Specifications
Brand Name :
Leomed
Model Number :
Phoeonix-9C
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
$2000
Payment Terms :
T/T
Delivery Time :
5-8 work days
Product Name :
Phoenix-9C Ceramic Sintering Furnace
Material :
Silicon Carbide Heating Rods
Max Temperature :
1530°C
Heating Rate :
200°C/minute
Voltage :
100-120V/230V Dual Mode
Dimensions :
27×36×56 cm (Main Unit)
Description

1530°C Fast-Sintering Ceramic Furnace 200°C/Min Heating Rate Silicon Carbide Rod Tech

The Phoenix - 9C sintering furnace redefines the efficiency standard of small - sized sintering equipment. Its core advantage lies in breaking through the traditional series - connection mode of silicon - carbide rods. By precisely adjusting the voltage to drive the heating elements, this innovation not only reduces the thermal load on silicon - carbide rods, extending their service life by over 30%, but also achieves extremely fast heating. It can reach a high temperature of 1530 °C in only 20 minutes, and the entire crystallization process can be completed in as short as 40 minutes, providing an efficient solution for laboratory sample preparation and small - batch production.​
Core Product Features​
  • High - Efficiency Heating System: With a heating rate of up to 200 °C/minute, it far exceeds that of similar equipment, significantly shortening the sintering cycle.​
  • Precise Temperature Control: The highest temperature of 1530 °C can be stably maintained, and the longest holding time reaches 2 hours and 46 minutes, meeting the needs of complex sintering processes.​
  • Flexible Power Adaptability: It is compatible with 100 - 120V and 230V voltages (50/60Hz), with currents of 14.5A@110V and 7.0A@230V respectively, suitable for power grids in most regions around the world.​
  • Compact Design: The main body size is 27×36×56cm (including some accessories), the furnace core platform diameter is 6.5cm, and the net weight is only 20Kg, saving laboratory space.​
Technical Principle and Applications​
The Phoenix - 9C uses voltage - regulation technology instead of series - connection driving, making the heating of silicon - carbide rods more uniform and reducing local overheating losses. It has a wide range of applications, including ceramic material sintering, small - scale glass crystallization experiments, and metal powder densification treatment. It is especially suitable for high - frequency use in research institutions and small - scale manufacturing enterprises.
Parameter Specific Value
Maximum Temperature 1530 °C
Heating Rate Up to 200 °C/minute
Power Adaptability 100 - 120V/230V 50/60Hz
Maximum Power 1300W
Furnace Core Diameter 6.5cm
Net Weight 20Kg (±1Kg, subject to accessory adjustment)
