Specifications
Brand Name :
KAD
Model Number :
CDD07B
Certification :
CE/ISO9001
Place of Origin :
China
MOQ :
1
Price :
$1791
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
50units/month
Delivery Time :
7work days
Packaging Details :
iron pallet +plastic film
Model NO. :
CDD07B
Load Capacity :
1-1.5t
Load Center :
500mm
Lift Height :
1600mm
Battery Capacity :
24V/210ah
Fork Size :
1220*100*40mm
Ground Clearance :
30mm
Turning Radius :
1500mm
Driving Speed :
4km/h
Gradient :
3°/5°
Driving Motor :
0.8KW
Lifting Motor :
0.8KW
Tyre Size :
300/250mm
Overall Size :
1603*852*1155mm
Weight :
266kg
Description
Electric Self Loading Stacker 500kg 1000kg Portable Design for Truck Loading

The wide-view mast and smooth vehicle shape, with multi-curved cover parts, unrestricted vision and improved working efficiency; the H-channel steel mast is resistant to bending and torsion, strong and durable, ensuring the vehicle's load capacity; the maintenance-free AC motor minimizes maintenance costs; the standard integrated handle integrates multiple functions for quick and easy operation; the front cover is easy to disassemble and various components are centrally arranged to make maintenance faster and smoother.
advantage:
1.Folding reduces the space occupied by the carriage and increases the cargo carrying capacity of the truck.
2. It can stably lock the body of the truck when going up and down the slope, avoiding slipping and increasing the safety factor.
3. It will not increase the load burden of transportation vehicles and meets the load limit requirements of urban freight transportation.
Electric Self Loading Stacker 500kg 1000kg Portable Design for Truck Loading
If you have any questions about this Semi-Electric Self-loading Stacker, please feel free to contact me via the following methods. I will be on call 24 hours a day. Thank you.
Model
CDD15D
CDD07B
CDD10E
CDD13
CDD15E
Type of Power
Li-Ion Battery
Li-Ion Battery
Li-Ion Battery
Li-Ion Battery
Battery
Max. Load
kg
1500
700
1000
1300
1500
Load Center
mm
400
400
400
400
400
Wheelbase
mm
1003
922
924
916
924
Wheel Distance: FR
mm
405/525
405/525
405/525
405/525
405/525
Wheel Distance: RR
mm
642/762
802
802
802
802
Type of Operation
Walk
Walk
Walk
Walk
Walk
Front Wheel
mm
2-Φ80×70/2-Φ80×60
φ80×70
φ80×70
2-φ80×70
2-φ80×70/2-φ80×60
Universal Wheel
mm
2-Φ50×43
Φ75×50
φ75×45
2-φ75×45
Φ75×45
Middle Wheel
mm
Φ45×30
φ45×30
2-φ45×30
Φ45×30
Driving Wheel
mm
Φ185×70
Φ185×70
φ185×70
φ185×70
Φ185×70
The Distance the Forks Extend
mm
256
158
158
158
158
Length of Outriggers
mm
791
770
770
772
780
Max. Fork Height
mm
800/900/1000/1100/1200 /1300/1500/1600
800/900/1000/1100/1200 /1300/1500/1600
800/900/1000/1100/1200 /1300/1500/1600
800/900/1000/1100/1200 /1300/1500/1600
800/900/1000/1100/1200 /1300/1500/1600
External Distance Between Forks
mm
565/685
565/685
565/685
565/685
565/685
Length of Fork
mm
1150
1195
1195
1250
1250
Thickness of Fork
mm
70
70
70
70
80
Width of Fork
mm
176.5
190
190
190
190
Overall Length
m
1586
Overall Length
mm
1851
1603
1603
1655
1657
Overall Width
mm
824/944
852
852
852
802
Overall Height (Mast Closed))
mm
1250/1350/1450/1550/1650 /1750/1950/2050
1155/1255/1355/1455/1555 /1655/1855/1955
1166/1266/1366/1466/1566 /1666/1866/1966
1163/1263/1363/1463/1563 /1663/1863/1963
1163/1263/1363/1463/1563 /1663/1863/1963
Overall Height (Max. Fork Height)
mm
1867/2067/2267/2467/2667 /2867/3267/3467
1875/2075/2275/2475/2675 /2875/3275/3475
1850/2050/2250/2450/2650 /2850/3250/3450
1861/2061/2261/2461/2661 /2861/3261/3461
1861/2061/2261/2461/2661 /2861/3261/3461
Lifting speed
mm/s
55
55
55
55
55
Descent speed
mm/s
100
100
100
100
100
Lift Motor Power
kw
2.2
0.8
1.6
1.6
2.0
Driving Motor Power
kw
0.8
0.8
0.8
0.8
0.8
Max. speed(Turtle speed / full-load)
kw/h
1/3.5
1/3.5
1/3.5
1/3.5
1/3.5
Grade Ability(Full-load/NO-load)
%
5/10
5/10
5/10
5/10
5/10
Battery Voltage
V
48
48
48
48
48
Battery Capacity
Ah
Standard configuration (15) optional (30/quick change 30)
Standard configuration (15) optional (30/quick change 30)
Standard configuration (15) optional (30/quick change 30)
Standard configuration (15) optional (30/quick change 30)
25
Battery Weight
kg
10kg/2*17kg
6/10/10
6/10/10
6/10/10
25
Total Weight(Include Battery)
kg
450/354/460/463/466 /470/480/480
266/270/274/278/282 /286/295/300
302/316/320/324/328 /332/342/347
365/369/375/378/381 /385/395/400
390/394/400/403/406 /410/420/425
