voltage 2.35V/cell@25℃
Container Material ABS(UL94-V0 optional)

  • Battery Dimension

Flexible Sealed Lead Acid Battery High Discharge Rate 51.3 Kg  2V 800AH

  • Performance Curves

Flexible Sealed Lead Acid Battery High Discharge Rate 51.3 Kg  2V 800AH
