Specifications
Brand Name :
DZ
Model Number :
DZH1-10
Certification :
CE
Place of Origin :
Shanghai,China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Delivery Time :
5-8 work days
Product Name :
Hydraulic Cargo Lift
Type :
Single Guide Rail
Load Capacity :
1000KG
Platform Size :
1.2m x 1.5m
Lifting Height :
10m
Lifting Speed :
4-5m/min
Motor Power :
3KW
Lift Drive / Actuation :
Hydraulic
Power Supply :
220/240/380/415V
Application :
Factory,Workshop,Warehouse,etc
Description

10m 1000kg Guide Rail Freight Elevator Vertical Hydraulic Cargo Lift

Standard features:

  • Commercial and industrial applications
  • 2 post design
  • Standard Max. 500kg and 1000kg loading capacity
  • Upper and lower landing limits
  • Upper safety limit
  • 24V DC safety control circuit
  • Outwards opening railings with interlock*1M height
  • Digital control panel on each landing stop
  • Manual lower down valve when power off
  • Explosive-proof valve
  • 4-5m/min. Lifting speed, down speed adjustable
  • 200mm minimum pit
  • 5 year warranty on main structural components (indoor use)
  • 1 year warranty electrical components

Description:

Warehouse two post cargo lift is a machine to lift goods vertically in a safe way. Persons are not allowed on the lift, only for loading and unloading. Kind of easy lifts require special safety measures, the cargo lift (goods lifts) can custom made available, for indoor or outdoor use. Cargo lift belongs to materials handle equipment, which is equipped with electrical control system. It is driven by hydraulic pump station. Such kind of cargo lift is suitable for both light goods and heavy materials.

Specifications:

MODEL CAPACITY PLATFORM SIZE (W*D) LIFTING HEIGHT PIT (W*L*D) MOTOR POWER POWER SUPPLY (V)
DZH0.5-3 500KG 1000X1000MM 3000MM 1300*1160*200MM 2.2KW 220/240/380/415
DZH0.5-5 500KG 1000X1000MM 6000MM 1300*1160*200MM 2.2KW 220/240/380/415
DZH0.5-7 500KG 1000X1000MM 8000MM 1300*1160*200MM 3KW 220/240/380/415
DZH0.5-9 500KG 1000X1000MM 10000MM 1300*1160*200MM 3KW 220/240/380/415
DZH1-3 1000KG 1200X1500MM 3000MM 1350*1660*300MM 3KW 220/240/380/415
DZH1-4 1000KG 1200X1500MM 4000MM 1350*1660*300MM 3KW 220/240/380/415
DZH1-5 1000KG 1200X1500MM 5000MM 1350*1660*300MM 3KW 220/240/380/415
DZH1-6 1000KG 1200X1500MM 6000MM 1350*1660*300MM 3KW 220/240/380/415
DZH1-7 1000KG 1200X1500MM 7000MM 1350*1660*300MM 3KW 220/240/380/415
DZH1-8 1000KG 1200X1500MM 8000MM 1350*1660*300MM 3KW 220/240/380/415
DZH1-9 1000KG 1200X1500MM 9000MM 1350*1660*300MM 3KW 220/240/380/415
DZH1-10 1000KG 1200X1500MM 10000MM 1350*1660*300MM 3KW 220/240/380/415

Applications:

Cargo lift is widely used in indoor or outdoor places of the buildings and warehouses to lift goods or pallets between floors.

10m Two Post Cargo Lift 1 Ton Vertical Cargo Lift Warehouse Cargo Elevator10m Two Post Cargo Lift 1 Ton Vertical Cargo Lift Warehouse Cargo Elevator10m Two Post Cargo Lift 1 Ton Vertical Cargo Lift Warehouse Cargo Elevator

FAQ:

1. Can you customize product ?

Yes, of course. we have a lot of experienced engineers,They can design products according to customer's requirement.

2. How can you ensure your quality?

Before the delivery, every products will be tested. You are also warmly welcomed to come to our factory for inspection.

3. What is your delivery & after-sales service?

The delivery is according to order qty . We can answer user's question and solve their problem in 24 hrs per each day and give full technical support in time to all of our products.

4.How long will it take you to ship the goods?

It depends on the product you need, but we guarantee to ship it as soon as possible. Usually in 5-10 days.

5.What kinds of payment you accept?

We usually accept T/T, L/C, etc. If you prefer other payments terms, please feel free to discuss with us.
