Multi Power CCT Adjustable LED Stairwell Lights 130 M/W
Multi Power CCT Adjustable LED Stairwell Lights 130 M/W
Specifications
Brand Name :
Noonlight
Model Number :
NL-LC4-2FT
Certification :
DLC / ETL / RoHS
Place of Origin :
China
MOQ :
200
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, Paypal
Supply Ability :
10000 Piece/Pieces per Month
Delivery Time :
30+ working days
Packaging Details :
1pc/inner box, 4pcs/CTN,
Product Name :
4” Wide 2FT Multi Power And CCT Adjustable 1300-4000lm LED Linear Stairwell 30-50K With Emergency Pack
Power :
30W-20W-14W-10W Power Adjustable
CCT :
30K/35K/40K/50K Tunable
Luminous Efficacy :
130 lm/W
Housing :
24 Gauge Steel, Gloss White Painting, PC Lens
Installation :
Surface Mounted, Suspension Mounted
DLC Category :
Direct Linear Ambient Luminaires & Stairwell and Passageway Luminaires
Description

4” Wide 2FT Multi Power And CCT Adjustable 1300-4000lm LED Linear Stairwell 30-50K With Emergency Pack

Multi Power CCT Adjustable LED Stairwell Lights 130 M/W

  • Integral with new trend of field-adjustable functions provide our customers greater flexibility on wattages and color temperatures.

  • Optional Occupancy Sensor & Built-in Emergency Backup

  • Ideal for stairwell, passageway and general lighting etc.

Multi Power CCT Adjustable LED Stairwell Lights 130 M/W

  • UP TO 135LM/W
  • An auxiliary to connect low voltage sensor/BLE or other IOT network.
  • Various Lens Option: Clear, Frosted,
  • Built-in Emergency Driver Option.
  • L70>50,000hrs, 5 year warranty.

Multi Power CCT Adjustable LED Stairwell Lights 130 M/W

Model No DLC Input Voltage Wattage Lens CRI/CCT Rated Lumen @ 50K

Rated

Efficancy

@ 50K

 Viewing Angle Replacing
N-LC4-2FT-30W-1XX-
[Blank, S1, S2]-C-FL-
CT-FA-Z		 YES

100-277VAC

or

100-347VAC

 30

Frosted/

Clear

Ra>80,

30K

35K

40K

50K

 3700 123 180°

3 X T5HO 2FT 24W

4 X T8 2FT

17W
N-LC4-2FT-20W-1XX-
[Blank, S1, S2]-C-FL-
CT-FA-Z		 YES

100-277VAC

or

100-347VAC

 20

Frosted/

Clear

Ra>80,

30K

35K

40K

50K

 2440 127 180°

3 X T5HO 2FT 24W

4 X T8 2FT

17W
N-LC4-2FT-14W-1XX-
[Blank, S1, S2]-C-FL-
CT-FA-Z		 YES

100-277VAC

or

100-347VAC

 14

Frosted/

Clear

Ra>80,

30K

35K

40K

50K

 1750 128 180°

3 X T5HO 2FT 24W

4 X T8 2FT

17W
N-LC4-2FT-10W-1XX-
[Blank, S1, S2]-C-FL-
CT-FA-Z		 YES

100-277VAC

or

100-347VAC

 10

Frosted/

Clear

Ra>80,

30K

35K

40K

50K

 1250 127 180°

1 X T5HO 2FT 24W

1 X T8 2FT

17W

Multi Power CCT Adjustable LED Stairwell Lights 130 M/W

Multi Power CCT Adjustable LED Stairwell Lights 130 M/W

4W or 8W UL Listed Emergency Backup

  • Listed for field Instllation-UL924 & CSA C22.2 NO. 141
  • Input: 120-277VAC/347VAC 50/60Hz
  • Output: 25-50VDC, 15 or 30W
  • Illumination Time: 90min
  • Battery Type:Li-ion/Ni-MH
  • Battery Recharge Time: 24Hrs
  • Surge Protection: 3KV
  • Protection:
  • Input over-current Protection (Fuse)
  • Output over-voltage Protection
  • Output Low Voltage Protection
  • Output Short Circuit Protection
  • Working Temp.: 10℃ to 50℃

Multi Power CCT Adjustable LED Stairwell Lights 130 M/W

HOW TO CHANGE THE WATTAGE IN THIS FIXTURE

Multi Power CCT Adjustable LED Stairwell Lights 130 M/W

Power Adjustable Slide Switch Position

Size/Positon

W1

W2

W3

W4

2FT

30W

20W

14W

10W

4FT

40W

25W

18W

12W

CCT Tunable Slide Switch Position

Position/Group

CCT

CCT1

3000K

CCT2

3500K

CCT3

4000K

CCT4

5000K

Multi Power CCT Adjustable LED Stairwell Lights 130 M/W

Multi Power CCT Adjustable LED Stairwell Lights 130 M/W

Multi Power CCT Adjustable LED Stairwell Lights 130 M/W

Stairwell Lighting, Passageway Lighting, Corridor Lighting, Shop Lighting, Strip Lighting, Low Bay Lighting, Warehouse Lighting
