High Fresh Rate Waterproof Led Display Exterior Led Panels For Stage
High Fresh Rate Waterproof Led Display Exterior Led Panels For Stage
High Fresh Rate Waterproof Led Display Exterior Led Panels For Stage
High Fresh Rate Waterproof Led Display Exterior Led Panels For Stage
High Fresh Rate Waterproof Led Display Exterior Led Panels For Stage
High Fresh Rate Waterproof Led Display Exterior Led Panels For Stage
High Fresh Rate Waterproof Led Display Exterior Led Panels For Stage
High Fresh Rate Waterproof Led Display Exterior Led Panels For Stage
Specifications
Place of Origin :
Guangdong, China
Model Number :
LRSP3.91
Brand Name :
LongRun
MOQ :
1 Piece
Price :
Negotiable
Application :
outdoor advertising
Color :
full color RGB
Panel Size :
250*250mm
Pixel Pitch :
3,91mm
Pixels per sqm :
3.91mm
Module size :
250*250mm
Brightness :
800-3000cd/sqm
Scan method :
1/16scan
Fresh rate :
>3840 Hz
Grey Level :
Current >3mA: 16bits
Certificate :
CE
Life Span :
>100,000 hours
Input voltage :
AC 110 or 220 V ±10%
Selling Units :
Single item
Single package size  :
65X85X67 cm
Single gross weight :
110.0 kg
Package Type :
For fixed instalation, wooden case or celluar carton packing is recommendedad gorgeous led display xxx video movies.
Description

High Fresh Rate Waterproof Led Display Exterior Led Panels For Stage

Feature

1. Standard dimension,module size 250mm * 250mm, cabinet size 500mm * 500mm, compatible P3.91 outdoor common-cathode led module.

2. High-precision die-cast aluminum cabinet, seamless unit box.

3. New design of top side lock,secondary small red lock to avoid loose cabinet caused by unintentional touch.

4. One-button open back cover,easy to take off the power supply and receiving card.

5. Module with back screw , uncessary to prepare tool, easy to fix and take off modules by hand.

6. Corners with small protectors, save the money,package and space.

P3.91 SPECIFICATION

500-S Outdoor Common-cathode Rental P3.91 Black Pixel 500-s Cool LED Display for hot weather

Specification

Item No.

P3.91 die cast aluminium led display screen

Classification

Full color

Pixel pitch

3.91 mm

Size of module (mm*mm)

250*250 mm

Pixel density

65536 dots/m2

Pixel composition

1RGB

LED encapsulation

SMD 1919

Resolution of module

64*64

Best viewing angle (Horizontal/Vertical)

160°/140°

Max power consumption

1200W/m2

Driving method

1/16 Scan

Refresh rate

≥3840HZ

White balance brightness

≥800~3000cd/m2

Working voltage

AC 220±10% or 110±10%

IC

ICN2150+ICN2012

Cabinet material

Die cast aluminium

Cabinet size

500*500mm

Cabinet weight

7 kg/cabinet

Non-Flatness

<1mm

Contrast Ratio

4000:1

Blind Spot Rate

<0.000001

Grey scale

14 bits

Product Pictures

High Fresh Rate Waterproof Led Display Exterior Led Panels For StageHigh Fresh Rate Waterproof Led Display Exterior Led Panels For Stage

What is the biggest difference between common-cathode led display and traditional led display?

The separate power supply of RGB chip.To lessen the currents' waste,the consumption is lower and heat is less which ensure the color temperature.Displaying a long-time, natural and vivid picture under outdoor hot weather is better.

High Fresh Rate Waterproof Led Display Exterior Led Panels For Stage

Success Case

High Fresh Rate Waterproof Led Display Exterior Led Panels For Stage

High Fresh Rate Waterproof Led Display Exterior Led Panels For StageHigh Fresh Rate Waterproof Led Display Exterior Led Panels For Stage

Logistics

High Fresh Rate Waterproof Led Display Exterior Led Panels For Stage

High Fresh Rate Waterproof Led Display Exterior Led Panels For Stage

Service Details

1. Your inquiry related to our products or price will be replied in 24hrs.


2. OEM&ODM,any your customized lightings we can help you to design and put into product.


3. Distributoership are offered for your unique design and some our current models.


4. Protection of your sales area,ideas of design and all your private information.


5. Best cost performance and perfect service before and after sales.
