Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Specifications
Type :
Vibratory Roller
Travel Speed :
0-10 KM/H
Grade Ability :
35%
Make :
LUHONGDA
Place of Origin :
Shandong, China
Brand Name :
LUHONGDA
Model Number :
10 ton road roller
Power(W) :
70.2 KW
Dimension(L*W*H) :
5120*1900*2690 MM
Warranty :
1 Year
Hydraulic Pump Brand :
KYB
Hydraulic Valve Brand :
KYB
Engine Brand :
YUNNEI
UNIQUE SELLING POINT :
Fully hydraulic system
Drum diameter :
1220 MM
Drum :
Single Drum Roller
Exciting Force :
93 KN
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Core Components :
Motor, Pump, Engine
Compaction width :
1700 MM
Vibration frequence :
51 Hz
Steel wheel size :
1700*1200 MM
Drive type :
Hydraulic station
Vibration type :
Hydraulic Vibration
Starting mode :
Electric
Operating weight :
10000 KG
Engine :
YN35C
Diesel Speed :
2400 R/Min
Fuel Tank Capacity :
260 L
MOQ :
1 set
Description
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
ITMIRS
SPECIFICATION
Drum Width
1700 MM
Drum Diameter
1220 MM
Working Weight
10000 KG
Gradeability
35%
Start Form
Electric Start
Product Size
5120*1900*2690 MM
Walking Speed
0-10 KM/H
Vibration Frequency
51 Hz
Vibration Force
93 KN
Turning Radius
6000 MM
Static Line Load
294 N/cm
Vibration Form
Hydraulic Vibration
Braking System
Disc air cap oil brake
Engine Model
YN35C
Diesel Speed
2400 R/Min
Engine Power
70.2 KW
Fuel Tank Capacity
260 L
This 10-ton road roller is equipped with a Yunnei engine, known for its reliable performance, strong power output, and excellent fuel efficiency. The engine ensures stable operation even under heavy-duty working conditions, making it ideal for long hours of continuous use. The roller delivers powerful compaction force, effectively compacting soil, gravel, and asphalt layers. It is well-suited for a wide range of construction scenarios, including road foundations, highways, urban roads, industrial sites, and large-scale infrastructure projects. With its robust performance and durable design, it provides a cost-effective and dependable solution for both contractors and developers.
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Compact Static Road Roller With 10 Ton Capacity Mini Small Compactor Vibratory Road Roller Machine
Our factory is dedicated to the manufacturing of both small-scale and large-scale road rollers, providing a comprehensive selection of equipment to accommodate the varied requirements of our clients. Whether for confined construction spaces or extensive infrastructure developments, we are well-equipped to deliver high-performance and dependable compaction solutions. We are pleased to offer preferential pricing for bulk orders and cordially invite customers to reach out to us for detailed inquiries and customized support.
