Specifications
Model Number :
Q24 DC
CCT :
6000K
Brand Name :
Intuiit
Light Source :
24*2W RGBW 4IN1
Supply Ability :
10000pcs per months
Product Measurement :
1000*109*139.5mm
Warranty :
2 years
Delivery Time :
25-35days
Light source :
LED
MOQ :
50
Packaging Details :
Carton
Control :
8 sections control
Payment Terms :
L/C, T/T
Beam angle :
9°
Certification :
CE、RoHs
Place of Origin :
China
IP rated :
IP65
Description

9° Outdoor Wall Washer – Segmented Precision Optics for Architectural Facades

9° Ultra-Narrow Wash. 8-Segment Control. Seamless Architectural Integration.

Key Specifications

Parameter Specification
Beam Angle 9° Ultra-Narrow
Control Segments 8 Programmable Zones
Lighting Modes Wall Wash + Direct-View Dual Mode
Design Modular Serialized Architecture

Core Advantages

9° Razor-Sharp Optics. Precision-engineered beam angle sculpts light across exterior surfaces with surgical clarity—defining textures, emphasizing architectural geometry, and creating the crisp shadow-to-light transitions that elevate premium facades.

8-Segment Independent Control. Program individual zones for dynamic gradient washes, rhythmic scene transitions, and instant ambiance shifts. Far beyond static floodlighting, this granular control transforms a building envelope into a responsive visual canvas.

Dual-Mode Output. Toggle between refined wall-washing for facade emphasis and direct-view glow for entryway or perimeter presence. One fixture serves both architectural accent and ambient illumination roles.

Modular Serialized Architecture. Scalable, chainable design adapts to any elevation geometry—from boutique storefronts and hotel entrances to continuous commercial facades and public plazas.

Applications

Architectural Facades · Hotel & Hospitality Exteriors · Commercial Storefronts · Public Plazas · Landscape Accent Walls · Entrance & Perimeter Illumination

Specification

Product Name 24*2W LED wall washer light
Item Number Q24 DC
Product Measurement 1000*63*50mm
Light source LED
Light Source 24*2W RGBW 4IN1
CCT 6000K
DMX Channel 4/6/9/32/37CH
Control protocol DMX512
Beam angle 9° Spot angle 26°
Max Lumen 722lm
Drive current 2A
Dimming 0-100%
IP Grade IP65 Working Temperature -20°~+45
Data Protocol

Auto Run,Built-in,Master & Slave
