Aluminum Acrylic/Iron PS Lens Intelligent LED Trunking Fixtures for Warehouse Lighting
Aluminum Acrylic/Iron PS Lens Intelligent LED Trunking Fixtures for Warehouse Lighting
Specifications
Brand Name :
Noonlight
Model Number :
N-TLB-2FT
Place of Origin :
China
Certification :
DLC, ISO9001, Rosh, ETL,
MOQ :
100pcs
Price :
Negotiable
Packaging Details :
Carton box
Delivery Time :
30 day(s)
Payment Terms :
T/T, AliPay, PayPal
Supply Ability :
3000 pcs/day
Warranty :
5 Years
Lifespan :
50,000hrs
Application :
LED Trunking Lighting System
CRI :
>80 >90 >95
Material :
Aluminum + Acrylic/Iron +PS Lens
Beam Angle :
30°,60°,90°,120°
Power :
30W(Max)
Luminous Efficacy :
160LM/W(Max)
Description

Product Description:

If you are looking for an exceptional lighting option for your space, the LED Trunking Light System is the perfect choice. It boasts a unique architectural design with its aluminum housing that offers incomparable aesthetic value.

Easy Installation

You'll be glad to know that installing this light system is effortless. You can choose between pendent, mounted, or recessed installation, depending on your preference. Regardless of the method you pick, you'll be able to install the LED Trunking Light System quickly and without complications.

Seamless Daisy Chain Connection

The LED Trunking Light System also features a seamless daisy chain connection that makes it easy to create long lines of continuous lighting with minimal effort. This feature eliminates the need for complicated wiring during installation, making your lighting project simpler and less expensive.

Customizable Light Beam Angle

One of the best things about the LED Trunking Light System is that it offers various lighting beam angles. This feature makes it the go-to light system for various settings where different requirements for lighting exist. Additionally, the light system offers up and down lighting options, providing the flexibility you need to customize it to fit your specific requirements.

Standard or Customized Lengths

Features:

The light fixtures are available in 30W at 60cm, 45W at 90cm, and 60W at 120cm. Additionally, there are two options for light efficacy which are 125Lm/W and 160 Lm/W. Customers can choose from different beam angles including 30°, 60°, 90°, and 120°. The dimming options for these lights include 0-10V (dual channel), Dali 2, and Non-dim. Moreover, wattage is adjustable across four settings, and the color temperature is tunable across four options.

There are also various options available for the CRI, including CRI>80, CRI>90, and CRI>95. To make sure the fixtures integrate with different settings, there is also an option for motion sensing and an emergency battery pack for added safety and convenience.

To present this information more clearly, we can use html tags to format the text:

  • The light fixtures are available in 30W at 60cm , 45W at 90cm , and 60W at 120cm .
  • Additionally, there are two options for light efficacy which are 125Lm/W and 160 Lm/W .
  • Customers can choose from different beam angles including 30° , 60° , 90° , and 120° .
  • Dimming options for these lights include 0-10V (dual channel) , Dali 2 , and Non-dim .
  • Moreover, wattage is adjustable across four settings, and the color temperature is tunable across four options.
  • There are also various options available for the CRI , including CRI>80 , CRI>90 , and CRI>95 .

Certifcate:

Aluminum Acrylic/Iron PS Lens Intelligent LED Trunking Fixtures for Warehouse Lighting

Specifcation:

Model No Dimmable Input Voltage CRI Wattage LPW Lumen Beam Angle
N-TLB-2FT-40W-DF 0-10V
0-10V Dual Channel
Dali2
Non-Dimmable		 120-277VAC
120-347VAC
220-240VAC		 >80
>90
>95		 30W 160LM/W(Max) 4800LM(Max) 120°
N-TLB-2FT-30W-[30,60,90] 30W 125LM/W(Max) 3750LM(Max) 30°,60°,90°
N-TLB-3FT-45W-DF 0-10V
0-10V Dual Channel
Dali2
Non-Dimmable		 120-277VAC
120-347VAC
220-240VAC		 >80
>90
>95		 45W 160LM/W(Max) 7200LM(Max) 120°
N-TLB-3FT-45W-[30,60,90] 45W 125LM/W(Max) 5625LM(Max) 30°,60°,90°
N-TLB-4FT-60W-DF 0-10V
0-10V Dual Channel
Dali2
Non-Dimmable		 120-277VAC
120-347VAC
220-240VAC		 >80
>90
>95		 60W 160LM/W(Max) 9600LM(Max) 120°
N-TLB-4FT-60W-[30,60,90] 60W 125LM/W(Max) 7500LM(Max) 30°,60°,90°

Aluminum Acrylic/Iron PS Lens Intelligent LED Trunking Fixtures for Warehouse Lighting

Accessories:

Aluminum Acrylic/Iron PS Lens Intelligent LED Trunking Fixtures for Warehouse Lighting

Emergency Pack
Specification
Input Voltage:100~277Vac/347Vac 50/60Hz , Input Current:100mA max.
Input Power Rating:7W max.
Output Voltage:25V~230Vdc
Emergency Power:30W max.
Warranty:5 Years
Ambient Temp:Li-ion:32~122°F(0~50°C)
Ni-MH: 41~149°F(5~65°C)
Weight:0.908 lbs(0.41kg)
Surge Protection:Line-Neutral 3KV

Applications:

Super market, office, commercial places, hospital, gym, warehouse, workshop, shopping mall
