1100 Aluminum Coil

Product Description:

Features:

Common Tempers (States)

The temper designation indicates the level of hardness and strength achieved through mechanical processing.

Temper Description Key Characteristics
O Soft / Annealed Maximum ductility, lowest strength, excellent for deep drawing and complex forming
H12 1/4 Hard Strain-hardened to a quarter-hard level. Balanced formability and strength
H14 Half Hard (Most Common) Strain-hardened to a half-hard level. Popular for general sheet metal work, offering enhanced rigidity
H16 3/4 Hard Strain-hardened to a three-quarter-hard level. Higher strength, reduced formability
H18 Full Hard Strain-hardened to maximum strength, minimum ductility
H22, H24, H26 Strain-hardened & partially annealed Intermediate tempers offering specific balances between strength and formability
Note: As the degree of work hardening increases (from O to H18), strength increases while formability decreases.

Thickness Range

1100 aluminum coil is available in a wide range of thicknesses to suit various applications.

Standard Range: 0.1 mm – 12.0 mm (0.004" – 0.472")

Ultra-Thin Gauge (Foil): Can be as low as 0.014 mm – 0.4 mm

Heavy Gauge: Up to 350 mm (for specific industrial applications, more common in plate form)

Common Coil Range: 0.2 mm – 3.0 mm for most coil applications

Note: Mechanical properties like tensile strength and elongation can vary slightly depending on the specific thickness within a temper.

Width Range

The width of 1100 aluminum coils is highly customizable depending on the supplier's slitting capabilities.

Common Width Range: 10 mm – 2650 mm (approx. 0.4" – 104")

Standard Stock Widths: Common stock widths include 1000 mm, 1219 mm (48"), 1250 mm, and 1524 mm (60")

Slitting Capabilities: Coils can be slit to specific widths for custom requirements

Inner Diameter: Typically 508 mm (standard)

Common Applications

Thanks to its high purity, excellent corrosion resistance, and superior formability, 1100 aluminum coil is used across a vast range of industries.

Food & Chemical Industry
Cooking utensils, pots, pans, and lids

Food and chemical handling equipment

Storage tanks and processing equipment

Bottle caps and closures

Foil and food packaging containers

Electrical & Electronics
Heat sinks and thermal management components

Capacitor shells and components

Transformer winding strips

Bus bars and electrical conductors

Lamp reflectors and lighting fixtures

Building & Construction
Building facades and architectural panels

Curtain wall decoration

Signage, nameplates, and traffic signs

Ceiling panels and decorative trim

Industrial & Manufacturing
Sheet metal work and general fabrication

Spun hollowware and deep-drawn stampings

Fin stock for heat exchangers

Chemical equipment and tank linings

Specialized Applications
CTP/PS plate base for printing industry

Reflective surfaces and mirror finishes

HVAC components and insulation jacketing

Technical Parameters:
