LFP24-300 High-Capacity RV Lithium Battery for Off-Grid Adventures, Marine Use & Backup Storage
LFP24-300 High-Capacity RV Lithium Battery for Off-Grid Adventures, Marine Use & Backup Storage
Specifications
Brand Name :
Ecolite/OEM/ODM
Model Number :
LFP24-300
Place of Origin :
China
MOQ :
500
Price :
Inquiry
Payment Terms :
L/C,T/T
Supply Ability :
5000 Units per month
Delivery Time :
1-2 months
Packaging Details :
Carton Pallet Container
Battery Nominal Voltage :
25.6V
Battery Rated Capacity :
314Ah
Energy :
8038Wh
Internal Resistance :
≤20mΩ
Cycle Life :
>8000cycles @0.5C,80% DOD
Efficiency :
≥0.98
Self Discharge :
＜5% per Month
Discharge Temperature :
-20℃ to 60℃
Storage Temperature :
-10℃ to 35℃
Continuous Discharge Current :
200A
Maximum Charge Current :
200A
Description

LFP24-300 High-Capacity RV Lithium Battery for Off-Grid Adventures, Marine Use & Backup Storage
For RV enthusiasts chasing cross-country freedom, boat owners navigating coastal waters, or homeowners securing reliable backup power—finding an RV Lithium Battery that blends massive energy, rugged durability, and flexible performance is non-negotiable. The EcoLite LFP24-300 (25.6V314Ah) is engineered to be that solution: a premium LiFePO4 RV Lithium Battery delivering 8038Wh of power, industry-leading longevity, and tailored functionality for RV, marine, and energy storage needs—with full customization to match your unique setup.


LFP24-300 High-Capacity RV Lithium Battery for Off-Grid Adventures, Marine Use & Backup Storage

Electrical Parameters
Nominal Voltage 25.6V
Rated Capacity 314Ah
Nominal Energy 8038Wh
Internal Resistance ≤20mΩ
Efficiency ≥0.98
Cycle Life >8000cycles @0.5C,80% DOD
Self Discharge <5% per Month
Cell in Series,Parallel 8S/1P

Mechanical Parameters
Dimension(LxWxH) 655x290x270mm
Dimension((LxWxH) 25.79x11.42x10.63''
Weight 68Kg
Terminal Type M8
Battery Housing SPCC
Housing Protection IP65
Cell Type-Chemistry LiFePO4 Cell
Communication Bluetooth

Charge Parameters
Charge Method CC-CV
Charge Voltage 28.4~29.2V
Recommended Float Voltage 26.2~26.8V@100%
Recommended Charge Current 150A
Maximum Charge Current 200A
BMS Charge Cut-off Voltage 29.2V

Discharge Parameters
Continuous Discharge Current 200A
Pulse Discharge Current 300A(<1S)
Recommended Volt. Disconnect 20V
BMS Discharge Cut-off Voltage 20V
Reconnect Voltage 21.6V
Short Circuit Protection 100-400us

Temperature Parameters
Discharge Temperature -20℃ to 60℃
Charge Temperature 0℃ to 55℃
Storage Temperature -10℃ to 60℃
BMS High Temperature Cut-off 65℃

Why This RV Lithium Battery Solves Your Biggest Power Frustrations

Every feature of this RV Lithium Battery is built to address the pain points users face with traditional lead-acid batteries or low-quality lithium alternatives—focused on reliability, convenience, and long-term value.

1. Unrivaled Longevity: 8000+ Cycles for Years of RV & Marine Use

Tired of replacing heavy, short-lived batteries every 1–2 years? This RV Lithium Battery leverages LiFePO4 chemistry to deliver an exceptional cycle life of >8000 cycles (tested at 25℃, 0.5C/0.5C, 100% DOD) with remaining capacity >70%. For RVers taking 10+ trips yearly, boat owners using their vessels seasonally, or homeowners relying on backup storage—this means a decade of hassle-free power (5–10x longer than lead-acid). No more unexpected battery failures mid-adventure or costly annual replacements—this RV Lithium Battery is an investment in long-term reliability.

2. Wide Temperature Resilience: Power Through Extreme RV & Marine Climates

RVs venture from snowy mountain campsites (-20℃) to desert parks (60℃); boats endure saltwater humidity and fluctuating coastal temperatures. This RV Lithium Battery thrives in it all:
  • Discharge Temperature Range: -20℃ to 60℃ – Keeps your RV’s air conditioner, marine GPS, or home emergency lights running in harsh conditions.
  • Charge Temperature Range: 0℃ to 55℃ – Recharges safely without performance drops, even on cool RV mornings or warm afternoons at the dock.
  • BMS High-Temperature Cut-off (65℃): Adds a safety layer against overheating—critical for enclosed RV battery compartments or marine engine rooms.

3. High Charge/Discharge Rates: Fast Recharges & Power for Demanding Gear

Whether you’re powering a 2kW RV rooftop AC or a marine bilge pump, this RV Lithium Battery delivers the speed and strength you need:
  • 200A Continuous Discharge Current: Handles high-wattage RV/marine equipment (e.g., refrigerators, water heaters, or fish finders) without voltage dips.
  • 300A Pulse Discharge (<1S): Tackles sudden power spikes (e.g., starting a boat’s auxiliary motor or RV’s microwave) with ease.
  • 200A Maximum Charge Current: Recharges rapidly via CC-CV technology—reach full capacity fast, so you spend less time waiting at RV hookups or marinas and more time enjoying your trip.

Key Features of This RV Lithium Battery (Tailored to User Needs)

Beyond core performance, this RV Lithium Battery includes user-centric features that simplify operation and boost versatility—perfect for off-grid lifestyles.

Integrated BMS for Ultimate Safety

A robust Battery Management System (BMS) protects the RV Lithium Battery (and your gear) from overcharging, over-discharging, short circuits (100–400µs response), and overcurrent. This means no risk of damage to your RV’s electronics, marine navigation systems, or home devices—even during unexpected power fluctuations.

Rugged, Weather-Resistant Design

Housed in durable SPCC steel with IP65 protection, this RV Lithium Battery resists dust, splashes, and mild saltwater corrosion. It’s built to withstand the bumps of RV travel, the humidity of marine environments, and the elements of outdoor energy storage setups—no need for extra enclosures.

Bluetooth Remote Monitoring

Check the RV Lithium Battery’s State of Charge (SOC), voltage, and temperature remotely via Bluetooth. No more crawling into your RV’s battery compartment or leaning over the boat’s deck to track power levels—monitor performance from your phone, anytime.

Flexible Scalability

Supports up to 2 batteries in series (for higher voltage) or 4 in parallel (for larger capacity)—ideal for expanding your RV’s power system for longer trips, upgrading a marine setup for multi-day voyages, or scaling home energy storage to cover more devices.

Customizable for Your Setup

We know one size doesn’t fit all. This RV Lithium Battery offers customization for housing (material/color) and capacity—whether you need a compact fit for a small RV, a corrosion-resistant shell for saltwater boating, or adjusted capacity for specific energy storage needs.
