100Watt SMD High Power LED Street Light / LED Road Lights High Brightness CRI > 70Ra
100Watt SMD High Power LED Street Light / LED Road Lights High Brightness CRI > 70Ra
100Watt SMD High Power LED Street Light / LED Road Lights High Brightness CRI > 70Ra
100Watt SMD High Power LED Street Light / LED Road Lights High Brightness CRI > 70Ra
Specifications
Brand Name :
Die Casting Man/OEM
Model Number :
ZHSL-03-100(100W)
Certification :
CE,ROHS, UL,SAA
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
By T/T 30% in advance and 70% after shipment EXW/FOB NINGBO, Western Union
Supply Ability :
10000PCS/Month.
Delivery Time :
7-30 days base on order quantity
Packaging Details :
Carton box with foam
Manufacturer :
Ninghai Zhouhua Die Casting Co.,Ltd
Material :
ADC12 Aluminum
Wattage :
100W
Fixture Color :
grey
IP :
65
LED Color :
WW/NW/CW
CRI :
>70
Input Voltage :
AC85 - 265V
Frequency Range :
50 - 60Hz
Working Ambient Humidity :
10% - 90%
Working Ambient Temperature :
-30℃ - 50℃
Description

SMD 100W LED Led Street Light Fixtures with tempering glass Diffuser 85-265VAC

Quick Detail:

Name

100W SMD Led Steet light

Application

Use for Street

Color

Grey

Feature

Old Design

Lamp Luminous Flux(lm)

9200

Certificate

TUV/UL /CE/ROHS

Description:

Old Patent 100W SMD LED streetlight made of High quality Die Casting Aluminum housing +Cree LED +UL LED Driver

1. The old version of high power SMD LED Street Light Housing.

2. State-of-art designing with completed die-casting body as heat sink offer the maximum heat management system,which can hold maximum 100pcs of 1W Creee SMD led.

3. Patented anti-glare optic lense enable this street light give an maximum 130 degree and 140 degree light spread,with an asymmetrical polar curve.

4. IP65 protection grade.

5. User-friendly mechanical designing,easy to assemble the led,potic lense and led power supply.

6.The Led power supply is designed to installed with two U brackets,so any brand of led power supply can be easily installed.

Applications:

minor roads,Motorways,Major roads,roundabouts,crossing and industrial areas.

Specifications

Model Number

ZHSL-03-100

Electrical Specifications

LED QTY

1Wx100PCS

TotaLPower consumption

100W

Operation Voltage

85-265VAC or 12VDC or 24VDC

Operating Humidity

10%~90%

Working Temperature

-30 ~ 50°C

Power Fact(PF)

>0.95

Driver Efficiency

> 0.9

Photometric Specifications

LED Luminous Flux

10000 lm - Initial

9200 lm - Maintain

Led Luminous Efficiency

>90LM/W

CRI

Ra ≥ 70

LED Color

3000k-6500k

Mechanical Specifications

IP Rating

IP65

Warranty

3Years

Heat Radiator

die-casting body as heat sink

Lens

tempering glass

Fixture Dimension

744.5x301x95.4MM

Fixture Weight

7.7kgs(17lbs)

Packing Information

Packing Type

1unit /ctn

Packing Dimension

79 x35 x16 cm (31” x13.8” x6.3”)

Packing Weight

8.6kgs(19lbs)

Our service:

your inquiries will be replied in 24 hours in our working days.

  • 3years warranty under normal use.
  • Professional design provided.
  • Timely delivery guaranteed.
